NXT -LP 600W/1000W
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NXT-LP 1000W and is the answer not in the manual?

Questions and answers

Related Manuals for P.L.LIGHT SYSTEMS NXT-LP 1000W

Summary of Contents for P.L.LIGHT SYSTEMS NXT-LP 1000W

  • Page 1 NXT -LP 600W/1000W INSTRUCTION MANUAL...

  • Page 3: Table Of Contents

    Table of Contents 1. Introduction 1.1. Used Symbols 2. Product Description 3. Product Information and Specifications 3.1. Dimensions 3.2. Technical Specifications 3.3. Environment 4. Safety Recommendations and Warnings 5. Contents (fig1) 6. Mounting Kit (fig2) 7. Controls, Connections and Indications (fig3) 8.

  • Page 4: Introduction

    1. Introduction Thank you for purchasing the P.L. Light Systems NXT-LP. Please read and under- stand this manually completely before using the product. Only use the product as specified in this manual. 1.1. Used Symbols Warning! A warning indicates severe damage to the user and/or product may occur when a procedure is not carried out as described.

  • Page 5: Product Information And Specifications

    3. Product Information and Specifications 3.1. Dimensions 600W/1000W length 21.25 in (53.98 cm) width 11.00 in (27.94 cm) height 7.50 in (19.05 cm) weight 10.00 lb (4.54 kg) 3.2. Technical Specifications 600W Rated Main Voltage 120V 240V Input Current 5.5A 2.65A Power Factor >0.98...

  • Page 6: Safety Recommendations And Warnings

    4. Safety Recommendations and Warnings Warning! Carefully read the warnings below before using or working with the product! • Always adhere to the local and national building and electrical codes when installing or using the fixture. • This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navi- gation or communication equipment operating between 0.45 - 30 MHz.

  • Page 7: Contents (Fig1)

    5. Contents (fig1) A. NXT-LP fixture 1. Cast aluminum housing with electronic ballast 2. Reflector bracket 3. Lamp holders 4. Alpha reflector 5. Mounting points (2) Eye Bolts B. 6ft 120V Power cord with 15A straight blade plug C. 6ft 240V Power cord with 15A straight blade plug D.

  • Page 8: Mounting Kit (Fig2)

    6. Mounting Kit (fig2) A. (2) S-hooks B. (1) Wire bracket C. (2) Eye bolts 7. Controls, Connections and Indications (fig3) REVISION HISTORY DESCRIPTION DATE APPROVED A. Dimming control knob (adjustable see 9.1) B. Integrated level C. 120V/240V Cord receptacle 1000 1150 8.

  • Page 9: Install Eye Bolts

    8.2. Install Eye Bolts • Thread eye bolts in designated areas (2) and tighten. Note: Dual eyebolts are recommended for leveling purposes. designated eye bolt holes 8.3. Mount Chain & Front Bracket • Cut chain to appropriate length for desired mounting height •...

  • Page 10: Attach Mounting Bracket

    8.5. Attach Mounting Bracket REVISION HISTORY DESCRIPTION DATE APPROVED • Lower front of reflector collar onto mounting bracket hooks • Adjust so that bracket is securely inserted beneath collar 8.6. Level Fixture REVISION HISTORY DESCRIPTION DATE APPROVED NAME DATE Solid Edge DRAWN Mike Ewer 09/21/16...

  • Page 11: Adjusting The Output Of The Lamp Manually

    9.1. Adjusting the Output of the Lamp Manually Note: Adjustment occurs gradually (60 seconds per step) to increase the lifespan of the lamp. • Turn the output control knob to adjust the output of the lamp: - 600W DE: 300/400/500/600/660 Watt - 1000W DE: 600/660/750/825/1000/1150 Watt 10.

  • Page 12: Placement And Replacement Of The Lamp

    10.1. Placement and Replacement of the Lamp Caution! Always wear cotton gloves when touching a lamp to avoid creating a dark spot on the bulb from the oils on your skin. Caution! Only use lamps specified by P.L. Light Systems (see paragraph 3.2). Note: The lamp must be replaced approximately every 10,000 burning hours.

  • Page 13: Placement And Replacement Of The Reflector

    10.2. Placement and Replacement of the Reflector Note: P.L. Light Systems recommends cleaning the reflector once a year (see 10.3) to maintain optimum performance. Depending on the environment and contamination levels the reflector will degrade over time and will eventually need to be replaced.

  • Page 14: Maintenance Cleaning The Reflectors

    10.3. Maintenance Cleaning the Reflectors Regular cleaning of reflectors is essential for optimal lighting performance. Your reflectors need to be cleaned at a minimum every two years, but every year is highly recommended. • Switch off main power source. • Remove the reflector from fixture(see paragraph 10.2.). •...

  • Page 15: Storage And Disposal

    If the product shows any defects within this period and that defect is not due to user error or improper use P.L.Light Systems shall, at its discre- tion, either replace or repair the product using suitable new or reconditioned products or parts.
  • Page 16 pl_light /pllightsystems @pllight /c/pllight /p-l--light-systems P.L. LIGHT SYS TEMS 1.800.263.0213 | www.nxt-lp.com 4800 Hinan Dr., Beamsville, ON, Canada...
