Summarization of Contents
Outer Panels
Outer Panel and Terminal Cover Removal
Remove top panel, terminal cover screws, and unfasten terminal cover hooks for access.
Outdoor Fan / Fan Motor
Electrical Box Cover and Fan Motor Removal
Remove electrical box cover, disconnect fan motor lead wire, and remove the outdoor fan by its nut.
Electrical Box
Electrical Box Wiring and Connector Disconnection
Remove wire fixture, disconnect terminal board wires, and disconnect connector [S20] and clamp.
Thermistor ASSY / PCB
Thermistor Assembly and Terminal Disconnection
Remove thermistor ASSY, earth/ground screw, and disconnect 3 terminals for power supply.
Partition Plate / Sound Blankets
Partition Plate and Sound Blanket Removal
Remove partition plate and outer sound blanket by unscrewing, lifting, and pulling.
Inner Sound Blanket Removal
Remove the inner sound blanket.
Electronic Expansion Valve Coil / Four Way Valve
Four Way Valve Coil Removal
Remove the screw and then the four way valve coil.
Expansion Valve Coil and Wiring Disconnection
Pull out expansion valve coil, remove terminal cover, bushing, and disconnect compressor lead wires.
Compressor
Electronic Expansion Valve Coil Removal
Pull out the electronic expansion valve coil.
Compressor Disconnection and Removal
Remove terminal cover, bushing, disconnect wires, heat pipes, and remove compressor.
