Summary of Contents for turck TN865-Q120 Series

  • Page 1 Your Global Automation Partner TN…-Q…L…-H1147 UHF Read/Write Heads Instructions for Use...
  • Page 2 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 3: Table Of Contents

    Contents About These Instructions ........................ 5 Target groups........................ 5 Explanation of symbols used .................. 5 Other documents ...................... 5 Naming convention ...................... 5 Feedback about these instructions................ 5 Notes on the Product .........................  6 Product identification.....................  6 Scope of delivery ...................... 6 Legal requirements......................
  • Page 4 EU Declaration of Conformity .................. 59 14.2 FCC/IC digital device limitations – TN902-Q120L130-H1147 ....... 59 14.3 FCC/IC digital device limitations – TN902-Q175L200-H1147 ....... 60 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 5: About These Instructions

    This symbol denotes actions that the user must carry out. RESULTS OF ACTION This symbol denotes relevant results of actions. Other documents Besides this document the following material can be found on the Internet at www.turck.com: Data sheet Quick start guide Configuration manual...
  • Page 6: Notes On The Product

    Mounting aid incl. mounting bracket and two M6 × 8 screws Grounding set Four screw covers One screw cap M12 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 7: Legal Requirements

    45472 Mülheim an der Ruhr Germany Turck supports you with your projects, from initial analysis to the commissioning of your applic- ation. The Turck product database contains software tools for programming, configuration or commissioning, data sheets and CAD files in numerous export formats. You can access the product database at the following address: www.turck.de/products...
  • Page 8: For Your Safety

    The devices are not suitable for the protection of persons or property and must not be used in safety-related applications. The devices must not be used under water. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 9: General Safety Notes

    General safety notes The device only meets the EMC requirements for industrial areas and is not suitable for use in residential areas. The device may only be assembled, installed, operated, parameterized and maintained by professionally-trained personnel. The device may only be used in accordance with applicable national and international regu- lations, standards and laws.
  • Page 10: Product Description

    Read/write distances up to several meters (depending on ambient conditions, the parameter setting of the read/write head and the selected tag) Compact design for mounting in restricted spaces Protection class IP67 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 11: Operating Principle

    Operating principle The read/write heads are used for contactless data exchange with tags. For this the controller sends commands and data via the interface to the read/write head and receives the corres- ponding response data from the read/write head. The reading of the IDs of all RFID tags in the read area or the writing of an RFID tag with a specific production date are examples of typical commands.
  • Page 12: Functions And Operating Modes

    For this reason, the application must be tested in all cases under real conditions (particularly with read and write operations in motion). Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 13: Technical Accessories

    Technical accessories The following accessories are supplied with the device: Dimension drawing Type Ident-No. Description RH-Q240L280/Q280L640 7030296 Arm bracket for UHF read/write heads 45 ø 6,5 (4x) V02.00 | 2020/08...
  • Page 14: Installing

    0.5 m Front to front 2.5 m 1.25 m NOTE The stated values do not take into account the effect of the tags. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 15: Mounting Plate Fixing

    Mounting plate fixing „ Fasten the device with four M5 × 35 cylinder screws on a pre-drilled mounting plate. Fig. 5: Screwing the read/write head onto the mounting plate V02.00 | 2020/08...
  • Page 16: Mast And Tube Mounting

    Fit the device with the intended mounting aid as shown in the following figure. M6 x 8 Fig. 6: Mast and tube mounting Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 17: With The Rh-Q240L280/Q280L640 Arm Bracket

    With the RH-Q240L280/Q280L640 arm bracket The RH-Q240L280/Q280L640 arm bracket (Ident-No. 7030296) is not supplied with the device and must be ordered separately. „ Secure the read/write head with two M6 × 12 screws on the arm bracket. „ Mount arm bracket with read/write head at the intended mounting location. M6 x 12 Fig. 7: Mounting the read/write head on the arm bracket V02.00 | 2020/08...
  • Page 18: Connection

    2 WH Data Connection cables …/S2503 Pin assignment Wiring diagram 1 BN 3 BU – 4 WH Data 2 BK Data Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 19: Commissioning

    The read/write heads can be assigned additional parameters via the DTM in the PACTware 5.0 FDT frame application. FDT and DTM can be downloaded free of charge from www.turck.com. The planning and preparation of an RFID system require different measures, depending on the application.
  • Page 20: Connecting The Read/Write Head With A Pc Via The Interface Converter

    USB-interface RFID cable Power supply e.g. RK4.5T/S2500 STW-RS485-USB-PS Fig. 9: Connecting the read/write head via the interface converter with a PC Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 21: Creating A Project In Pactware

    7.1.3 Creating a project in PACTware „ Open PACTware. „ Right-click HOST PC in the project tree. „ Click Add device. Fig. 10: Adding a device in PACTware NOTE The example shows the connection via an interface converter. When using a TBEN- RFID interface, choose the BL Service Ethernet option.
  • Page 22 PC (COM & LPT). „ Set the transfer rate. Fig. 12: Setting up the RS485 interface „ Confirm the changes by clicking Accept. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 23 „ Right-click RS485 RFID in the project tree. „ Click Add device. Fig. 13: Adding the device to the RS485 interface V02.00 | 2020/08...
  • Page 24 Select the connected device (example: TN865-Q175L200-H1147). „ Confirm the selection with OK or double-click the device. Fig. 14: Select the connected device (example: TN865-Q175L200-H1147) Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 25 „ Right-click the device in the project tree. „ Establish a connection. Fig. 15: Establishing a connection The RFID Test and Parameterization functions can be started from the project tree at Additional Functions. V02.00 | 2020/08...
  • Page 26: Parameterizing Read/Write Heads With The Dtm

    The connection between the read/write head and the PC must be established. A project must have been created in PACTware. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 27: Starting The Extended Read/Write Head Parameter Setting

    7.2.1 Starting the extended read/write head parameter setting „ Right-click the device. „ Start the parameter setting: Choose Parameterization or Online parameterization. The device must be connected to the PC for the Online parameterization. Fig. 17: Example: starting online parameter setting V02.00 | 2020/08...
  • Page 28: Dtm Main Menu - Overview

    CSV export current values Exports the current values from the DTM to a CSV file. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 29: Choosing The Access Level

    NOTE Modifications made in the Administrator access level can result in serious changes to operation. The Administrator access level is therefore only available for Turck service technicians. All relevant settings for the successful parameter setting of an application are available in the Advanced access level.
  • Page 30: Calculating Radiated Power

    Set the required radiated power with the slide adjuster in the DTM at Ò Ò Antenna RF Power Output power. Fig. 20: Setting the radiated power Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 31: Switching On Presence Sensing Mode

    7.2.5 Switching on Presence sensing mode In order to use the Continuous presence sensing mode command, the Presence sensing mode must be activated in the read/write head. In Presence sensing mode, the read/write heads are automatically switched on as soon as a tag is located in the detection range. Ò...
  • Page 32: Transferring The Rssi Value - Communication

    Transponder RSSI and select the enabled option. The RSSI value is displayed with the inventory in the read data. Fig. 22: Switching on RSSI transmission Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 33: Setting The Air Interface Parameters - Epc Class 1 Gen 2

    7.2.7 Setting the air interface parameters – EPC Class 1 Gen 2 The EPC Class1 Gen2 tab is used to set the EPC Class1 Gen2 parameters for the air interface. The parameters set are used if the read/write head performs an Inventory command. All para- meters and the settable values are written in the DTM.
  • Page 34: 7.2.10 Setting The Rssi Filter - Post Read Filter

    RSSI outside of the set limit values are filtered out and not displayed. Ò „ At Post read filter RSSI filter switch on the RSSI filter. Fig. 24: Switching on the RSSI filter Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 35: 7.2.11 Setting Led Indication - Signaling

    Ò Ò „ Set the limit values at Post read filter RSSI filter Lower threshold. Example: all read operations below an RSSI value of -45 dBm are filtered out. Fig. 25: Example – setting the limit value for RSSI 7.2.11 Setting LED indication – Signaling The Signaling tab enables the default settings for the USER LEDs to be edited.
  • Page 36: Testing The Read/Write Head

    Right-click the device in the project tree. Ò „ In the context menu choose Additional functions RFID Test. Fig. 26: Starting the RFID Test Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 37: Start Window - Overview

    7.3.2 Start window – overview The RFID Test window consists of the following elements: Main menu Basic test Tag actions Reader Status Logger Fig. 27: RFID Test – overview of the start window V02.00 | 2020/08...
  • Page 38: Rfid Test - Main Menu

    Resets the window layout. HF diagnosis Opens the window for HF diagnostics. Firmware update Opens the window for the firmware update. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 39: Rfid Test - Basic Test Window

    7.3.4 RFID Test – Basic test window Fig. 29: RFID Test – Basic test window The following functions are available in the Basic test window: Icon Function Description Polling Shows the first tag in the polling memory of the device in the tag list.
  • Page 40: Rfid Test - Tag Actions Window

    The EPC is decremented automatically by 1. Switch on/off access password Switches the password for write or read access on or off. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 41 Example: execute tag actions „ Position tag in detection range of the read/write head. „ Activate the trigger for the read/write head in the main menu. Fig. 31: Main menu – activating trigger „ Basic test window: execute polling command in order to display tag in the tag list. „...
  • Page 42: Rfid Test - Logger Window

    The Logger window displays read/write information and error messages. The list can be cleared via the Delete button. Fig. 35: Messages in the Logger window Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 43: Rfid Test - Reader Status Window

    7.3.7 RFID Test – Reader Status window The Reader Status window displays the following parameters: Ambient temperature: Temperature inside the read/write head PA temperature: Temperature of the power amplifier Transceiver temperature: Temperature of the read/write head chip Transmit power: Effective radiated power (ERP) Reverse power: The power radiated back to the electronics Fig. 36: Messages in the Reader Status window The list can be cleared via the Delete button.
  • Page 44: Querying Device Information With The Dtm

    „ Right-click the device in the project tree. Ò „ Choose Additional functions Identify. Fig. 38: Calling up Identification Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 45 The DTM shows the available information on the device according to the selected access level. Fig. 39: Device information for TN865-Q175L200-H1147 in the Advanced access level V02.00 | 2020/08...
  • Page 46: Operation

    2 (state of the wireless field) Wireless field deactivated Yellow Wireless field activated 3 (errors) No internal error Internal error detected Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 47: Troubleshooting

    Troubleshooting If the device does not work as expected, proceed as follows: „ Exclude environmental disturbances. „ Check the connections of the device for errors. „ Check device for parameterization errors. If the malfunction persists, the device is faulty. In this case, decommission the device and replace it with a new device of the same type.
  • Page 48: Rectifying Errors

    Right-click the device in the project tree. „ Select Diagnosis in the context menu. Fig. 40: Project tree – starting diagnosis Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 49 The diagnosis window opens in the DTM. Fig. 41: DTM – diagnosis Rectifying error messages: „ Click the Reset read/write head button in the RFID Test main menu. „ Select Reset the read/write head in the drop-down menu. The read/write head is reset. Fig. 42: DTM –...
  • Page 50: Maintenance

    Disposal The devices must be disposed of correctly and must not be included in general household garbage. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 51: Technical Data

    Technical Data 13.1 Technical data – TN865… Technical data TN865-Q120… TN865-Q175… Mounting condition Non-flush Non-flush Ambient temperature -25…+50 °C -25…+50 °C Operating voltage 12…24 VDC 12…24 VDC Data transmission Electromagnetic Electromagnetic AC field AC field Operating frequency 865…868 MHz 865…868 MHz Wireless communication and ISO 18000-6C ISO 18000-6C protocol standards EN 302208...
  • Page 52: Technical Data - Tn902

    IP67 MTTF 51 years acc. to SN 29500 51 years acc. to SN 29500 (Ed. 99) (Ed. 99) 40°C 40°C Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 53: Technical Data - Tn840/920

    13.3 Technical data – TN840/920… Technical data TN840/920-Q120… TN840/920-Q175… Mounting condition Non-flush Non-flush Ambient temperature -25…+50 °C -25…+50 °C Operating voltage 12…24 VDC 12…24 VDC Data transmission Electromagnetic Electromagnetic AC field AC field Operating frequency 920…925 MHz 920…925 MHz Wireless communication and ISO 18000-6C ISO 18000-6C protocol standards EPCglobal Gen 2 EPCglobal Gen 2...
  • Page 54: Technical Data - Tn917

    IP67 MTTF 51 years acc. to SN 29500 51 years acc. to SN 29500 (Ed. 99) (Ed. 99) 40°C 40°C Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 55: Technical Data - Tn866

    13.5 Technical data – TN866… Technical data TN866-Q120… TN866-Q175… Mounting condition Non-flush Non-flush Ambient temperature -25…+50 °C -25…+50 °C Operating voltage 12…24 VDC 12…24 VDC Data transmission Electromagnetic Electromagnetic AC field AC field Operating frequency 866…868 MHz 866…868 MHz Wireless communication and ISO 18000-6C ISO 18000-6C protocol standards EPCglobal Gen 2 EPCglobal Gen 2...
  • Page 56: Technical Data - Tn902/915

    IP67 MTTF 51 years acc. to SN 29500 51 years acc. to SN 29500 (Ed. 99) (Ed. 99) 40°C 40°C Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 57: Technical Data - Tn920

    13.7 Technical data – TN920… Technical data TN920-Q120… TN920-Q175… Mounting condition Non-flush Non-flush Ambient temperature -25…+50 °C -25…+50 °C Operating voltage 12…24 VDC 12…24 VDC Data transmission Electromagnetic Electromagnetic AC field AC field Operating frequency 920…926 MHz 920…926 MHz Wireless communication and ISO 18000-6C ISO 18000-6C protocol standards EPCglobal Gen 2 EPCglobal Gen 2...
  • Page 58: Technical Data - Tn921

    IP67 MTTF 51 years acc. to SN 29500 51 years acc. to SN 29500 (Ed. 99) (Ed. 99) 40°C 40°C Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 59: Appendix: Conformity Declarations And Approvals

    14.1 EU Declaration of Conformity Hans Turck GmbH & Co. KG hereby declares that the TN-865-… wireless system complies with directive 2014/53/EU. The complete text of the EU declaration of conformity can be obtained from the following Internet address: www.turck.com.
  • Page 60: Fcc/Ic Digital Device Limitations - Tn902-Q175L200-H1147

    This equipment should be installed and operated with minimum distance 30 cm between the radiator & your body. CAN ICES-3 (A)/NMB-3(A) Use only with listed LPS or class 2 power supply! Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 61 Over 30 subsidiaries and over 60 representations worldwide! 100000797 | 2020/08 100000797 www.turck.com...
