NTN K-N25 Series Instruction Manual

INSTRUCTION
MANUAL
NTN Bowl Feeder
Type N25/N32/N40
Introduction
Thank you for your purchase of the NTN bowl feeder.
For correct operation of the NTN bowl feeder, read this Instruction Manual carefully before use, and
ensure execution of safe work through correct operation.
Be sure to deliver this Instruction Manual to the end user. The end user is further requested to store the
Instruction Manual carefully in a ready-to-take-out place to facilitate ready reference at any time after
reading.
1. Before Use
†
When the machine is delivered,
check for damage during transport
and missing parts. If any trouble is
found, inform the sales office nearby.
†
When packaging of the machine and
holding fixture for transport are
attached to the body, be sure to
remove them before use.
†
Be sure to use NTN controller and
bowl for this machine.
Otherwise, specified performance of
the machine may not be obtained.
Before use
Read this Instruction Manual
thoroughly, and operate the
machine correctly.
CONTENTS
Introduction ········································· 1
1. Before Use ···································· 1
2. Precaution for Safety ··················· 2 3
3. Operating Principle ·························· 4
4. Names of Main Component Parts ······· 4
5. Dimensional Drawing ··················· 5 7
6. Transportation and Installation ··········· 8
7. Wiring and Operating Methods ···· 9 10
8. Inspection and Adjustment ········ 10 13
9. Troubleshooting······················ 13 14
10. Specifications ························· 15 18
- 1 -
No. PMPH002E-d
