installation and
servicing
icos
Your Ideal installation and servicing guide
For details of document amendments, refer to page 3
HE12, HE15, HE18, HE24
For users guide see reverse of book
When replacing any part on this appliance, use only spare parts that you can be
assured conform to the safety and performance specification that we require. Do not
use reconditioned or copy parts that have not been clearly authorised by Ideal Boilers.
September 2005
UIN 200 212 A10
For the very latest copy of literature for specification purposes please visit our website
www.idealboilers.com where you will be able to download the relevant information in pdf format.
ENGINEERED FOR PEACE OF MIND
