  • Page 1 O P E R A T I N G I N S T R U C T I O N S BEDIENUNGSANLEITUNG D A S STEREO INTEGRATED AMPLIFIER AX-4103 DISCRETE AMPLIFIER STAGE VOLUME TONE BALANCE REMOTE SENSOR STANDBY TUNER TAPE...
  • Page 2: Introduction

    Introduction UNPACKING AND INSTALLATION Congratulations on Your Purchase! FOR U.S.A FCC INFORMATION Your new high fidelity amplifier is designed to deliver This equipment has been tested and found to maximum enjoyment and years of trouble free service. comply with the limits for a Class B digital device, Please take a few moments to read this manual pursuant to Part 15 of the FCC Rules.
  • Page 3: Read This Before Operating Your Unit

    READ THIS BEFORE OPERATING YOUR UNIT FOR U.S.A AND CANADA ........120 V FOR OTHER COUNTRIES ......115 V/230 V FOR YOUR SAFETY FOR YOUR SAFETY Units shipped to the U.S.A and Canada are designed Units shipped to countries other than the above for operation on 120 V AC only.
  • Page 4: Table Of Contents

    CONTENTS Introduction UNPACKING AND INSTALLATION ....................... 2 READ THIS BEFORE OPERATING YOUR UNIT................... 3 System Connections ............................5 Front Panel & System Remote Controls ....................7 REMOTE CONTROL OPERATION RANGE ................... 9 LOADING BATTERIES ..........................9 Operations LISTENING TO A PROGRAM SOURCE ....................10 RECORDING ............................
  • Page 5: System Connections

    System Connections Do not plug the AC input cord into the wall AC outlet until all connections are completed. Be sure to connect the white RCA pin cord to the L(left) and the red RCA pin cord to the R(right) jacks when making audio connections.
  • Page 6 Standby mode — switched AC outlet off System Power-on mode — switched AC outlet on Tape deck control cord Tuner, etc. • Connect this jack to the DIGI LINK jack of the external Sherwood component that uses the DIGI LINK II or III remote control system.
  • Page 7: Front Panel & System Remote Controls

    PHONES SPEAKER System Remote Controls • You can remotely control not only this amplifier but also Sherwood compatible components bearing the DIGI LINK II or III logo. • For system remote control operation, first make the DIGI LINK connections. POWER NUMERIC BUTTONS(1~0) For selecting preset stations in tuner mode.
  • Page 8 SPEAKER A, B SELECTOR BUTTONS Each time this button is pressed, the brightness of all These buttons allow you to select various combinations fluorescent displays of Sherwood components of speakers as follows: connected by the DIGI LINK III changes together as...
  • Page 9: Remote Control Operation Range

    FLUORESCENT DISPLAY REMOTE CONTROL OPERATION RANGE LOADING BATTERIES Remove the cover. D A S STEREO INTEGRATED AMPLIFIER AX-4103 DISCRETE AMPLIFIER STAGE VOLUME TONE BALANCE REMOTE SENSOR STANDBY TUNING/PRESET TUNER TAPE TV/AUX TONE DIRECT POWER PHONES SPEAKER Load two batteries matching the polarity.
  • Page 10: Operations

    Operations LISTENING TO A PROGRAM SOURCE Select the desired input source. Before operation Enter the standby mode. STANDBY TUNER TAPE TV/AUX POWER The STANDBY indicator lights up. This means that the amplifier is not disconnected from the AC mains and POWER DISC REPEAT...
  • Page 11 At the desired tone mode, adjust the tone Adjusting the tone(bass and treble) as desired. Enter the tone mode. POWER POWER DISC REPEAT INTRO A<>B DISC REPEAT INTRO A<>B TONE DECK SEL. DECK DECK SEL. DECK INPUT SELECTOR SLEEP DISPLAY INPUT SELECTOR SLEEP DISPLAY...
  • Page 12: Recording

    While operating the sleep timer, “SLEEP” lights up. When the sleep time is selected, all display panels of In the display OFF mode, pressing any button will Sherwood components connected by the DIGI LINK restore the display ON mode. III are dimly lit.
  • Page 13: Troubleshooting Guide

    Troubleshooting Guide If a fault occurs, run through the table below before taking your amplifier for repair. If the fault persists, attempt to solve it by switching the amplifier off and on again. If this fails to resolve the situation, consult your dealer.
  • Page 14 O P E R A T I N G I N S T R U C T I O N S AX-4103 STEREO INTEGRATED AMPLIFIER INTEGRIERTER STEREO VOR-/ENDVERSTARKER 5707-21055-001-0...
