コンポ−ネント
BKM-101C
コンポ−ネント
BKM-102
Installation Manual for Dealers
特約店様用取付説明書
Monitors Available for BKM-101C and 102
BKM-101C
PVM-14M2U/14M2E/14M2A/14M4U/14M4E/14M4J/14M4A/14M4B
PVM-20M2U/20M2E/20M4U/20M4E/20M4J/20M4A
PVM-20S1WU/20S1WE/20S1WA(英文のみ/English only
BVM-14M4E/20M4E
Monitors Available for BKM-102
BKM-102
に対応するモニター
BVM-14M4DE/14M4DJ/20M4DE
WARNING!
When installing the kit, to prevent shock hazard,
do the following:
• Turn off the whole system connected to the
monitor.
• Unplug all cables, the power cable etc., con-
nected to the monitor.
取り付けの際は、感電を防ぐため、次の項目を必
ず守ってください。
モニターと接続しているシステムの電源をすべ
て切ってください。
モニターに接続されている電源ケーブルなど、
すべてのケーブルを外してください。
 1997 by Sony Corporation
SDI
<VIDEO>
キット
SDI
<AUDIO>
キット
102
および
に対応するモニター
3-859-887-06 (1)
)
