Yamaha FX HO 2012-2018 Instructions

For the best support, please watch our installation video on our website here:

***Note: keep all buckles on port (left) side of ski.

Extra washers should be used as backing washers

inside hull for all rivets.

https://highsurfrescue.com/portfolio/strap-kit/

Download color copy at

https://highsurfrescue.com/resources/

Provided: Straps & Hardware

Needed: Drill, 3/16 Drill Bit & Rivet Gun

#1 – #4 Straps denoted in the order that

they are attached to the ski from bow

(front) to stern (back)

Table of Contents

Need help?

Do you have a question about the FX HO 2017 and is the answer not in the manual?

Page 1 Yamaha FX HO 2012-2018 Instructions For the best support, please watch our installation video on our website here: https://highsurfrescue.com/portfolio/strap-kit/ Download color copy at https://highsurfrescue.com/resources/ ***Note: keep all buckles on port (left) side of ski. Provided: Straps & Hardware Needed: Drill, 3/16 Drill Bit & Rivet Gun Extra washers should be used as backing washers #1 – #4 Straps denoted in the order that inside hull for all rivets. they are attached to the ski from bow (front) to stern (back)
Page 2 STEP #1 STEP #2 Align the #2 strap by placing the strap Hole in #1 strap sandwiches in hatch. over the glove box. Align ends that will be Loosen bolt in photo, slide strap in between riveted with trim on each side. Using strap plastic and align hole with bolt. Re-fasten mark holes where drilling is needed. Drill bolt. Close hatch, with strap dangling, place holes, attach rivets and repeat for opposite bracket parallel with the hatch. Using the side. brackets, mark holes where drilling is needed. Drill holes, attach rivets and repeat for opposite side. STEP #3 STEP #4 Align the # strap (with handle) on the rear Align the #4 strap on the rear of the rear of the front seat. Level bracket, using seat. Using strap, mark holes where bracket mark holes where drilling is drilling is needed. Drill holes, attach rivets needed. Drill holes, attach rivets and and repeat for opposite side. repeat for opposite side.
