Summarization of Contents
Product Description
Compressor Specifications
Details technical specifications for Valeo TM08, TM13, TM15, and TM16 compressors.
Magnetic Clutch Overview
Presents specifications and benefits of the Valeo magnetic clutch for compressor systems.
Compressor Name Plate Identification
Explains the importance of the name plate for compressor identification and smooth operation.
Dimensions TM08
Provides detailed technical drawings and dimensions for the TM08 compressor model.
Dimensions TM13
Provides detailed technical drawings and dimensions for the TM13 compressor model.
Dimensions TM15
Provides detailed technical drawings and dimensions for the TM15 compressor model.
Dimensions TM16
Provides detailed technical drawings and dimensions for the TM16 compressor model.
Exploded View of Components
An exploded diagram illustrating compressor parts with corresponding numbers.
Performance Data TM08
Presents performance data and graphical representations for the TM08 compressor.
Performance Data TM13
Presents performance data and graphical representations for the TM13 compressor.
Performance Data TM15
Presents performance data and graphical representations for the TM15 compressor.
Performance Data TM16
Presents performance data and graphical representations for the TM16 compressor.
Swash Plate System Explanation
Explains the working mechanism of the swash plate type compressor.
General Operational Guidelines
Covers general compressor operation, oil charge, and installation limits.
Handling Instructions
Maintenance Precautions
Guidelines for maintaining a clean and well-ventilated work area for AC service.
Refrigerant Handling Safety
Critical safety warnings and procedures for handling refrigerants to prevent injury.
Compressor Handling and Removal
Safe practices for handling compressors and detailed steps for their removal.
Oil Return and Handling Procedures
Instructions for oil return, oil specification, quantity, and proper handling.
Oil Contamination and Check
Methods for identifying oil contamination and performing oil checks.
Component Replacement Oil Charge
Specifies oil quantities needed when replacing AC system components.
Compressor and Clutch Running-in
Procedures for running-in the compressor and magnetic clutch after repairs.
Leak Testing and Compressor Storage
Steps for leak testing repaired compressors and guidelines for temporary storage.
Refrigerant Charging and Leak Check
Procedures for safely charging refrigerant and performing initial system leak checks.
Installation Position and Precautions
Correct installation positioning and essential precautions for compressor mounting.
Piping Connection Precautions
Guidelines for correctly connecting piping and hoses, including O-ring application.
Troubleshooting Guide
Compressor Troubleshooting Tree
A diagnostic tree to help identify compressor malfunctions based on symptoms.
Insufficient Cooling Capacity
Troubleshooting steps for diagnosing and resolving insufficient cooling performance.
Compressor Intermittent Operation
Addresses issues related to the compressor running intermittently and potential causes.
Abnormal Noise and Smoke Issues
Diagnosing and resolving abnormal noise from the compressor and smoke-related problems.
A/C Cycle Diagnosis by Gauge Pressure
Procedure for diagnosing A/C system issues by measuring suction and discharge pressures.
Service Procedures - Magnetic Clutch
Magnetic Clutch Removal
Step-by-step instructions for removing the magnetic clutch assembly from the compressor.
Magnetic Clutch Inspection
Guidelines for inspecting the armature, pulley assembly, and field coil.
Magnetic Clutch Installation
Detailed steps for correctly installing the magnetic clutch components.
Clutch Clearance Adjustment
Procedure for checking and adjusting the magnetic clutch clearance using shims.
Service Procedures - Shaft Seal Assembly
Shaft Seal Assembly Removal
Steps for removing the shaft seal assembly from the compressor.
Shaft Seal Inspection and Installation
Procedures for inspecting and correctly installing a new shaft seal.
Service Procedures - Cylinder Heads
Cylinder Heads Disassembly
Instructions for disassembling the front and rear cylinder heads.
Cylinder Heads Inspection
Guidance on inspecting cylinder heads and valve plates for damage or blockages.
Rear Cylinder Head Reassembly
Steps for reassembling the rear cylinder head and associated components.
Front Cylinder Head Reassembly
Steps for reassembling the front cylinder head and final checks.
Service Tools
Magnetic Clutch Service Tools
List of specialized tools required for magnetic clutch disassembly and assembly.
Compressor and Inspection Tools
Tools for compressor disassembly, testing, and inspection procedures.
