ASCOM REMOTE TESTS UNITS Datasheet page 2

PRODUCT SHEET: REMOTE TEST UNIT
Device Capabilities Ericsson F3607gw (Internal RTU-4GS)
WCDMA bands 850/1900/2100 or 900/1900/2100 MHz
GSM bands 850/900/1800/1900 MHz
GSM/WCDMA voice HR/FR/EFR/AMRHR/AMRFR/AMR-WB
GSM/GPRS/EDGE Multislot Class 10 (GPRS and EDGE)
WCDMA R99/HSPA HSDPA Categories up to 7.2 Mbps (Category 1–8)
HSUPA Categories up to 2.0 Mbps (Category 1, 3, 5)
Testing Capabilities
Voice, incl. SQI and PESQ UL/DL, MoToMo/MoToFix
Video telephony, incl. VTQI
FTP Get / Put, incl. TCP-HS
HTTP, browsing and download
Video streaming / Mobile TV, incl. VSQI, direct access
Video streaming / Mobile TV, incl. VSQI, WAP access
WAP, 1.x and 2.0
PING, ICMP
MMS, end-to-end
SMS, end-to-end
Idle mode (network standby)
Scanning (GSM/WCDMA)*
* More information, see scanning table capabilities
Scanning Capabilities PCTel EX Scanner (External)
Technology GSM and WCDMA (concurrent)
WCDMA bands 2100, 900/2100, or 850/1900 MHz
GSM bands 900/1800 or 850/1900 MHz
WCDMA scanning Top-N Pilot (CPICH), BCH (optional)
GSM scanning RSSI, BSIC, C/I (optional) and BCCH (optional)
Control functionality
Lock on RAT (GSM/WCDMA)
Lock on GSM band
Lock on WCDMA band
EDGE capability control
HS capability control
Preferred voice codec (HR/FR/EFR/AMR-HR/AMR-HR/AMR-WB)
Ascom Network Testing Inc.
1943 Isaac Newton Square
Reston | VA | 20190-5006 | USA
www.ascom.com/tems
Sierra Wireless MC8700 (Internal RTU-4GS)
850/900/1900/2100 MHz
850/900/1800/1900 MHz
N/A
Multislot Class 12 (GPRS and EDGE)
HSDPA Categories up to 21.1 Mbps (Category 14) (Evolved HSPA)
HSUPA Categories up to 5.76 Mbps (Category 6)
Ericsson F3607gw Sierra Wireless
(Internal RTU-4G) MC8700 (Transceiver)
X -
- -
X X
X X
X X
X X
X X
X X
X X
X X
X X
X -
Scanning Receiver Unit F3607gw (External)
GSM and WCDMA (sequential)
850/1900/2100 or 900/1900/2100 MHz
850/900/1800/1900 MHz
Top-N Pilot (CPICH), BCH
RSSI, BSIC
Ericsson F3607gw (Internal RTU-4GS)
X
X
X
X
X
X
General RTU Information:
Operating system: Windows XP Embedded
Input voltage range: 6 ... 36 V DC
Power consumption: RTU with 2 internal measurement devices: 31.1 W
RTU with 3 internal measurement devices: 34.6 W
RTU with 3 internal + 2 external devices: Max 60 W
Dimensions: 50 x 260 x 176 mm
Weight: 2.6 kg
Operating temperature: –30
º
Certifications: CE approval, e13 Mark
* Note: Maximum temperature may be affected by technology and measurement device used.
Sony Ericsson Z750
(MTU 750)
X
-
X
X
X
X
X
X
X
X
X
X
Ericsson F3607gw (Internal RTU-4GS)
GSM and WCDMA (sequential)
850/1900/2100 or 900/1900/2100 MHz
850/900/1800/1900 MHz
Top-N Pilot (CPICH), BCH
RSSI, BSIC
Sierra Wireless MC8700 (Transceiver Test Unit)
X
X
X
X
X
N/A
C ... +60 C*
º
Option GT Express
HSUPA (MTU 750)
-
X
X
X
X
X
X
X
X
X
X
-
