Visonic MCX-610 Features And Benefits

MCX-610
Wireless Repeater
Features & Benefits
•
Supports both one-way and
two-way keyfobs*, remote
commander and all wireless
PowerCode detectors
•
Compact and easily installed
•
Mains powered with 36 hours
backup battery (rechargeable)
•
Front and back tamper protected
•
LED indications for power failure,
activity and diagnostics of
installations performance
•
Complies with EN and FCC
•
Up to 50 different devices can be
enrolled to the repeater
*Only with partitions versions or newer
and PowerMax are registered trademarks of Visonic Ltd. Other names are the property of their owners.
Visonic reserves the right to change information or specifications without notice.
Designed by: Linor Ankri
Advanced The MCX-610 extends communication
range between the PowerMax systems
and other PowerCode transmitters
including one-way and two-way
keyfobs* and PowerCode detectors.
The MCX-610 receives alarm, status and
control messages from the wireless
devices and repeats these messages
to the control panel.
Specifications
Power supply: 230VAC, 50Hz/9VAC, 0.35A min
120VAC, 60Hz/9VAC, 0.35A min
Battery type:
Battery back-up:
Weight
(including battery):
Operating
temperature:
Operating
environment:
Dimensions:
4.8-Volt 1300mAh
rechargeable
36 hours (rechargeable)
463g (16oz.)
0°C to 49°C
(32°F to 120°F).
Indoor
161 x 161 x 50mm
(6.44 x 6.44 x 1.75in.)
(USA)
