Instruction
Manual
NTN
Small Linear Feeder
Type S05/S08
Introduction
Thank you for your purchase of the NTN Linear Feeder.
For correct operation of the machine, read the Instruction Manual carefully before use, and ensure
execution of safe work through correct operation.
Be sure to deliver this Instruction Manual to the end user. The end user is further requested to store the
Instruction Manual carefully in a ready-to-take-out place to facilitate reference at any time after reading.
1.
Before Use
Upon receipt of the machine, check it
for break and missing parts caused
during transportation. If any problem
is found, contact your local
distributor.
Be sure to remove packages of the
machine and the transportation
fixtures, if attached to the main body,
before use.
Be sure to use an NTN controller for
the machine.
If other controllers should be used,
specified performances of the
machine may not be exhibited.
Read the Instruction Manual to
the last before use, and operate
the machine correctly.
CONTENTS
Introduction········································ 1
1. Before Use ···································· 1
2. Precautions for Safety ···················· 2
3. Operating Principle ························ 4
4. Names of Main Component Parts ····· 4
5. Dimensional Drawing ····················· 5
6. Transportation and Installation ········ 6
7. Wiring and Operating Methods ········ 7
8. Inspection and Adjustment ············· 8
9. Troubleshooting ·························· 12
10. Specifications ····························· 14
- 1 -
No. PMPH005E-e
Advertisement
Table of Contents
Related Manuals for NTN K-S05 Series
Summary of Contents for NTN K-S05 Series
-
Page 1: Table Of Contents
Small Linear Feeder Type S05/S08 Introduction Thank you for your purchase of the NTN Linear Feeder. For correct operation of the machine, read the Instruction Manual carefully before use, and ensure execution of safe work through correct operation. Be sure to deliver this Instruction Manual to the end user. The end user is further requested to store the Instruction Manual carefully in a ready-to-take-out place to facilitate reference at any time after reading. -
Page 2: Precautions For Safety
Precautions for Safety This machine is designed and manufactured as a parts feeder based on the concept of trouble-freeness and labor saving. However, you are also highly responsible for safety as a user. Be sure to fully read this Instruction Manual before starting to operate the machine and strictly observe the safety precautions given below. - Page 3 Instruction Manual and other manuals. [2] Avoid use of the NTN linear feeder in such a manner as to spoil safety of the machine. If any sign of change likely to spoil safety, inform NTN of the details of the sign.
-
Page 4: Operating Principle
Operating Principle The chute installed on the upper vibrator is connected to the lower vibrator by means of the leaf spring provided at a certain angle, and they are vibrated with a magnet, so that works on the chute are thrown upward aslant, resulting in little-by-little advancement of the works. -
Page 5: Dimensional Drawing
Dimensional Drawing CAUTION In mounting a chute, be careful of the bolt length. Ensure that the threaded area length protruding from the chute bottom face does not exceed the depth of the screw for chute mounting shown below. If bolts longer than specified should be used, the drive unit will be damaged, so that the machine is put in condition not to fully fulfill its functions. -
Page 6: Transportation And Installation
Transportation and Installation CAUTION The machine is heavy. Transport the machine carefully with care not to cause drop. Transportation If the machine is transported while holding the chute, the chute or leaf spring may be deformed. Be sure to hold the base or the main body. -
Page 7: Wiring And Operating Methods
Wiring and Operating Methods WARNING Ensure that the supply voltage is as specified on the machine nameplate (seal bearing the type, power supply and manufacturer's serial No.) attached to the vibrator body. CAUTION As to settings for controllers such as controllers with selector switches (full wave/half wave, 50/60 Hz, 100 V/200 V, etc.) and frequency variable controllers with F-V curve setting function, adjust the settings to specifications of the main body and power conditions. -
Page 8: Inspection And Adjustment
Leaf spring Amplitude Type/size Part No. <<Upper + Lower>> K-PLS2-35×5 0.7 mm K-PLS2-35×5 0.7 mm Amplitude marking label (Note) When NTN specifies a recommended speed, set the speed adjusting knob of controller at a corresponding recommended graduation. - 8 -... - Page 9 [2] Precautions for attachment/detachment of leaf spring When attaching/detaching the leaf spring, be sure to attach/detach the leaf spring in one leaf spring unit and then proceed to the next unit. Do not loosen all units at one time. a) The required bolt bite depth (Dimension L includes bite depth on the upper vibrator side) shall be 1.5 to 2.1 times as much as the screw diameter (As to S05 and S08, the bolt bite depth shall be 7.5 to 10.5 mm, since M5 screws are used).
- Page 10 The clearance between the magnet and the moving iron core is duly set as shown below before shipping of the main body from NTN. But, it is advisable to narrow the clearance as much as possible within the range not to cause touch of the magnet with the moving iron core during operation of the machine at the maximum amplitude.
- Page 11 (4) Change of power frequency NTN linear feeder is adjusted in conformance with the power frequency applicable to the district where it is to be used or the set frequency on the controller. Accordingly, normal vibrations cannot be attained, if the power frequency being the driving output frequency or the frequency set on the controller is different.
-
Page 12: Troubleshooting
[2] Switching of frequency in controller Conduct setting as described in the following table. For details, refer to the Instruction Manual of the controller. power source frequency In the case of 50Hz In the case of 60Hz Setting of DIP switch by K-EGA57. - Page 13 [3] Interference of cover with vibrator [4] Non-removal of transportation fixtures When the cause cannot be located, inform NTN of the symptom as in detail as possible while referring to those described above to enable quick establishment of countermeasures. - 13 -...
-
Page 14: 10. Specifications
10. Specifications K-S 05 Voltage - drive method (1: 100 V full wave, 2: 200 V full wave) Design change code Main body size Main body type Product No. K-S0511 K-S0512 K-S05A1 K-S05A2 Supply voltage (V) Dissipation current (A) 0.10 0.05 0.10 0.05... - Page 15 K-S 08 2 Voltage - drive method (1: 100 V full wave, 2: 200 V full wave) Design change code Main body size Main body type Product No. K-S0821 K-S0822 Supply voltage (V) Dissipation current (A) Power consumption (VA) Drive method Full wave No.
- Page 16 About NTN Parts Feeder Shipping Warranty Card A shipping warranty card is attached to this product. Be sure to receive the card at the occasion of your purchase of the product. The warranty card assures free repair of the product in accordance with conditions specified in the card.
