Summarization of Contents
EMC, Safety & Environmental
Isolation Standards
Electrical isolation specifications for different models.
Safety Standards
Safety test voltage, impulse voltage, insulation resistance, leakage current.
Environmental Specifications
Environmental conditions like cold heat, vibration, shock.
Measurement
Measurement Error Output Handling
Controller output behavior during measurement errors.
Display Configuration and Indicators
Details on display parameters and LED indicators.
Control States
Automatic Control Mode
Description of the automatic control function.
Control Off Mode
Description of the control off state.
Bumpless Manual Control
Manual control with bumpless transfer.
Control Actions
ON/OFF Control Action
Details on ON/OFF control with hysteresis.
Neutral Zone ON/OFF Control
Neutral zone ON/OFF control description.
PID Control Action
Description of PID control parameters.
Ramp and Soak
Power Down Resume Modes
Strategies for resuming after power failure.
Alarms
Alarm Types
Various types of alarm conditions.
Alarm Functions
Functions for acknowledging and delaying alarms.
Menus
Set Point Menu Parameters
Parameters related to set points (SPLL, SPHL, nSP).
Input Menu Parameters
Parameters for sensor input configuration (SEnS, ISCL, ISch, etc.).
Output Menu Parameters
Parameters for configuring controller outputs (OPCF, o1cF, OP1, OP2, OP3).
Alarm 1 Menu Parameters
Parameters for Alarm 1 configuration (A1tY, A1Fn, A1Lo, etc.).
Regulator Menu Parameters
Parameters for regulator control (Cont, Func, hEst, Auto, Pb, Int, dEr).
Modbus
Modbus Function 3 Read
Frame structure for reading multiple holding registers.
Modbus Function 6 Write
Frame structure for writing a single holding register.
Modbus Exception Reply
Structure of Modbus exception responses.
Modbus Queries
Modbus PV Variable
Description of the Process Variable (PV) Modbus query.
Modbus Control Output Variable
Description of the Control Output (coP) Modbus query.
Modbus Set Point Variable
Description of the Set Point (SP) Modbus query.
Modbus SPLL Variable
Description of the Set Point Low Limit (SPLL) query.
Modbus Sensor Select Variable
Description of the Sensor Select (SEnS) Modbus query.
Modbus Key Configuration Variable
Description of the Key configuration (Key) Modbus variable.
