Control Explanation
Information
i
coming from the graphics card in your computer. See your
graphic card's user guide for instructions on changing the
resolution and refresh rate (vertical frequency).
VESA 1024 x 768 @ 60 Hz (recommended) means that the
resolution is 1024 x 768 and the refresh rate is 60 Hertz.
H. Frequency:
V. Frequency:
Pixel Clock:
Resolution:
Model Number: VLCDS23585-2W
Serial No:
1:EXIT
Image Adjust
1:EXIT
The Image Adjust controls are explained below:
H./V. Position
screen image. You can toggle between Horizontal and Vertical
by pressing button [2]. Horizontal moves the screen image to
the left or to the right. Vertical moves the screen image up and
down.
H. Size
NOTE:
ViewSonic Corporation
displays the timing mode (video signal input)
Information
48.60 KHz
60.00 Hz
65.00 MHz
1024 x 768
www.viewsonic.com
Image Adjust
H./V. Position
H. Size
Fine Tune
Sharpness
2:SELECT
adjusts horizontal and vertical position of the
(Horizontal Size) adjusts the width of the screen image.
Vertical size is automatic with your LCD display.
