Visonic RP-610 PG2 Datasheet

RP-610 PG2
Two-way Wireless Repeater
•
PowerG ® two-way Frequency Hopping
Spread Spectrum FHSS-TDMA technology -
provides robustness and reliability closer
than ever to wired
•
Extends the communication range between
the PowerMaster
PowerG transmitters
•
Transmission range is by far greater than
the industry standard
•
Visible signal quality indication shown on
the device
•
Mains powered, with rechargeable 48-hour
backup battery
•
Compact and easy to install
•
Front and back tamper protected
•
LED indications for power failure, activity
and installation performance diagnostics
•
Compatible with PowerMaster systems and
PowerG receivers
, PowerG and PowerMaster are registered trademarks of Visonic Ltd. Other names are the property
of their owners. Visonic reserves the right to change information or specifications without notice.
systems and other
®
RP-610 PG2 extends the communi-
cation range between PowerMaster
alarm systems and other PowerG
transmitters. It receives alarm, status
and control messages from the wireless
devices, and sends these messages to
the control panel.
Specifications:
Power supply:
Back-up battery type: 4.8V, 1300mAh
Battery back-up:
Weight
(including battery):
Operating
temperature:
Operating
environment:
Dimensions:
Certifications:
230VAC, 50Hz/9VAC,
0.35A min
120VAC, 60Hz/9VAC,
0.35A min (USA)
48 hours (rechargeable)
470g (16.5oz)
0°C to 49°C
(32°F to 120°F)
Indoor
161 x 161 x 50mm
(6.44 x 6.44 x 1.75in)
