  • Page 1 07/2013 Mod: 350/GXS Production code: 15354C1R02IHL...
  • Page 2 Professional slicer CE SERVICE CENTRE AUTHORISED DEALER Operating and Maintenance Manual...
  • Page 3 INTRODUCTION  This manual has been re-presented to provide the Client with all the information on the machine and its safety regulations, and also the use and maintenance instructions which permit using the machine in the best way and maintaining its efficiency throughout time. ...
  • Page 4 CHAP. 5 - MACHINE USE page 19 CHAP. 1 - RECEIVING THE MACHINE - OPERATIONAL CHECK - LOADING AND CUTTING THE PRODUCT - SHARPENING THE BLADE 1.1 - PACKAGE CHAP. 6 - ROUTINE CLEANING page 22 The slicer is shipped in a package which consists of (Fig. n°1): cardboard box, - GENERALITIES wooden pallets and protective nylon.
  • Page 5 turn the package!! When transporting it make sure that it is firmly held by the four corners (keeping it parallel to the floor Do not expose the package to humidity or rain (Fig. n°4). CHAP. 2 - INSTALLATION Fig. n°4 WARNING! All operations must be carried out by specialized personnel (Fig.

  • Page 6: Electrical Connection

    2.3 - ELECTRICAL CONNECTION 2.2 - POSITIONING Check that the data reported on the Position the pallet, with the slicer, on a technical-part number plate (Fig. n°18), flat surface and take off (a) the sharpe- the delivery documents and the order, ner from the slicer (Fig.
  • Page 7 the position of two of the three phase 2.4.1 - Single-phase 230 V. tension selection wires (black, gray or brown) in the plug. Fig. n°20 OUTPUT DIAGRAM 2.3.5 - Electrical connection modification Unless otherwise specified, the slicers are equipped with 400 V. three-phase connection.

  • Page 8: Preliminary Check

     The slicer must only be used by 2.5 - PRELIMINARY CHECK trained personnel who know the Before testing make sure the goods safety norms contained in this manual holder plate is well-blocked, after which perfectly. test functioning with the following ...

  • Page 9: Construction Features

     Do not pull the slicer or the feeding LEGEND: cable (Fig. n°29) to unplug it. Sharpener handgrip Blade protection  Regularly check the state of the fee- Sharpener Base ding cable; a worn out cable or in any case not intact represents a serious Thickness gauge plane Extractable pin electrical danger.

  • Page 10: Safety Devices Installed On The Machine

    4.2 - SAFETY DEVICES INSTALLED ON THE MACHINE - A relay in the control circuit, that re- quires the machine to start up again 4.2.1 - Mechanical safety in case of an accidental loss of electri- As far as mechanical safety is concerned, the slicer described in this manual city (Fig.

  • Page 11: Operational Check

    CHAP. 5 - MACHINE USE 5.1 - OPERATIONAL CHECK For the 1° use follow these instructions: check that installation has been car- ried out correctly as in chapter 2; check that the plate is well fastened with the lock handgrip (Fig. n°35 ref.1);...

  • Page 12: Loading And Cutting The Product

    5.2 - LOADING AND CUTTING THE PRODUCT cutting effort increases (chapter 5.3). WARNING: The goods to be cut are loaded on the plate only with the graduated handgrip at “0” and the motor stopped, being careful with the blade and the 5.3 - SHARPENING THE BLADE points.
  • Page 13 ders and the blade (chapter 6.2.3); with warm water, the equipped 9. once the operation is finished, detergent or neutral detergent (pH 7) replace the sharpening device in its Fig. n°47. original position, doing the procedure in reverse. Fig. n°47 6.2.2 - Cleaning the blade, the bladeguard and the ring Fig.
  • Page 14 6.2.3 - Cleaning the sliceguard CHAP. 7 - MAINTENANCE (Fig. n°51) To remove the sliceguard simply grasp 7.1 - GENERALITIES the handgrip (1) and pull up so that the Before carrying out any maintenance operations it is necessary to: two pins unhook (2), and then extract a) disconnect the feed plug from the electrical network to completely isolate the sliceguard.

  • Page 15: Out Of Service

    CHAP. 8 - DISMANTLING 8.1 - OUT OF SERVICE If for some reason it is decided to put the machine out of service, make sure that it cannot be used by anyone: detach or cut the electrical connections. 8.2 - WEEE Waste of Electric and Electronic Equipment Directive 2002/95/EC, 2002/96/EC and 2003/108/EC on the restriction of the use of certain hazardous substances in electrical and electronic equipment, and waste electrical and electronic equipment.
