Summary of Contents for Ideal Boilers Atlantic 30
- Page 1 combination boilers INSTALLATION & SERVICING INSTRUCTIONS For User Guide see reverse of book UIN 223483 A01 August 2019 THESE INSTRUCTIONS TO BE RETAINED BY USER THESE INSTRUCTIONS TO BE RETAINED BY USER...
- Page 2 ERP DATA MODEL SYMBOL UNITS Condensing Boiler Low Temperature Boiler B1 Boiler Cogeneration Space Heater Equipped with a Supplementary Heater Combination Heater Nominal Heat Output for Space Heating Full Load 24.3 24.3 24.3 Part Load Auxiliary Electricity Consumption Full Load 0.042 0.032 0.029...
-
Page 3: Control Of Water Temperature
PRODUCT FICHE ATLANTIC COMBI COMBINATION BOILER Ideal Boilers ERP DATA SYMBOL UNITS MODEL Condensing boiler Seasonal Space heating efficiency class Rated heat output ƞ Seasonal space heating energy efficiency Annual energy consumption Sound power level, indoors Water heating energy efficiency class... - Page 4 Installation and Servicing...
- Page 5 To restart the boiler press the restart button. The boiler will repeat the ignition sequence if a heat demand is present. DOCUMENT AMENDMENTS Relevant Installation changes implemented in this book from Mod Level ......A01 (August 19) Ideal Boilers reserve the right to vary specification without notice Installation and Servicing...
- Page 6 Installation and Servicing...
-
Page 7: Table Of Contents
CONTENTS GENERAL ..............10 3.11 Burner Replacement ..........42 Introduction ..............10 3.12 Ignition Electrode / Ionisation Detection Probe Operation ..............10 Replacement .............. 43 Safe Handling ............. 10 3.13 Spark Generator Replacement ........44 Optional Extra Kits ............. 10 3.14 Gas Control Valve Replacement ........ - Page 8 SECTION 1 - GENERAL Table 1 - General Data ATLANTIC COMBI Gas supply 2H - G20 - 20mbar Gas Supply Connection 15mm copper compression Injector Size 4.15 4.65 Inlet Connection 15mm copper tail Outlet Connection 15mm copper compression Flow Connection 22mm copper compression Return Connection 22mm copper compression...
- Page 9 SECTION 1 - GENERAL ATLANTIC COMBI Natural Gas only Boiler size G.C. Appliance No. (Benchmark No.) 47-349-81 47-349-82 47-349-83 Destination Country: GB, IE For GB, to comply with Building Regulations Part L1 (Part 6 in Scotland) the boiler should be fitted in accordance with the manufacturer’s instructions.
-
Page 10: General
SECTION 1 - GENERAL The boiler features a comprehensive diagnostic system which GENERAL gives detailed information on the boiler status when operating, and performance of key components to aid commissioning and fault finding. 1.1 INTRODUCTION The Atlantic combi range of boilers are wall mounted, full 1.3 SAFE HANDLING sequence, automatic spark ignition, low water content, fanned flue, high efficiency, condensing, combination gas boilers. -
Page 11: Safety
Installation and Servicing Instructions or as otherwise In both cases, details of essential features of cupboard / recommended by Ideal Boilers in writing. If in doubt please compartment design, including airing cupboard installation, are to enquire. -
Page 12: Gas Supply
SECTION 1 - GENERAL 1.8 GAS SUPPLY 3. Minimum acceptable spacing from the terminal to obstructions and ventilation openings are specified in The local gas supplier should be consulted, at the installation Table 4. planning stage, in order to establish the availability of an adequate 4. -
Page 13: Air Supply
SECTION 1 - GENERAL 1.10 AIR SUPPLY It is NOT necessary to have a purpose-provided air vent in the room or internal space in which the boiler is installed. Neither is it necessary to ventilate a cupboard or compartment in which the boiler is installed, due to the low surface temperatures of the boiler casing during operation;... -
Page 14: Boiler Dimensions, Services & Clearances
SECTION 1 - GENERAL 1.15 BOILER DIMENSIONS, SERVICES & CLEARANCES Side and Rear Flue The boiler connections are made on the boiler bulkhead fittings. Refer to Section 2.18. a. Provided that the flue hole is cut accurately, e.g. with a core drill, the flue can be installed from inside the building where wall The following minimum clearances must be maintained thicknesses do not exceed 600mm. -
Page 15: System Requirements - Central Heating
SECTION 1 - GENERAL 1.16 SYSTEM REQUIREMENTS - Central Heating Notes a. The method of filling, refilling, topping up or flushing sealed primary hot water circuits from the mains via a temporary hose connection is only allowed if acceptable to the local water authority. -
Page 16: System Balancing
The application of any other treatment to this 3. In hard water areas, treatment to prevent lime scale may be necessary - product may render the guarantee of Ideal Boilers however the use of artificially softened water is NOT permitted. -
Page 17: Installation
SECTION 2 - INSTALLATION INSTALLATION Note that item numbers are linked to the spares list 2.1 BOILER ASSEMBLY - Exploded View CH RETURN VALVE RETURN THERMISTOR CONDENSATE OUTLET CH FLOW VALVE WATER PRESSURE SWITCH CONNECTION DHW INLET & OUTLET PRESSURE GAUGE PUMP HEAD GAS COCK IGNITION ELECTRODE/... -
Page 18: Unpacking
SECTION 2 - INSTALLATION 2.2 UNPACKING The boiler is supplied fully assembled in Pack A. A telescopic or non-telescopic flue assembly for rear or side flue outlet in Pack B is suppled as a separate order. Unpack and check the contents. IMPORTANT. -
Page 19: Unpacking Cont'd
SECTION 2 - INSTALLATION 2.3 UNPACKING CONT’D Note. This flue system incorporates a removable flue outlet nose that utilises a push fit location system. This enables the installation of deflector, high level or balcony outlet flue kits without the removal of the whole ‘B’ pack terminal. The appliance must not be operated without the desired outlet nose correctly fitted in place. -
Page 20: Wall Mounting Template
SECTION 2 - INSTALLATION 2.5 WALL MOUNTING TEMPLATE Extended centre line 1 5 5 The wall mounting template is located on the internal protective (2 0 0 ) “A” - See Diagram in packaging. The template shows the position of the fixing and rear Frame 1 flue centre holes for a standard installation Care MUST be taken to ensure the correct holes are drilled. -
Page 21: Determining The Flue Length And Flue Packs Required
(1000mm long) B Pack cut 75mm * If wall thickness is <126 and >102.5, contact Ideal Boilers. For Flue lengths between 658 & 708 use a Horizontal Flue Terminal (1000mm long) B Pack, cut 75mm off the end of the terminal section of the telescopic flue only. -
Page 22: Determining The Flue Length And Flue Packs Required, Cont'd
INSTALLATION 2.10 DETERMINING THE FLUE LENGTH AND FLUE PACKS REQUIRED, CONT’D FIGURE 1 Edge of turret Edge of turret Edge of turret to outside face of wall plus to outside face of wall plus to outside face of wall plus 44mm = ue length 44mm = ue length 44mm = ue length... -
Page 23: Cutting & Setting The Flue Length
INSTALLATION 2.11 CUTTING & SETTING THE FLUE LENGTH TELESCOPIC FLUES TELESCOPIC FLUE B PACK SHOULD ONLY BE ADJUSTED FOR USE WITHIN ITS SPECIFIED RANGE AND MUST NOT BE CUT HORIZONTAL FLUE TERMINAL (1000MM LONG) B PACK (TELESCOPIC) MUST ONLY BE CUT IF REQUIRED FLUE LENGTHS ARE BETWEEN 602 &... -
Page 24: Installing The Flue
INSTALLATION 2.12 INSTALLING THE FLUE FITTING FLUE THROUGH THE WALL 1. Measure wall thickness and add 14mm. 2. Measure from the outer terminal lip towards the end of outer flue, place a small location mark at the dimension acquired at point 1. 3. -
Page 25: Fitting The Optional Roof Flue Kit (Flat Or Pitched)
INSTALLATION 2.13 FITTING THE OPTIONAL ROOF FLUE KIT (Flat or Pitched) Note. A flat or pitched roof flashing plate (not supplied) is required before proceeding with the installation of this kit. This kit is suitable for both flat and pitched roof terminations, using a concentric flue to run vertically from the top of the boiler and terminating above roof level. -
Page 26: Flue Terminal Position
INSTALLATION 2.15 FLUE TERMINAL POSITION The terminal should be positioned so that products of combustion can safely disperse at all times. Pluming may occur at the termination so, where possible, terminal positions where this could cause a nuisance should be avoided. 3 0 0 m m Minimum dimensions are shown below m i n... -
Page 27: Assembling The Roof Flue Kit
INSTALLATION 2.16 ASSEMBLING THE ROOF FLUE KIT Determine the correct height that the flue should terminate above the roof. If after calculating or measuring the overall flue height from the top of the boiler, it is necessary to cut both pipes of assembly A, then ensure they are cut equally leaving the inner flue tube longer than the outer air tube as supplied. -
Page 28: Condensate Drain
SECTION 2 - INSTALLATION 2.17 CONDENSATE DRAIN to drain by gravity to a suitable internal foul water discharge point such as an internal soil and vent stack or kitchen or bathroom waste pipe etc. See Figs 1 and 2. Condensate Pump Condensate Where gravity discharge to an internal termination is not physically Drain... - Page 29 SECTION 2 - INSTALLATION CONDENSATE DRAIN - CONT’D..Figure 3 - Connection of a Condensate Pump Typical Figure 4 - Connection of condensate Drainage Pipe to Method (see manufacturer’s detailed instructions) External Soil & Vent Stack Boiler Water/weather Visible air break with 75mm proof insulation Boiler...
-
Page 30: Connections & Filling
SECTION 2 - INSTALLATION 2.18 CONNECTIONS & FILLING NOTES. Ensure all boss blanking plugs are removed before connecting hardware. Each valve must be fitted to the correct boss as shown in the picture. Ensure each union is fitted with fibre seals provided. Do not subject any of the isolating valves to heat as the seals may be damaged. -
Page 31: Electrical Connections
SECTION 2 - INSTALLATION 2.19 ELECTRICAL CONNECTIONS WARNING. This appliance MUST be earthed. Wiring should be 3 core PVC insulated cable, not less than 0.75mm (24 x 0.2mm), and to BS 6500 Table 16. For IE A mains supply of 230Vac ~ 50 Hz is required. reference should be made to the current ETCI rules for electrical The fuse rating should be 3A. -
Page 32: Wiring Diagram
SECTION 2 - INSTALLATION 2.22 WIRING DIAGRAM Installation and Servicing... -
Page 33: Commissioning And Testing
SECTION 2 - INSTALLATION 2.23 COMMISSIONING AND TESTING A. Electrical Installation B. Gas Installation 1. Checks to ensure electrical safety should be carried out by a 1. The whole of the gas installation, including the meter, competent person. should be inspected and tested for tightness and purged in accordance with the recommendations of IGEM/UP/1B. -
Page 34: Initial Lighting
SECTION 2 - INSTALLATION 2.24 INITIAL LIGHTING Legend Domestic Hot Water Temperature Knob Central Heating Temperature Knob Mode Knob Boiler Status Display Preheat Indicator Burner ‘on’ Indicator G. Preheat On Off button Restart button Central Heating Economy Setting Pressure Gauge CH Flow Isolating Valve M. -
Page 35: General Checks
SECTION 2 - INSTALLATION 2.25 GENERAL CHECKS Make the following checks for correct operation in: WATER CIRCULATION SYSTEM DOMESTIC HOT WATER (DHW) MODE 1. Fully open all DHW taps in turn and ensure that water flows 1. With the system COLD, check that the initial pressure is freely from them. -
Page 36: Restart Procedure
SECTION 2 - INSTALLATION 2.26 RESTART PROCEDURE To restart the boiler press the restart button. Restart button 2.27 HANDING OVER After completing the installation and commissioning of the system the installer should hand over to the householder by the following actions: 1. -
Page 37: Servicing
SECTION 3 - SERVICING SERVICING 3.1 SERVICING For the very latest copy of literature for specification & maintenance practices, visit our website www.idealboilers.com, where you will be able to download the relevant information. WARNING. Always turn OFF the gas supply at the gas service cock, and switch OFF and disconnect the electricity supply to the appliance before servicing. -
Page 38: Boiler Upper & Lower Front Panel Removal / Replacement
SECTION 3 - SERVICING 3.2 BOILER UPPER & LOWER FRONT PANEL REMOVAL / REPLACEMENT REMOVAL REPLACEMENT 1. Lift the lower front panel access flap. 4. Hook the upper panel onto the top retaining clips. 2. Unscrew the fixing screw, close the access flap to retain the 5. -
Page 39: Burner Removal And Cleaning
SECTION 3 - SERVICING 3.4 BURNER REMOVAL AND CLEANING 1. Ensure the sump is fully drained 2. Undo the two screws and remove the sump cover retaining the lower flue manifold. 3. Lift the manifold to clear the bottom sealing gasket and remove manifold. -
Page 40: Cleaning The Heat Exchanger
SECTION 3 - SERVICING 3.6 CLEANING THE HEAT EXCHANGER Note: Ensure the condensate trap/siphon Ignition/Flame Electrode is fully drained before cleaning. Refer to Section 3.19. 1. Remove the ignition/flame detection electrode. Refer to Section 3.12. 2. It is advisable to replace the sump cover prior to the water flush process. -
Page 41: Replacement Of Components
SECTION 3 - SERVICING 3.8 REPLACEMENT OF COMPONENTS GENERAL IMPORTANT. When replacing ANY component Ensure all gas valve connections are gas tight with a gas soundness check up to the gas control valve. 1. Isolate the electricity supply. When work is complete, the front panels must be correctly 2. -
Page 42: Burner Injector Replacement
SECTION 3 - SERVICING 3.10 BURNER INJECTOR REPLACEMENT 1. Refer to Section 3.8. 2. Disconnect the electrical leads from the fan. 3. Remove the clip from the gas valve to venturi pipe and ease the pipe upwards, rotate and ease ... -
Page 43: Ignition Electrode / Ionisation Detection Probe Replacement
SECTION 3 - SERVICING 3.12 IGNITION ELECTRODE / IONISATION DETECTION PROBE REPLACEMENT 1. Refer to Section 3.8. 2. Remove the burner. Refer to Section 3.11. 3. Unplug the ignition lead from the electrode. 4. Remove the earth lead from the ignition electrode/ionisation detection probe. -
Page 44: Spark Generator Replacement
SECTION 3 - SERVICING 3.13 SPARK GENERATOR REPLACEMENT 1. Refer to Section 3.8. 2. Disconnect the leads from the spark generator. 3. Pull the spark generator to unclip from the mounting bracket. 4. Fit the new spark generator and re- assemble in reverse order ensuring Spark Generator ... -
Page 45: Diverter Valve Actuator Replacement
SECTION 3 - SERVICING 3.15 DIVERTER VALVE ACTUATOR REPLACEMENT To remove the motor: Diverter Valve Motor 1. Refer to Section 3.8. 2. Remove the condensate trap/siphon. Refer to Section 3.16. 3. Remove the wiring connector by inserting a terminal screwdriver to release the latch, then withdraw the connector. -
Page 46: Main Pcb Replacement
SECTION 3 - SERVICING 3.17 MAIN PCB REPLACEMENT * Note. that production boiler PCB’s are factory pre-set to operate for boiler range and output, but when ordering PCB as a spare Note. Fit the earth strap provided with the PCB to your wrist and secure to a suitable earth on the boiler chassis. -
Page 47: Replacing The Mechanical Timer
SECTION 3 - SERVICING 3.18 REPLACING THE MECHANICAL TIMER 1. Refer to Section 3.8. 2. Swing the boiler lower front panel into the service position. Refer to Section 3.2. 3. Remove the 4 fixing screws. 4. Disconnect the 4 push on connectors. 5. -
Page 48: Dhw Flow Turbine Sensor Replacement
SECTION 3 - SERVICING 3.20 DHW FLOW TURBINE SENSOR REPLACEMENT 1. Refer to Section 3.8. 2. Drain the DHW system. Refer to Section 3.19. 3. Pull off the electrical connection. 4. Using a suitable tool, lift and remove the retaining clip. ... -
Page 49: Safety Relief Valve Replacement
SECTION 3 - SERVICING 3.22 SAFETY RELIEF VALVE REPLACEMENT 1. Refer to Section 3.8. 2. Drain the boiler. Refer to Section 3.19. 3. Pull out and remove the clip (positioned safety valve. 4. Undo the safety valve pipe compression fitting positioned outside the boiler casing. -
Page 50: Diverter Valve Body Assembly Replacement
SECTION 3 - SERVICING 3.24 DIVERTER VALVE BODY ASSEMBLY REPLACEMENT To remove the valve body assembly: 15. Lift the manifold assembly and remove from boiler. Refer to Section 3.8. 16. Twist and remove the DHW manifold. 2. Drain the boiler. Refer to Section 3.19. 17. -
Page 51: Water Pressure Switch Replacement
SECTION 3 - SERVICING 3.27 CH WATER PRESSURE SWITCH REPLACEMENT 1. Refer to Section 3.8. 2. Drain the boiler. Refer to Section 3.19. 3. Pull off the two electrical connections. 4. Using a suitable tool, pull out the metal retaining clip. 5. -
Page 52: Flow Thermistor
SECTION 3 - SERVICING 3.29 FLOW THERMISTOR 1. Refer to Section 3.8. 2. Drain down the boiler. Refer to Section 3.19. 3. Unplug the electrical lead. 4. Unscrew the thermistor (to facilitate removal a 13mm socket spanner should be used). 5. -
Page 53: Heat Engine Renewal
SECTION 3 - SERVICING 3.31 HEAT ENGINE RENEWAL Refer also to Section 2.1 - ‘Boiler Exploded View’ IMPORTANT - Before starting the removal procedure, protect the gas and electrical controls with a waterproof sheet or plastic bag. 1. Refer to Section 3.8. 2. -
Page 54: Expansion Vessel Recharging & Replacement
SECTION 3 - SERVICING 3.32 EXPANSION VESSEL RECHARGING & REPLACEMENT RECHARGING 1. Refer to Section 3.8. Recharge Point 2. Remove the charge point cover. 3. Recharge the tank pressure to 0.75 bar. 4. Re-assemble in reverse order 5. Check operation of the boiler. Refer to Sections 2.24 &... -
Page 55: Fault Finding
SECTION 4 - FAULT FINDING FAULT FINDING 4.1 FAULT FINDING CHART MAIN MENU GO TO SECTION 4.2 - ‘L1’ FLOW TEMPERATURE OVERHEAT LOCKOUT GO TO SECTION 4.3 - ‘L2’ IGNITION LOCKOUT 5 RESETS WITHIN 15 MINS - ‘LC’ TURN POWER OFF AND ON GO TO SECTION 4.5 - ‘L6’... -
Page 56: L1' - Flow Temperature Overheat Lockout
SECTION 4 - FAULT FINDING 4.2 ‘L1’ - FLOW TEMPERATURE OVERHEAT LOCKOUT Is the Boiler and CH System filled with water and all Fill and vent the system and open all isolation and radiator valves open? isolation valves, then restart boiler Is the Flow/Return Differential across the Boiler in Check that the Pump is rotating freely. -
Page 57: Lc' - 5 Resets Within 15 Mins
SECTION 4 - FAULT FINDING 4.4 ‘LC’ - 5 RESETS WITHIN 15 MINS Turn power off and on 4.5 ‘L6’ - FALSE FLAME LOCKOUT Check condition of ignitor and spark generator. Replace if required. Restart the boiler, does Boiler Work OK? Check routing and integrity of internal boiler wiring is OK. -
Page 58: F2 Or Fn Or Ln' - Flame Loss
SECTION 4 - FAULT FINDING 4.7 ‘F2 OR FN OR LN’ - FLAME LOSS Does the boiler ignite for a short Is the Gas Pressure available at Check gas supply and time and then extinguish? the Boiler Inlet (18 mbar)? rectify fault Check wiring from gas Is 24Vdc supply available at the... -
Page 59: L4 Or F4' - Flow Thermistor Fault
SECTION 4 - FAULT FINDING 4.9 ‘L4 OR F4’ - FLOW THERMISTOR FAULT Securely connect the wiring to the Flow Is the wiring securely connected to the Flow Thermistor Thermistor (located in the top of the Heat Exchanger?) Disconnect the wiring from the Flow Thermistor Check the resistance using a suitable multimeter connected Fit a new Thermistor across the Thermistor’s terminal pins. -
Page 60: F6 - Outside Sensor Fault
SECTION 4 - FAULT FINDING 4.11 F6 - OUTSIDE SENSOR FAULT Securely connect the wiring at both the Is the wiring securely connected at both the boiler and boiler and Outside Sensor Outside Sensor? Disconnect the wires to the outside sensor. Check the resistance using a suitable multimeter Fit a new Outside Sensor connected across the Outside Sensor’s terminal pins. -
Page 61: No Ch Operation But Hw Works Ok
SECTION 4 - FAULT FINDING 4.15 NO CH OPERATION BUT HW WORKS OK Is the mode knob in the Winter position? Move the mode knob to the Winter position Are the Timer and the Room Thermostat switched on? Switch the Timer and Room Thermostat On Are the Radiator Valves Open? Open the Radiator Valves There is no Voltage from the Timer/Room Stat. -
Page 62: No Hw But Ch On
SECTION 4 - FAULT FINDING 4.16 NO HW BUT CH ON Is hot and cold pipework crossed? Does the display show “dH” when a tap is on? Adjust flow rates to achieve 35º Are the flow rates correct as per Section 1.16. temp rise and check filter fitted in turbine is not blocked with debris. -
Page 63: Spare Parts
When replacing any part on this appliance use only spare parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Boilers. Failure to do so could affect safety or performance of this appliance. - Page 64 SECTION 5 - SPARE PARTS Installation and Servicing...
- Page 65 Benchmark Commissioning & Warranty Validation Service Record It is a requirement that the boiler is installed and commissioned to the manufacturers’ instructions and the data fields on the commissioning checklist completed in full. To instigate the boiler warranty the boiler needs to be registered with the manufacturer within one month of the installation.
- Page 66 GAS BOILER SYSTEM COMMISSIONING CHECKLIST & WARRANTY VALIDATION RECORD Address: Boiler make and model: Boiler serial number: Commissioned by (PRINT NAME): Gas Safe registration number: Company name: Telephone number: Company email: Company address: Commissioning date: Heating and hot water system complies with the appropriate Building Regulations? Optional: Building Regulations Notification Number (if applicable): Time, temperature control and boiler interlock provided for central heating and hot water Boiler Plus requirements (tick the appropriate box(s))
- Page 67 SERVICE & INTERIM BOILER WORK RECORD It is recommended that your boiler and heating system are regularly serviced and maintained, in line with manufacturers’ instructions, and that the appropriate service / interim work record is completed. Service provider When completing a service record (as below), please ensure you have carried out the service as described in the manufacturers’ instructions. Always use the manufacturers’...
- Page 68 SERVICE & INTERIM BOILER WORK RECORD It is recommended that your boiler and heating system are regularly serviced and maintained, in line with manufacturers’ instructions, and that the appropriate service / interim work record is completed. Service provider When completing a service record (as below), please ensure you have carried out the service as described in the manufacturers’ instructions. Always use the manufacturers specified spare parts.
-
Page 69: Flue & Integrity Checks
FLUE & INTEGRITY CHECKS FLOWCHART FOR CO LEVEL AND COMBUSTION RATIO CHECK ON COMMISSIONING A CONDENSING BOILER Important Preliminary Information on Checks The air gas ratio valve is factory-set and must not be adjusted DURING COMMISSIONING. If the boiler requires conversion to operate with a different gas family (e.g. conversion from natural gas to LPG) sepa- rate guidance is provided with the conversion kit supplied and this must be followed. - Page 70 Start Set Boiler to Maximum Gas Rate Carry Out Flue Integrity Check Using Analyser In accordance with boiler instructions, Insert analyser probe into air inlet test point (where available) and allow set boiler to operate at maximum rate readings to stabilise. (full load condition).
- Page 71 NOTES Installation and Servicing...
- Page 72 Ideal Boilers provides after-sales assistance and Technical advice forAtlantic combi boilers Ideal Technical Helpline: 01482 498663 Ideal Boilers P.O. Box 103, National Avenue, Kingston Upon Hull, HU5 4JN We reserve the right to change the specifications without prior notice. Consumers’ statutory rights are not affected.
- Page 73 combination boilers USER GUIDE For Installation Guide see reverse of book UIN 223483 A01 August 2019 THESE INSTRUCTIONS TO BE RETAINED BY USER...
- Page 74 Benchmark Commissioning Checklist. You can check your installer by calling Gas Safe Register direct on 0800 4085500. Ideal Boilers is a member of the Benchmark scheme and fully supports the aims of the programme. Benchmark has been introduced to improve the standards of installation and commissioning of central heating systems in the UK and to encourage the regular servicing of all central heating systems to ensure safety and efficiency.
-
Page 75: Boiler Operation
BOILER OPERATION Legend A. Domestic Hot Water Temperature Knob B. Central Heating Temperature Knob C. Mode Knob D. Boiler Status Display E. Preheat Indicator F. Burner ‘on’ Indicator G. Preheat On Off button H. Restart button J. Central Heating Economy Setting K. -
Page 76: Efficient Heating System Operation
3. SYSTEM WATER PRESSURE EFFICIENT HEATING SYSTEM OPERATION The system pressure gauge (K - see The boiler is a high efficiency, condensing appliance which will page 3) indicates the central heating automatically adjust its output to match the demand for heat. system pressure. -
Page 77: General Information
GENERAL INFORMATION MECHANICAL 24 HOUR TIMER BOILER PUMP Operating Mode Indicator The boiler pump will operate briefly as a self-check once every 24 hours, regardless of system demand. Permanently o Permanently on Timer Control MINIMUM CLEARANCES Clearance of 165mm (6 ”) above, 100mm (4”) below, 2.5mm ( ”) at the sides and 450mm (17... -
Page 78: Points For The Boiler User
POINTS FOR THE BOILER USER Note. In line with our current warranty policy we would ask that you check through the following guide to identify any problems external to the boiler prior to requesting a service engineers visit. Should the problem be found to be other than with the appliance we reserve the right to levy a charge for the visit, or for any pre-arranged visit where access is not gained by the engineer. -
Page 79: Normal Operation Display Codes
NORMAL OPERATION DISPLAY CODES DESCRIPTION DISPLAY CODE ON BOILER The boiler is in standby operation awaiting either a central heating call or hot water demand. The boiler has a call for central heating but the appliance has reached the desired temperature set on the boiler. -
Page 80: Fault Codes
FAULT CODES DESCRIPTION ACTION DISPLAY CODE ON BOILER Low Water Pressure Check system water pressure is between 1 & 1.5bar on the system pressure gauge. To re-pressurise the system see Section 3. If the boiler still fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period.
