PRODUCT SHEET
Product: TEMS ™ Automatic – Remote Test Unit
The next generation of autonomous test units has
arrived. The RTU contains multiple test devices.
The unit is smaller, more powerful, and more ro-
bust than our previous mobile test units, with
support for up to three embedded measurement
devices. They support voice and data for GSM/
GPRS/EDGE, WCDMA R99, and HSPA, including
AMR-WB.
REMOTE TEST UNITS
TEMS AUTOMATIC
™
Small and durable, the new Remote Test Units can be deployed nearly any-
where. They fit well in taxis, buses, trains, delivery trucks, and even on ships
and ferries. For fixed testing, they can be easily deployed in public areas
such as airports, offices, and shopping centers. It is even possible to stack
RTUs for even more flexibility.
Comprehensive service and network information is collected by the
RTUs. Because they are powerful as well as easily deployed, the RTUs allow
TEMS Automatic to perform a wide range of valuable tasks: benchmarking,
optimization, quality assurance monitoring, and service performance
monitoring are among them.
The RTUs have advanced autonomous operation and are controlled
remotely from the TEMS Automatic back-end server. The timing, location,
and type of testing can be configured in this way. Even software and firm-
ware upgrades can be performed remotely.
The RTU can be configured together with one Transceiver Test Unit
(TTU), which is a small boxed solution containing a Sierra Wireless MC8700
embedded module that is mounted to the RTU itself. An external scanner,
either a Scanning Receiver Unit (SRU), a PC-Tel EX or PC-Tel EX mini (also
mounted on the RTU) is also available.
The RTU itself holds up to three embedded measurement devices
(Ericsson F3607gw and, or Sierra Wireless MC8700), an 8 slot SIM switch, and
a dedicated data upload modem, together with a GPS. The RTU operates
without a fan, which represents an important enhancement, particularly for
in-building deployment as a fixed test unit.
