- Page 1 Your Global Automation Partner TN…-Q…L…-H1147 UHF Read/Write Heads Operating Instructions...
- Page 2 Contents Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 3: Table Of Contents
Contents About These Instructions Target groups Explanation of symbols Other documents Naming convention Feedback about these instructions Notes on the Product Product identification Scope of delivery Legal requirements Manufacturer and service For Your Safety Intended use Obvious misuse General safety notes Product Description Device overview 4.1.1... - Page 4 Appendix: Conformity Declarations and Approvals 15.1 EU conformity declaration 15.2 FCC/IC Digital Device Limitations – TN902-Q120L130-H1147 15.3 FCC/IC Digital Device Limitations – TN902-Q175L200-H1147 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 5: About These Instructions
This symbol denotes actions that the user must carry out. RESULT OF ACTION ➥ This symbol denotes the relevant results of actions and procedures. Other documents Besides this document the following material can be found on the Internet at www.turck.com: ■ Data sheet ■ Quick start guide ■... -
Page 6: Naming Convention
If you have any suggestions for improving the design or if some information is missing in the document, please send your suggestions to techdoc@turck.com. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 7: Notes On The Product
Notes on the Product Product identification These instructions apply to the following UHF read/write heads: Type code Operating frequency Region TN865-Q120L130-H1147 865…868 MHz Europe TN902-Q120L130-H1147 902…928 MHz North America (USA, Canada, Mexico) TN840/920-Q120L130- H1147 920.5…924.5 MHz China TN917-Q120L130-H1147 917…920.8 MHz Korea TN866-Q120L130-H1147 866…868 MHz... -
Page 8: Legal Requirements
For overseas inquiries contact your national Turck representative. Hans Turck GmbH & Co. KG Witzlebenstraße 7 45472 Mülheim an der Ruhr Germany Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 9: For Your Safety
The product is designed according to state of the art technology. Residual hazards, however, still exist. Observe the following warnings and safety regulations in order to prevent danger to persons and property. Turck accepts no liability for damage caused by failure to observe these warnings and safety instructions. -
Page 10: General Safety Notes
The radiation of the UHF read/write heads may have an adverse effect on the operation of electrically controlled medical equipment. Keep an additional distance from active radiation sources up to the maximum transmission distance. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 11: Product Description
Product Description The UHF read/write heads have a rectangular design (120 × 130 mm or 175 × 200 mm). The devices are rated to degree of protection IP67 and are contained in an aluminum housing with a plastic front. The power supply to the device and data exchange with the controller are imple- mented via a BL ident®... -
Page 12: Operating Principle
The devices can be fully tested, configured and parameterized from a PC using the specified software tools. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 13: Operating Frequency
4.4.1 Operating frequency The Turck BL ident® UHF system uses nationally specified transmission frequencies for the com- munication between the tags and read/write heads. These national operating frequencies for UHF are the frequency ranges that are individually specified by the national regulation bodies. -
Page 14: Technical Accessories
The following accessories are not supplied with the device: Dimension drawing Type Ident no. Description RH-Q240L280/Q280L640 7030296 Arm bracket for UHF read/write heads 45 ø 6,5 (4x) Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 15: Mounting
Mounting The devices can be mounted in any position. Mount the device with the appropriate fixing accessories. ➤ ➤ The minimum distance between two read/write heads using the same frequency depends on the maximum radiant power and the alignment of the antenna. Fig. -
Page 16: Screw Fastening On A Mounting Plate
Fasten the device with four M5 × 35 cylinder screws on a pre-drilled mounting plate. ➤ ➤ Fig. 5: Screwing the read/write head onto the mounting plate Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 17: Mounting With An Application-Specific Adapter
Mounting with an application-specific adapter Make the adapter according to the following dimension drawings. ➤ ➤ M6 x 8 (2x) 19.5 A - A M5 x 35 (4x) Fig. 6: Dimension drawing for TN…-Q120… M6 x 10 (2x) A - A M5 x 35 (4x) Fig. -
Page 18: Mast/Tube Mounting
Fit the device with the intended mounting aid as shown in the following figure. ➤ ➤ M6 x 8 Fig. 8: Mast/tube mounting Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 19: Mounting With The Rh-Q240L280/Q280L640 Arm Bracket
Mounting with the RH-Q240L280/Q280L640 arm bracket The RH-Q240L280/Q280L640 arm bracket (Ident no. 7030296) is not supplied with the device and must be ordered separately. Fasten the device with two M6 × 12 screws through the fixing holes of the read/write head ➤... -
Page 20: Connection
Pin layout Wiring diagram 1 BN 3 BU – 4 WH Data 2 BK Data Fig. 12: Connection cables …/S2503 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 21: Commissioning
Commissioning The device is operational automatically once the cables are connected and the power supply is switched on. The planning and preparation of an RFID system require different measures, depending on the application. Further information on this is provided in the RFID engineering manual. Operation LEDs The devices are provided with three LEDs for displaying the status of the device. -
Page 22: Setting And Parameterization
RFID cable Ethernet cable e.g. RK4.5T-…-RS4.5T/S2500 e.g. RSSD-RJ45… Fig. 13: Connecting the read/write head with a PC via the TBEN-S2-2RFID-4DXP Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 23: Connecting Read/Write Heads With A Pc Via The Interface Converter
9.1.2 Connecting read/write heads with a PC via the interface converter The following accessories are required to connect read/write heads to a PC: ■ STW-RS485-USB interface converter (Ident no. 7030354) ■ STW-RS485-USB-PS power supply unit (Ident no. 7030355), Accessories are not supplied with the device and must be ordered separately. Connect the read/write head to the interface converter using a suitable connection cable (e.g. -
Page 24: Creating A Project In Pactware
Example: Select “RS485 RFID” to connect the read/write head to the PC via the RS485 ➤ ➤ interface. Fig. 16: Example: Selecting “RS485 RFID” Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... - Page 25 Double-click “RS485 RFID” in the project tree. ➤ ➤ Select the COM port. The COM port to which the device is connected is shown in the device ➤ ➤ manager in the control panel of the PC (COM & LPT). Set the baud rate.
- Page 26 Fig. 20: Establishing a connection The “RFID Test” and "Parameterization” functions can be started from the project tree at “Ad- ➥ ➤ ditional functions”. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 27: Testing The Read/Write Heads
Testing the read/write heads The following functions can be executed via the RFID Test in the DTM: ■ Displaying read data ■ Displaying the protocol of the communication between host or PC and read/write head ■ Logging of the interface communication between host or PC and read/write head ■... -
Page 28: Start Window - Overview
The “RFID Test” window consists of the following elements: ■ Main menu ■ Basic test ■ Tag actions ■ Logger Fig. 22: “RFID Test” – Start window Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 29: Rfid Test" - Main Menu
9.2.3 “RFID Test” – Main menu Fig. 23: “RFID Test” – Main menu The main menu provides the following functions: Icon Function Description Start trigger/ON Starts the trigger for command execution Stop trigger/OFF Closes the trigger for command execution Switch on antenna Switches on the read/write head antenna Switch off antenna Switches off the read/write head antenna. -
Page 30: Rfid Test" - "Basic Test" Window
The queried data is displayed in the tag list. The content of the message can be set via the “Con- figure message content” function. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 31: Rfid Test" - "Tag Actions" Window
9.2.5 “RFID Test” – “Tag Actions” window The functions in the “Tag actions” window are available if a tag is marked in the tag list of the “Basic Test” window. Fig. 25: “RFID Test” – “Tag Actions” window The following functions are available in the “Tag actions” window: Icon Function Description... - Page 32 “Basic Test” window: Execute polling command in order to display tag in the tag list. ➤ ➤ “Basic Test” window: Select tag from the tag list. ➤ ➤ Fig. 27: Select the tag Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
- Page 33 “Tag actions” window: Enter required values and confirm entry with ENTER. ➤ ➤ Fig. 28: Entering the data Execute the required function by clicking the appropriate button (here: “Read”). ➤ ➤ Fig. 29: Execute tag action (example: “Read”) V01.00 | 2018/06...
-
Page 34: Rfid Test" - "Logger" Window
The “Logger” window displays read/write information and error messages. The list can be cleared via the “Delete” button. Fig. 31: Messages in the “Logger” window Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 35: Hf Diagnosis" Window
9.2.7 “HF diagnosis” window The current power level of the read/write head is displayed for each channel in the “HF diagno- sis” window. Fig. 32: “HF diagnosis” window The following functions can be executed in the “HF diagnosis” window: Icon Function Description Start/stop HF diagnostic... -
Page 36: Setting Read/Write Heads Parameters Via The Dtm
Choose “Parameter” “Parameterization” or “Online parameterization” in the context menu. ➤ ➤ Fig. 33: Example: Starting online parameter setting via the context menu Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 37: Main Menu - Overview
9.3.2 Main menu – Overview Fig. 34: Parameterization – Main menu The main menu provides the following functions: Icon Function Description Help on the DTM Starts the DTM help Help on the device Opens the data sheet of the connected read/write head Activating/deactivating Expert mode Opens the drop-down menu to select the access level. -
Page 38: Choosing The Access Level
The current access level is displayed in the top right screen area of the DTM. Fig. 35: Display of the access level Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 39: Basic Setup
9.3.4 “Basic setup” The “Basic Setup” tab is used to set the basic parameters for the read/write heads. All param- eters and the settable values are written in the DTM. 9.3.5 “Antenna” The “Antenna” tab is used to set the antenna parameters for the read/write heads. All param- eters and the settable values are written in the DTM. -
Page 40: Device Information Via The Dtm
Right-click the device in the project tree. ➤ ➤ Choose “Additional functions” Select “Identify”. ➤ ➤ Fig. 36: Calling up “Identify” Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... - Page 41 The DTM shows the available information on the device according to the selected access ➥ ➤ level. Fig. 37: Example: Device information for TN865-Q175L200-H1147 in the “Advanced” access level V01.00 | 2018/06...
-
Page 42: Troubleshooting
Disposal The devices must be disposed of correctly and must not be included in normal household garbage. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 43: Technical Data
Technical Data 14.1 Technical data – TN865… Technical data TN865-Q120… TN865-Q175… Mounting condition Non-flush Non-flush Ambient temperature -25…+50 °C -25…+50 °C Operating voltage 12…24 VDC 12…24 VDC Data transmission Electromagnetic AC field Electromagnetic AC field Operating frequency 865…868 MHz 865…868 MHz Wireless communication and ISO 18000-6C ISO 18000-6C... -
Page 44: Technical Data - Tn902
IP67 MTTF 51 years to SN 29500 (Ed. 99) 51 years to SN 29500 (Ed. 99) 40 °C 40 °C Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 45: Technical Data - Tn840/920
14.3 Technical data – TN840/920… Technical data TN840/920-Q120… TN840/920-Q175… Mounting condition Non-flush Non-flush Ambient temperature -25…+50 °C -25…+50 °C Operating voltage 12…24 VDC 12…24 VDC Data transmission Electromagnetic AC field Electromagnetic AC field Operating frequency 920…925 MHz 920…925 MHz Wireless communication and ISO 18000-6C ISO 18000-6C protocol standards... -
Page 46: Technical Data - Tn917
IP67 MTTF 51 years to SN 29500 (Ed. 99) 51 years to SN 29500 (Ed. 99) 40 °C 40 °C Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 47: Technical Data - Tn866
14.5 Technical data – TN866… Technical data TN866-Q120… TN866-Q175… Mounting condition Non-flush Non-flush Ambient temperature -25…+50 °C -25…+50 °C Operating voltage 12…24 VDC 12…24 VDC Data transmission Electromagnetic AC field Electromagnetic AC field Operating frequency 866…868 MHz 866…868 MHz Wireless communication and ISO 18000-6C ISO 18000-6C protocol standards... -
Page 48: Technical Data - Tn902/915
IP67 MTTF 51 years to SN 29500 (Ed. 99) 51 years to SN 29500 (Ed. 99) 40 °C 40 °C Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 49: Technical Data - Tn920
14.7 Technical data – TN920… Technical data TN920-Q120… TN920-Q175… Mounting condition Non-flush Non-flush Ambient temperature -25…+50 °C -25…+50 °C Operating voltage 12…24 VDC 12…24 VDC Data transmission Electromagnetic AC field Electromagnetic AC field Operating frequency 920…926 MHz 920…926 MHz Wireless communication and ISO 18000-6C ISO 18000-6C protocol standards... -
Page 50: Technical Data - Tn921
IP67 MTTF 51 years to SN 29500 (Ed. 99) 51 years to SN 29500 (Ed. 99) 40 °C 40 °C Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 51: Appendix: Conformity Declarations And Approvals
Appendix: Conformity Declarations and Approvals 15.1 EU conformity declaration Hans Turck GmbH & Co. KG hereby declares that the wireless system type TN865-… complies with directive 2014/53/EC. The complete text of the EU declaration of conformity can be ob- www.turck.com tained from the following Internet address: 15.2... -
Page 52: Fcc/Ic Digital Device Limitations - Tn902-Q175L200-H1147
This equipment should be installed and operated with minimum distance 30 cm between the radiator & your body. CAN ICES-3 (A)/NMB-3(A) Use only with listed LPS or class 2 power supply! Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... - Page 53 V01.00 | 2018/06...
- Page 54 Over 30 subsidiaries and over 60 representations worldwide! 100000797 | 2018/06 *100000797* www.turck.com...
