NTN K16 Instruction Manual

INSTRUCTION
MANUAL
NTN Bowl Feeder
Type K10/K14/K16/K20

Introduction

Thank you for your purchase of the NTN bowl feeder.
For correct operation of the NTN bowl feeder, read the Instruction Manual carefully before use, and
ensure execution of safe work through correct operation.
Be sure to deliver this Instruction Manual to the end user. Users are requested to keep the Instruction
Manual in a place to facilitate ready reference at any time after reading.

1. Before Use

When the machine is delivered, check
for damage during transport and
missing parts. If any trouble is found,
inform the sales office nearby.
When packaging of the machine and
holding fixture for transport are
attached to the body, be sure to
remove them before use.
Be sure to use NTN controller and
bowl for this machine.
Otherwise, specified performance of
the machine may not be obtained.
Before use
Read this Instruction Manual
thoroughly, and operate the
machine correctly.
Contents
Introduction ................................................... 1
1. Before use .............................................. 1
2. Precaution for safety ............................. 2 - 3
3. Operating principles .............................. 3
4. Names of main component parts .......... 4
5. Dimensional drawing ............................. 5
6. Transportation and installation .............. 6
Wiring and operating methods ............. 7 - 8
7.
8. Inspection and adjustment .................... 8 - 11
9. Troubleshooting..................................... 12
10. Specifications ........................................ 13-15
- 1 -
PMPH001E-f
Page
