SERVICE
SAMSUNG R65/P50
If there are the Contents not included in this book, please refer to K-zone Service Manual
SAMSUNG
R65/P50
HABANA
NP-R65xxxx/xxx
NP-P50xxxx/xxx
Manual
FEATURES
1. Simple & Essential Note PC
-. New Intel Napa technology.
-. High Bright Gloss, 4:3 LCD.
-. Convenient Multi-media.
2. High Performance &
Convenient Management function.
-. High-Performance Dual Core
-. Powerful connectivity.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HABANA NP-R65 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung HABANA NP-R65 Series

Summary of Contents for Samsung HABANA NP-R65 Series

  • Page 1 R65/P50 HABANA NP-R65xxxx/xxx NP-P50xxxx/xxx SERVICE Manual FEATURES SAMSUNG R65/P50 1. Simple & Essential Note PC -. New Intel Napa technology. -. High Bright Gloss, 4:3 LCD. -. Convenient Multi-media. 2. High Performance & Convenient Management function. -. High-Performance Dual Core -.

  • Page 2: Table Of Contents

    - This Document can not be used without Samsung's authorization - - Contents - 1. Precautions 1) General After-Sales Service Precautions 2) Safety Precautions 3) Ground 4) Static Electricity Precautions 2. Introduction and Specification 1) Introduction 2) Specification 3) Specification comparison between R50 and R65.
  • Page 3 - This Document can not be used without Samsung's authorization - - Contents - 8. System Block Diagram 1) Block diagram 9. System Wire Diagram 1) R65 Top 2) R65 Bottom 3) P50 Top 4) P50 Bottom 5) LCD 10. Part list...

  • Page 4: Precautions

    - This Document cannot be used without the authorization of Samsung - Precautions 1) General After-Sales Service Precautions (1) Do not let customers repair the product themselves. ☞ There is a danger of injury and the product life time may be shortened.
  • Page 5 - This Document cannot be used without the authorization of Samsung - Precautions 2) Safety Precautions (1) EMI This device has been registered regarding EMI for residential use. It can be used in all areas. (2) Circuit Test (Logic Test) Precautions The LSI and MSI used in this product are semiconductor integrated circuits based on MOS-FET or CMOS.
  • Page 6 - This Document cannot be used without the authorization of Samsung - Precautions 3) Ground The product must be grounded to protect it from static electricity and other dangers. When using a multitap, please use a multitap with a ground terminal only.
  • Page 7 - This Document can not be used without Samsung's authorization - 11. References 1) Safety Notice (1) An electric leakage related safety Electric leakage is the flow of electricity to the ground through electrical wires due to ripped coating or bad insulation.
  • Page 8 - This Document can not be used without Samsung's authorization - 11. References 2) Model Numbering Rule 1. CTO ( Computer Model Numbering System) 11-2...
  • Page 9 - This Document can not be used without Samsung's authorization - 11. References 11-3...
  • Page 10 - This Document can not be used without Samsung's authorization - 11. References 2. Non - CTO ( Computer Model Numbering System) 11-4...
  • Page 11 - This Document can not be used without Samsung's authorization - 11. References 11-5...
  • Page 12 - This Document can not be used without Samsung's authorization - 11. References 3) CPU Code table Code name Samsung CODE L1 cache L2 cache clock speed 0902-001943 667MHz 32KB 1.66GHz T1300 0902-001916 667MHz 32KB 1.66GHz T2300 0902-001939 667MHz 32KB 1.83GHz...
  • Page 13 - This Document can not be used without Samsung's authorization - 11. References 4) Glossary Bad Sector An area on a hard disk or floppy disk that cannot be used to store data, because of a manufacturing defect or accidental damage. A floppy or hard disk saves data in units and the smallest unit of storage on a disk is a sector.
  • Page 14 - This Document can not be used without Samsung's authorization - 11. References Cache Memory High-speed memory with a copy of the most recently used memory data. When the CPU's request for instructions or data can be satisfied from the cache, the CPU can run at full rated speed. Using a part of the hard disk space as cache memory due to small main memory capacity is called disk cache.
  • Page 15 - This Document can not be used without Samsung's authorization - 11. References Device Driver A program stored on the hard drive that tells the operating system how to communicate with an input/output device such as a printer. You may think of it as dedicated software that controls a device such as a printer.
  • Page 16 - This Document can not be used without Samsung's authorization - 11. References EPROM Abbreviation for ‘Erasable Programmable Read Only Memory’. An EPROM differs from a PROM in that a PROM can be written to only once and cannot be erased. IF an EPROM is exposed to ultraviolet light, the data is erased.
  • Page 17 - This Document can not be used without Samsung's authorization - 11. References ALU (Arithmetic-Logic Unit) Abbreviation for ‘Arithmetic Logic Unit’. A part of the CPU. ALU carries out additions, subtractions, multiplications and divisions, as well as logical operations within instructions.
  • Page 18 - This Document can not be used without Samsung's authorization - 11. References Firmware Low-level software that controls the hardware. Firmware is a combination of software and hardware. The name, 'Firmware', is used because it is partly hardware and it is partly software that controls the underlying hardware of the system.
  • Page 19 - This Document can not be used without Samsung's authorization - 11. References Audio Frequency An audio frequency normally audible to humans. Although the audio frequencies may differ depending on individuals and the volume and type of the sound, audio frequencies range roughly from 20 Hz to 20 kHz.
  • Page 20 - This Document can not be used without Samsung's authorization - 11. References Dual Core This refers to a CPU that has dual processing cores within and has been developed by technology that incorporates two or more Intel Pentium-based processing cores within a single processor.
  • Page 21 - This Document can not be used without Samsung's authorization - 11. References 5) Hardware Upgrade All reassembly is done in the reverse order of disassembly. (1) Upgrading the ODD 1. Remove the screws at the bottom of the system.
  • Page 22 - This Document can not be used without Samsung's authorization - 11. References 4. Remove the ODD. 5. ODD Types ODDs that can be used for the R65/P50 include DVD-Combo, CD-ROM, DVD-ROM and Super Multi Drive (Dual Layer). - DVD-Combo Drive...
  • Page 23 - This Document can not be used without Samsung's authorization - 11. References (2) Upgrading the HDD. 1. Remove the HDD compartment cover. 2. Separate the HDD-FPC from the HDD connector on the main board. 3. Separate the HDD from the BRKT-HDD and replace the HDD. (The HDD type is PATA)
  • Page 24 - This Document can not be used without Samsung's authorization - 11. References (3) Replacing the Bluetooth Module 1. Remove the HDD compartment cover. 2. Remove the screw fixing the Bluetooth module. 3. Replace the Bluetooth module (When replacing the module, note the shape of the cable)
  • Page 25 - This Document can not be used without Samsung's authorization - 11. References (4) Replacing the WLAN 1. Remove the screws at the bottom of the system. 2. Press the keyboard hooks downwards and lift the keyboard up. 3. Remove the screws fixing the BRK-KBD.
  • Page 26 - This Document can not be used without Samsung's authorization - 11. References 4. Remove the WLAN Cable-Antenna. 5. Remove the WLAN (Lift the WLAN up sliding the WLAN hook left) 11-20...
  • Page 27 - This Document can not be used without Samsung's authorization - 11. References (5) Upgrading Memory 11-21...
  • Page 28 - This Document can not be used without Samsung's authorization - 11. References 11-22...
  • Page 29 - This Document can not be used without Samsung's authorization - 3. Function 1) Construction of System 3- 1...
  • Page 30 - This Document can not be used without Samsung's authorization - 3. Function 3- 2...
  • Page 31 - This Document can not be used without Samsung's authorization - 3. Function 3- 3...
  • Page 32 - This Document can not be used without Samsung's authorization - 3. Function 3- 4...
  • Page 33 - This Document can not be used without Samsung's authorization - 3. Function 2) Keyboard 3- 5...
  • Page 34 - This Document can not be used without Samsung's authorization - 3. Function 3- 6...
  • Page 35 - This Document can not be used without Samsung's authorization - 3. Function 3) Multi Card Slot 3- 7...
  • Page 36 - This Document can not be used without Samsung's authorization - 3. Function 3- 8...
  • Page 37 - This Document can not be used without Samsung's authorization - 3. Function 3- 9...
  • Page 38 - This Document can not be used without Samsung's authorization - 3. Function 4) PC Card Slot 3- 10...
  • Page 39 - This Document can not be used without Samsung's authorization - 3. Function 5) SPDIF Port 3- 11...
  • Page 40 - This Document can not be used without Samsung's authorization - 3. Function 3- 12...
  • Page 41 - This Document can not be used without Samsung's authorization - 3. Function 3- 13...
  • Page 42 - This Document can not be used without Samsung's authorization - 3. Function 6) ASF and Core Multi Processing. -. ASF (Alert Standard Format) ASF configuration : "CMOS setup -> Advanced -> ASF Configuration." -. Core Multi Processing Core Multi Processing configuration : CMOS Setup -> Advanced -> Core Multi Processing.
  • Page 43 - This Document can not be used without Samsung's authorization - 3. Function 7) Description of Main board (1) TOP Item Item 14 LAN Jack Combo MCH-Calistoga 15 Battery Connector ICH7-M 16 Keyboard Connector GFX Board Conn. (Internal board no-stuff)
  • Page 44 - This Document can not be used without Samsung's authorization - 3. Function (2) BOTTOM Item Docking Connector Micom Azalia Modem TPM Connector (Home model no-stuff) RTC Battery Modem Cable Clock Generator DDR2 SODIMM Memory Connector LAN Controller 10 BIOS...
  • Page 45 - This Document can not be used without Samsung's authorization - 3. Function (3) GFX BOARD BOTTOM Item GFX Chip GFX Connector GDDR3 Memory 3- 17...

  • Page 46: Introduction And Specification

    - This Document can not be used without Samsung's authorization - 2. Introduction and Specification 1) Introduction (1) High Performance Note PC - High Performance Note PC with Intel Pentium M CPU and DDR II Memory. - PCI-Express Graphics (Option) - Wireless LAN (Option), Bluetooth (Option), IrDA.
  • Page 47 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification (5) Home model (R65) and Business model (P50) Special feature of Home model(R65) -. High gloss 15" LCD (Glare) -. Convient Multi Media function . (AVS now & Multi Memory Card Slot [5in1] ) Special feature of Biz model(P50) -.
  • Page 48 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification 2) Specification Processor and Motherboard P50 / R65 Intel Yonah Processor Dual-core T2300(1.66GHz) ~ T2700(2.33GHz) Intel Yonah Processor Single-core T1300(1.66GHz) ~ T1400(1.83GHz) - Intel® Centrino® Mobile Technology with Intel® Core™...
  • Page 49 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification Viewing angle Hor. +60/-60,Ver. +45/-45 Contrast Ratio min.300 (CR) Brightness min.180, typ.200(cd/m2) Factory option Intel GMA 950_DVMT 128MB Graphics Controller NVIDIA GeForce GO 7300_256MB (Physical 64MB + TurboCache 　...
  • Page 50 Average Access Time 13m sec. 4200rpm,5400rpm,7200rpm Speed PATA, SATA(ready) 40GB / 60GB / 80GB / 100GB / 120GB : HGST, Hitachi, Samsung - 40 ~ 120 GB PATA 4200rpm Capacity - 40 ~ 100GB PATA 5400rpm - 60 ~ 80GB PATA 7200rpm...
  • Page 51 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification Weight 190g or less S/W supplied Power DVD Player (5.0), Nero Burning or equivalent S/W Security RPC-II Regional Encoding Super MultiDual Layer 2 Factory Option Module type Fixed 12.7mm Slim...

  • Page 52: Function

    - This Document can not be used without Samsung's authorization - 2. Introduction and Specification Controller Ricoh R5C841 Support 32bit CardBus cards Express Card Slots 1 Express card slot Type USB Type Support USB Type + Express Type 　 I/O Ports...
  • Page 53 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification Dimension 204x48.05x21.4mm Weight 330g (max) Recharge Time 2 hours to 100% with Windows on & off Battery Life over 6.5hour ( Battery mark 4.01) Details of Cell...
  • Page 54 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification 3) Specification comparison between R50 and R65. P50 / R65 533MHz Pentium M 667MHz Pentium M (Yonah) Chipset 945(Calistoga) Memory DDR2 400 / 533MHz DDR2 400 / 533 / 667MHz...
  • Page 55 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification 4) Wireless LAN Specification (1) Wireless LAN Standard (802.11ABG card ) Intel(R) PRO/Wireless LAN 3945ABG Network Connection Device 2- 10...
  • Page 56 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification 2- 11...
  • Page 57 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification 5) Option list BA59-01747A 40GB (4.2KR) 40G,HTS421240H9AT00,S63,H16,C16383,H9.5,W100*L69.85mm 40GB,MHV2040AT,S63,H16,C16383,H9.5,W100*L69.85mm BA59-01639A 40GB (4.2KR) 60G,HTS421260H9AT00,H16,C16383,H9.5,W100*L69.85mm BA59-01746A 60GB (4.2KR) BA59-01819A 60GB (4.2KR) 60GB,MHV2060AT-L,S63,H16,C16383,H9.5,W100*L69.85mm BA59-01702A 80GB (4.2KR) 80G,HTS421280H9AT00,S63,H16,C16383,H9.5,W100*L69.85mm BA59-01820A 80GB (4.2KR) 80GB,MHV2080AT-PL,S63,H16,C16383,H9.5,W100*L69.85mm...
  • Page 58 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification BA96-03003A S-MULTI(D/L) DV-W28EA BA96-03011A Combo DW-224E-C BA96-03010A Combo TS-L462C BA96-02999A DVD-ROM DV-28EN BA96-03059A CD-ROM CD-224E-N MEMORY 1105-001610 512M(SEC) DDR2 533 512MB SO-DIMM M470T6554CZ3-CD5 1105-001609 256M(SEC)
  • Page 59 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification LCD PENEL BA59-01567A XGA-G LTN150XG-L05-G BA59-01749A XGA-G N150X3-L08 BA59-01719A SXGA+G LTN150PG-L03-E BA59-01811A XGA-NG LTN150XG-L05-V BA59-01750A XGA-NG N150X3-L09 BA59-01402A SXGA+NG LTN150PG-L03-V BA59-01751A SXGA+NG N150P5-L02 BATTERY BATTERY(6CELL)
  • Page 60 - This Document can not be used without Samsung's authorization - 2. Introduction and Specification 6) The seperate sale list Docking AA-RD1NX25 / XX X-Docking 2- 15...

  • Page 61: Disassembly And Reassembly

    - This document cannot be used without Samsung's authorization - 4. Disassembly and Reassembly 4-1. Disassembly and Reassembly of R65 Part Figure Description 1. Make sure to separate the AC adapter and battery before disassembling the system. 2. Slide the knob all the way to the end in the direction of the arrows (1) and push the battery in the direction of the arrows (2).
  • Page 62 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 7. When removing the HDD compartment cover, you will find the HDD. Separate the HDD cable and lift up the HDD at an angle of 70º as shown in the figure.
  • Page 63 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 11. Lift up the keyboard, then the Connector Lock and separate the FPC. 12. Remove the 2 screws fixing the Bracket- Support_KBD and remove the bracket.
  • Page 64 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 16. Remove the 2 screws fixing the Hinge and the Top. 17. Lift up the Assy LCD slightly and separate it by pulling it in the direction of the arrow.
  • Page 65 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 20. (1) Separate the Ontop cable from the Main board. (2) Separate the Speaker cable from the Main board. (3) Separate the Touchpad cable from the Main board.
  • Page 66 - This document cannot be used without the authorization of Samsung- 4. Disassembly and Reassembly Part Figure Description 25. (1) Remove the screw fixing the USB board and the Bottom. (2) Remove the screw fixing the 1394 board and the Bottom.
  • Page 67 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 29. Remove the screw fixing the Fan, separate the cable and separate the Fan. * When the Main board is assembled with the bottom, if you want to disassemble the FAN, you should disassemble the another screw.
  • Page 68 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 33. Lift up and separate the PCMCIA socket. Main System 34. The figure shows a picture of the PCB when the part is removed.
  • Page 69 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 3. Slide the latch with your finger to prevent intervention with the LCD Front and insert your finger between the LCD Panel and LCD Front and separate the upper part of the LCD Front.
  • Page 70 - This document cannot be used without the authorization of Samsung- 4. Disassembly and Reassembly Part Figure Description 8. Remove the screws indicated by the arrows in the figure and remove the antenna wire. * Caution Remove the wire keeping an eye on the hook on the LCD Back.
  • Page 71 - This document cannot be used without the authorization the Samsung - 4. Disassembly and Reassembly Part Figure Description 13. Separate the Invertor board connector. 14. Remove the silver tapes in circles 1 and 2. 15. Pull the LCD cable in circle 1 in the direction of the arrow and separate it.
  • Page 72 - This document cannot be used without the authorization of Samsung- 4. Disassembly and Reassembly Part Figure Description 1. To separate the TOP, separate the materials in the yellow circles in the figure. 2. Remove the 2 screws fixing the Speaker-R and the Bottom.
  • Page 73 - This document cannot be used without the authorization of Samsung- 4. Disassembly and Reassembly Part Figure Description 5. Remove the 3 screws fixing the Bracket- Touchpad and the Top. 6. (1) Separate the Touchpad cable from the hook. (2) Separate the FFC cable from the connector.

  • Page 74: Disassembly And Reassembly Of P50

    - This document cannot be used without the authorization of Samsung- 4. Disassembly and Reassembly 4-2. Disassembly and Reassembly of P50 Part Figure Description 1. Make sure to separate the AC adapter and battery before disassembling the system. 2. Slide the knob all the way to the end in the direction of the arrows (1) and push the battery in the direction of the arrows (2) in the figure.
  • Page 75 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 7. When removing the HDD compartment cover, you will find the HDD. Separate the HDD cable and lift up the HDD at an angle of 70º as the figure shows.
  • Page 76 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 11. Lift up the keyboard, then the Connector Lock and separate the FPC. 12. Remove the 2 screws fixing the Bracket- Support_KBD and remove the bracket.
  • Page 77 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 16. Remove the 2 screws fixing the Hinge and the Top. 17. Lift up the Assy LCD slightly and separate it by pulling it in the direction of the arrow.
  • Page 78 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 20. (1) Separate the Ontop cable from the Main board. (2) Separate the Speaker cable and the Mic cable from the Main board.
  • Page 79 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 24. (1) Remove the screw fixing the USB board and the Bottom. (2) Remove the screw fixing the 1394 board and the Bottom.
  • Page 80 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 28. Remove the screw fixing the Fan, separate the cable and separate the Fan. * When the Main board is assembled with the bottom, if you want to disassemble the FAN, you should disassemble the another screw.
  • Page 81 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 32. Lift up and separate the PCMCIA socket. Main System 33. The figure shows the picture of the PCB when the part is removed.
  • Page 82 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 3. Slide the latch with your finger to prevent intervention with the LCD Front and insert your finger between the LCD Panel and LCD Front and separate the upper part of the LCD Front.
  • Page 83 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 8. Remove the screws indicated by the arrows in the figure and remove the antenna wire. *Caution Remove the wire keeping an eye on the hook on the LCD Back.
  • Page 84 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 13. Separate the Invertor board connector. 14. Remove the silver tapes in circles 1 and 2. 15. Pull the LCD cable in circle 1 in the direction of the arrow and separate it.
  • Page 85 - This document cannot be used without the authorization of Samsung- 4. Disassembly and Reassembly Part Figure Description 1. To separate the TOP, separate the materials in the yellow circles in the figure. 2. Remove the 2 screws fixing the Speaker-R and the Bottom.
  • Page 86 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description 5. Remove the screw holding the Fingerprint board. *.The Fingerprint board is optional. 6. Pull the cable connected to the Fingerprint board in the direction of the arrow and separate 7.
  • Page 87 - This document cannot be used without the authorization of Samsung - 4. Disassembly and Reassembly Part Figure Description Name 11. Remove the Bracket-Touchpad and separate the Touchpad board and the IF board. 12. Strip the tape from the Mic cable, pull the Mic in the direction of the arrow and separate it.

  • Page 88: Troubleshooting

    - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 1) General (1) Tools used for repairing the product System Diagnostics Disk MS-DOS Booting Disk System Diagnostics Card Screwdrivers ( ┼ , ━ ) Tweezers Multi-meter...
  • Page 89 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 2) Debugging Flow Chart Start Power on No problem No problem No problem Check there is Check Adapter and Check Ontop board Change Mainboard Power on? any short in the Battery.
  • Page 90 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting No problem No problem Check speaker Change Mainboard Speaker's sound is OK? Check driver status. connection and and check it. speaker cable It is It is problem.
  • Page 91 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting No problem No problem No problem Check 1394IR function Change Mainboard Check driver status. Check 1394IR cable. 1394IR sub is OK? and check it. board. It is...
  • Page 92 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 3) System Diagnosis (1) System Diagnostics Card The Diagnostics Card shows the system operations during the POST (Power On Self Test) in a 2 digit hexadecimal number by connecting the cable to the 10 pin connector below the PCMCIA slot after separating the Top part.
  • Page 93 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting Test the CPU bus-clock frequency Initialize Phoenix Dispatch Manager Warm start shutdown Shadow system BIOS ROM Auto size cache Advanced configuration of chipset registers Load alternate registers with CMOS values...
  • Page 94 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting Re-initialize onboard I/O ports. Configure Mothe board Configurable Devices Initialize BIOS Data Area Enable Non-Maskable Interrupts (NMIs) Initialize Extended BIOS Data Area Test and initialize PS/2 mouse...
  • Page 95 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting (3) Use of Debug card -. Like upper picture, debug card is connected to J628 in Main board. -. Debug code is shown at the viewer in red line.
  • Page 96 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 4) Hardware Troubleshooting For the procedures to disassemble each part, refer to the descriptions of Chapter 4, “Disassembly and Reassembly”. ◆ LCD Related Troubles 1. The screen is dark or the colors of the screen are distorted.
  • Page 97 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting ◆ Main System Troubles 5. The system is not turned off. → Check if the AC adapter LED is lit and if the adapter is properly connected to the system.
  • Page 98 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 6. Although system power is supplied, the system does not boot or immediately turns off after being turned on. → Since this may be a short circuit in the system, disconnect the power immediately, disassemble the system and check if there are any conducting alien objects such as a screw inside.
  • Page 99 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 9. I cannot hear sound through the headphones. → Check if the sound is muted in Windows. → Turn the volume up. → Replace the main board 10.
  • Page 100 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 12. The fingerprint identification function does not work. (Optional) → Check the connection status of the cable between the Touch Pad I/F board and the main board.
  • Page 101 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 14. The Touch Pad does not work or is malfunctioning. → Check the connection status of the Touch Pad FFC. → Check the connection status of the Touch Pad cable.
  • Page 102 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 17. The IrDA or 1394 port does not work. → Check the connection status of the cable between the 1394IR board and the main board. → Replace the 1394IR board.
  • Page 103 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting ◆ When booting up the computer 20. The "Invalid System Disk. Replace the Disk and then press any key" message appears. → This message may appear when the connected USB memory or CD media does not include bootable data.
  • Page 104 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting ◆ Windows / Screen Related Problems 26. The computer hangs while running a program. → If the running program causes an error: In Windows XP, press the <Ctrl>, <Alt> and <Del> key combination, select the application program and click on End Task in the Applications tab of the [Windows Task Manager] window.
  • Page 105 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting ◆ Fingerprint Related Problems (Optional) 32. Test the computer with the supplied "ChkSensor2kUSB_2_2" program. Run the test program and the following window appears. Test Program ChkSensor2kUS B_2_2 If you click the Test button, the test result is displayed in the window as follows.
  • Page 106 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 5) Device Settings Related Software Diagnosis (1) Check if the drivers of each of the devices are properly installed. That is, check if there are any yellow exclamation marks in the Device Manager.
  • Page 107 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting (2) Check the device driver version and check if it is conflicting with another driver. If the driver is not properly installed, install a new driver.
  • Page 108 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting Click on the SRS Control Panel in the Control Panel and check if the SRS function works normally. If all audio drivers and programs are properly installed, the following window will appear.
  • Page 109 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting If there is an improperly installed driver or program the following warning message appears. (4) HDD and ODD Related Problems For an HDD, check if the HDD operates in Ultra DMA Mode 5 by selecting the Primary IDE Channel in the Control Panel as follows.
  • Page 110 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting Check if the HDD and ODD models are properly displayed. If not, check the BIOS SETUP or replace the FPC or drive, if necessary. 5- 23...
  • Page 111 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting (5) Other Problems Press each corresponding button and check its operation. The following figure illustrates the operation of the volume control button. The drivers and application software are listed in the following table.
  • Page 112 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting Ricoh R5C841 MS, SD XPMCE/XPPRO/XPHOME/WIN2K- Driver KOR/ENG/FRE/GER/CHS/CHT/TAI/JPN/UK/SPN/RUS/POR/SIN-MS_SD_MMC_xD XPPRO/XPHOME/WIN2K-KOR/ENG/FRE/CHS/CHT/JPN/UK/SPN/GER/RUS/POR- TPM Driver v.1.70.0154.00 Application ITEM Revision XPMCE/XPPRO/XPHOME-KOR/ENG/FRE/GER/CHS/CHT/TAI/UK/SPN/RUS/POR- Samsung Command Center 1.0.24.0N NoAD XPMCE/XPPRO/XPHOME-KOR-6.0.0.34(6.34.2.11) XPMCE/XPPRO/XPTabletPCEd/XPHOME/WIN2K/WIN98/WIN98SE/WINME- VirusDefinition KOR/ENG/FRE/GER/CHS/CHT/TAI/JPN/UK/SPN/RUS/POR/SIN-05.07.18 Napster XPMCE/XPPRO/XPHOME/WIN2K-UK/ENG-2.5.1.8...
  • Page 113 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting Norton AntiVirus 2005 XPMCE/XPPRO/XPHOME/WIN2K-CHT-11.0.2 Norton AntiVirus 2005 XPMCE/XPPRO/XPHOME/WIN2K-SPN-11.0.1 Acrobat Reader XPHOME/XPPRO/WIN2K/XPMCE-KOR-6.0.1[S] Acrobat Reader XPHOME/XPMCE/XPPRO/WIN2K-ENG/UK/RUS-6.0.1[S] Acrobat Reader XPMCE/XPPRO/XPHOME/WIN2K-FRE-6.0.1[S]+ Acrobat Reader XPHOME/XPMCE/XPPRO/WIN2K-GER-6.0.1[S] Acrobat Reader XPHOME/XPMCE/XPPRO/WIN2K-CHS-6.0.1[S] Acrobat Reader XPHOME/XPMCE/XPPRO/WIN2K-CHT-6.0.1[S] Acrobat Reader XPHOME/XPMCE/XPPRO/WIN2K-SPN-6.0.1[S]...
  • Page 114 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 6) CPU Fan Control Problems Item Mode Design Guideline DC 2.5V Middle1 DC 3.0V FAN Operating Voltage Middle2 DC 3.5V High1 DC 4.0V High2 DC 4.5V >...
  • Page 115 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 7) Battery Use Time Check the following check lists for systems where the battery use time is too short to diagnose problems. (1) Check the battery Check if the battery is out of order referring to the Battery check program distributed to Service Centers and the 'Battery Check Manual' included in the 'Note-PC A/S Guide'.
  • Page 116 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 5- 29...
  • Page 117 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 5- 30...
  • Page 118 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting 3. Battery Capacity Table 4. Battery Check Program 5- 31...
  • Page 119 - This document cannot be used without the authorization of Samsung - 5. Troubleshooting (2) Check the battery use environment 1. Generally, the battery usage time in advertisements by notebook manufacturers refers to the maximum battery use time. Since the system specifications and the usage environment may differ, the user's battery usage time may differ from the advertisement even if there is no problem with the system.

  • Page 120: Exploded View

    - This Document can not be used without Samsung's authorization - 6. Exploded View 2) P50 Exploded View 2-1. Ass'y System (P50)

  • Page 121: Exploded View Of R65

    - This Document can not be used without Samsung's authorization - 6. Exploded View 2-2. Ass'y LCD (P50)

  • Page 122: Exploded View Of P50

    - This Document can not be used without Samsung's authorization - 6. Exploded View 2-3. Ass'y Partlist (P50) NP-P50CV03/CHN Part Code Part Name & Specification Q'ty SA/SNA Note BA97-02500A ASSY MECHA-LCD;HABANA,BIZ,-,-,- BA75-01721B UNIT-HOUSING_BACK;HABANA,SEC,PC/GF,W272* BA42-00151A ANTENNA-MAIN;SS-03-03-069,Habana,2.4to6G BA42-00152A ANTENNA-AUX;SS-03-03-070,Habana,2.4to6GH 6001-001570 SCREW-MACHINE;CH,+,-,M2,L4,ZPC(BLK),SWRC BA59-01811A LCD PANEL-15XGA;LTN150XG-L05-V,15XGA,N/G...
  • Page 123 - This Document can not be used without Samsung's authorization - 6. Exploded View NP-P50CV03/CHN Part Code Part Name & Specification Q'ty SA/SNA Note BA92-04028A ASSY ETC-1394IR-BOARD;HABANA,1394IR-BOAR 6001-001570 SCREW-MACHINE;CH,+,-,M2,L4,ZPC(BLK),SWRC BA39-00543A WIRE HARNESS-SIO;HABANA,wire,DA-1571,8PI BA39-00530A WIRE HARNESS-SIO;HABANA,Wire,UL1571,8PIN BA39-00540A WIRE HARNESS-USB;HABANA,wire,DA-1571,10P BA39-00533A WIRE HARNESS-USB;HABANA,Wire,UL1571,10PI BA39-00541A WIRE HARNESS-1394_IR;HABANA,wire,DA-1571...
  • Page 124 - This Document can not be used without Samsung's authorization - 6. Exploded View 2-4. LCD (P50)
  • Page 125 - This Document can not be used without Samsung's authorization - 6. Exploded View...
  • Page 126 - This Document can not be used without Samsung's authorization - 6. Exploded View 2-5. LCD Partlist (P50) NP-P50CV03/CHN Part Code Part Name & Specification Q'ty SA/SNA Note BA81-02319B HOUSING-LCD15_BACK;HABANA,W272*L329.8*T1 BA81-02332A KNOB-LATCH;HABANA,ABS,W6.8*L143.58mm,PLA BA61-00631A SPRING ETC-KNOB_LCD;AQUILLA,STS304,T0.25 BA81-02320A BRACKET-LCD_UPPER;HABANA,SUS304,W18.6*L3 6001-001570 SCREW-MACHINE;CH,+,-,M2,L4,ZPC(BLK),SWRC BA81-02409A INSULATOR-PROTECT_BACK;HABANA,PET,W316*L...
  • Page 127 - This Document can not be used without Samsung's authorization - 6. Exploded View 2-6. TOP (P50)
  • Page 128 - This Document can not be used without Samsung's authorization - 6. Exploded View...
  • Page 129 - This Document can not be used without Samsung's authorization - 6. Exploded View 2-7. TOP Partlist (P50) NP-P50CV03/CHN Part Code Part Name & Specification Q'ty SA/SNA Note BA81-02314A HOUSING-TOP_B;HABANA,PC/GF,W269.67*L325. BA81-01782A TAPE-TOP_PLATE;FIRENZE,POLYESTER,W188.0* BA81-02313A BRACKET-TOP_PLATE;HABANA,SUS304,W37.85*L BA81-02308A LENS-INDICATOR_POWER;HABANA,PC,W13.7*L37 BA81-00773A KEYBOARD-LOCK;NEON,POM,W17.0*L18.6*H2.8, BA81-02310A KNOB-TOUCHPAD;HABANA,PC/ABS,W29.8*L74.0* BA81-02358A COVER-DC;HABANA,PC/ABS,L14*W15*T1.0mm,NT...
  • Page 130 - This Document can not be used without Samsung's authorization - 6. Exploded View 2-8. Bottom (P50) 6-11...
  • Page 131 - This Document can not be used without Samsung's authorization - 6. Exploded View 6-12...
  • Page 132 - This Document can not be used without Samsung's authorization - 6. Exploded View 2-9. Bottom Partlist (P50) NP-P50CV03/CHN Part Code Part Name & Specification Q'ty SA/SNA Note BA81-02295A HOUSING-BOTTOM;HABANA,PC/GF,W296.97*L325 BA81-02227A KNOB-BATTERY_L;SEDONA,PC+ABS,T1.0mm,BLAC BA81-02228A KNOB-BATTERY_R;SEDONA,PC+ABS,T1.0mm,BLAC BA81-02298A LINK-BATTERY_L;HABANA,POM,W8.5*L26.4*H3. BA81-02299A LINK-BATTERY_R;HABANA,POM,W8.5*H4.0*L26. BA81-02328A LENS-IRDA;HABANA,PC,W5.54*L13.54*H3.73mm BA81-02300A COVER-DUMMY_5IN1;HABANA,PC,W5.92*L41.39*...
  • Page 133 - This Document can not be used without Samsung's authorization - 6. Exploded View 3) ODD 3-1. ODD 6-14...
  • Page 134 - This Document can not be used without Samsung's authorization - 6. Exploded View 3-2. ODD Partlist NP-P50CV03/CHN Part Code Part Name & Specification Q'ty SA/SNA Note BA59-01624A DVD-SUPERMULTI;DV-W28EA,8X,130ms,EIDE,2M BA81-02262A BRACKET-ODD;SEDONA,STS304 1/2H,W20*L8.7* 6001-001532 SCREW-MACHINE;CH,+,M2,L3,ZPC(BLK),SWRCH1 BA81-02253C UNIT-BEZEL_SUPERMULTI;SEDONA,PC+ABS,W15. BA81-01761A LENS-ODD;FIRENZE,PC,W2.1*L7.3*T0.6mm,CLE BA81-02231C BEZEL-SUPERMULTI;SEDONA,PC+ABS,W15.2*L12 BA81-02232A KNOB-DVDCOMBO;SEDONA,PC+ABS,-,BLACK,-,-,...
  • Page 135 - This Document can not be used without Samsung's authorization - 6. Exploded View NP-P50CV03/CHN Part Code Part Name & Specification Q'ty SA/SNA Note 1205-002807 IC-SWITCH;R5538D001-TR-F,QFN,20P,4x4mm,P 1205-002813 IC-CODEC;AD1986AJSTZ_R0.2,LQFP,48P,7x7mm 1209-001531 IC-TEMP. TRANSDUCER;EMC6N300,SSOP,24P,8. 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 2007-000972 R-CHIP;5.1ohm,5%,1/4W,TP,3216 2007-002910 R-CHIP;30.1Kohm,1%,1/10W,TP,1608 2203-001201 C-CER,CHIP;0.0070nF,0.5pF,50V,NP0,1005 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005...
  • Page 136 - This Document can not be used without Samsung's authorization - 6. Exploded View NP-P50CV03/CHN Part Code Part Name & Specification Q'ty SA/SNA Note 6001-001420 SCREW-INCH MACH;CH,+,UNC4-40,L4,NI PLT,S BA39-00531A WIRE HARNESS-MDC;HABANA,wire,DA-1571,2PI BA39-00534A WIRE HARNESS;TC05D37,AWG28,UL 1061,2PIN, BA39-00537A WIRE HARNESS-MDC;HABANA,Wire,UL1571,2PIN BA44-00210A ADAPTOR;API5AD10,AD-9019S,AC/DC,90to264V BA44-00215A ADAPTOR;0455A1990,AD-9019S,AC/DC,90to264...
  • Page 137 - This Document can not be used without Samsung's authorization - 6. Exploded View NP-P50CV03/CHN Part Code Part Name & Specification Q'ty SA/SNA Note BA46-03755A S/W CD;RCD,NP/DT,WINXPH SP2 OSCD,1.0,CHS BA46-04488B S/W CD;UTILITY,AQUILLA-SO,WINXP H/P,1.0, BA46-04630B S/W CD;UTILITY,HABANA-Biz,WINXP H/P,1.0, 0403-001047 DIODE-ZENER;BZX84C12L,5%,225mW,SOT-23,TP 0404-000114 DIODE-SCHOTTKY;MMBD301,30V,200MA,SOT-23,...
  • Page 138 10. Electrical Partlist Main System Option SEC code Location Name Spec. Unit 0902-001916 D-T2300_1.66GHz IC-MICROPROCESSOR IC-MICROPROCESSOR;Yonah-2M,1.67GHz,64Bit 0902-001937 D-T2600_2.16GHz IC-MICROPROCESSOR IC-MICROPROCESSOR;Yonah-2M,2.16GHz,64Bit 0902-001938 D-T2500_2.0GHz IC-MICROPROCESSOR IC-MICROPROCESSOR;Yonah-2M,2.0GHz,64Bit, 0902-001939 D-T2400_1.83Ghz IC-MICROPROCESSOR IC-MICROPROCESSOR;Yonah-2M,1.83GHz,64Bit 0902-001943 D-T1300_1.66GHz IC-MICROPROCESSOR IC-MICROPROCESSOR;756,1.66GHz,64Bit,uFCP 1105-001609 256M_D5(SEC) IC-DRAM MODULE IC-DRAM MODULE;M470T3354BG0,32Mx64Bit,SO PC 1105-001609 512M_D5(SEC 256X2) IC-DRAM MODULE IC-DRAM MODULE;M470T3354BG0,32Mx64Bit,SO PC...
  • Page 139 10. Electrical Partlist Option SEC code Location Name Spec. Unit BA39-00528A LCD CABLE CABLE FORM CONN.COAX CABLE FORM CONN.COAX;Habana,Twin coaxial BA39-00529A LED CABLE WIRE HARNESS-ONTOP WIRE HARNESS-ONTOP;HABANA,Wire,UL1571,10 PC BA39-00530A SIO CABLE WIRE HARNESS-SIO WIRE HARNESS-SIO;HABANA,Wire,UL1571,8PIN BA39-00531A MDC CABLE WIRE HARNESS-MDC WIRE HARNESS-MDC;HABANA,wire,DA-1571,2PI BA39-00531A MDC CABLE...
  • Page 140 INS-COMBO_JACK INSULATION-COMBO_JACK INSULATION- BA62-00396A INS-COMBO_JACK INSULATION-COMBO_JACK INSULATION- BA62-00402A INSULATION-FAN INSULATION-FAN BA63-00525A BOTTOM NO GFX COVER-SUPPORT_GM COVER- BA64-00700B LCD FRONT LOGO-SAMSUNG LOGO-SAMSUNG;CICHLID2,NI,T0.75(W/Tape),W BA64-00700E LCD BACK LOGO-SAMSUNG LOGO-SAMSUNG;CICHLID2,NI,T0.75(W/Tape),W BA68-00793D WINXP LOGO LABEL-LOGO_WINXP LABEL-LOGO_WINXP;OSCAR,- BA68-01781A BLUETOOTH LOGO LABEL LABEL;TAURUS,SWB-1000M,-,ART PAPER,T0.2, BA68-02155A NVIDIA LABEL LABEL-NVIDIA LABEL-NVIDIA;AQUILA,ALL,-,-,W20,L20MM,SI...
  • Page 141 10. Electrical Partlist Option SEC code Location Name Spec. Unit BA81-02325A LCD BACK HINGE-L HINGE-L;HABANA,ZINC/STS304,W12.7*L36.0mm PC BA81-02326A LCD BACK HINGE-R HINGE-R;HABANA,ZINC/STS304,W12.7*L36.03m BA81-02328A BOTTOM LENS-IRDA LENS- BA81-02332A LCD BACK KNOB-LATCH KNOB- BA81-02588A BOTTOM CAP-SIO CAP- BA92-03975A G72M-SS64MB ASSY VIDEO BD-GRAPHIC-BD ASSY VIDEO BD-GRAPHIC-BD;HABANA,NVIDIA,G PC BA92-03976A G73M_SS256MB ASSY VIDEO BD-GRAPHIC_BD ASSY VIDEO BD-GRAPHIC_BD;HABANA,NVIDIA,G...
  • Page 142 10. Electrical Partlist Option SEC code Location Name Spec. Unit 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005...
  • Page 143 10. Electrical Partlist Option SEC code Location Name Spec. Unit 2203-006048 C155 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C156 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006090 C157 C-CER,CHIP 10000nF,10%,6.3V,X5R,2012 2203-006048 C158 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C159 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C160 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006090 C161 C-CER,CHIP 10000nF,10%,6.3V,X5R,2012 2203-006048 C183 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006093...
  • Page 144 10. Electrical Partlist Option SEC code Location Name Spec. Unit 2203-006048 C302 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C303 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C304 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006093 C305 C-CER,CHIP 1000nF,+80-20%,6.3V,Y5V,1005 2203-006048 C306 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C307 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C308 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006093 C309 C-CER,CHIP 1000nF,+80-20%,6.3V,Y5V,1005 2203-006048...
  • Page 145 10. Electrical Partlist Option SEC code Location Name Spec. Unit 2203-006048 C507 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C508 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C509 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C511 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C512 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C513 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C514 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006090 C517 C-CER,CHIP 10000nF,10%,6.3V,X5R,2012 2203-006048...
  • Page 146 10. Electrical Partlist Option SEC code Location Name Spec. Unit 2203-006090 C722 C-CER,CHIP 10000nF,10%,6.3V,X5R,2012 2203-006090 C723 C-CER,CHIP 10000nF,10%,6.3V,X5R,2012 2203-006048 C724 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C726 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C727 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C728 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C729 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C732 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048...
  • Page 147 10. Electrical Partlist Option SEC code Location Name Spec. Unit 2203-006048 C864 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C865 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C866 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C867 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C868 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C869 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006090 C870 C-CER,CHIP 10000nF,10%,6.3V,X5R,2012 2203-006048 C871 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048...
  • Page 148 10. Electrical Partlist Option SEC code Location Name Spec. Unit 3711-000386 J628 HEADER-BOARD TO CABLE BOX,10P,1R,1.25MM,SMD-S,SN,WHT 3722-001641 J1001 JACK-USB 4P/2C,AUF,BLK,ANGLE-OFFSET,A TYPE 3701-001323 J1002 CONNECTOR-DSUB 9P,2R,FEMALE,ANGLE-OFFSET,NI 3711-000386 J1003 HEADER-BOARD TO CABLE BOX,10P,1R,1.25MM,SMD-S,SN,WHT 3722-001822 J1004 JACK-IEEE1394 4P/1C,AU30U,BLK,ANGLE,IEEE1394 3708-002167 JHDD1 CONNECTOR-FPC/FFC/PIC 50P,0.5mm,SMD-A,AU,Y,FLIP,BOTOM SMD,P- 0601-000189 LED602 GRN,3.2X1.6X1.1MM,557NM,3.2X1.6X1.1MM...
  • Page 149 10. Electrical Partlist Option SEC code Location Name Spec. Unit PI5V330QX,-,QSOP,16P,150MIL,DUAL,5V,- 1001-001251 IC-ANALOG MULTIPLEX 40to85C,PLASTIC,0.5W,10Ohm,5ns,5ns,1uA,TP,- FST3125,BUS 1001-001097 IC-ANALOG SWITCH SWITCH,TSSOP,14P,173MIL,QUAD,7V,- 40TO+85C,PLASTIC,-,4OHM,5.6NS,5.5NS AD1986AJSTZ_R0.2,LQFP,48P,7x7mm,PLASTIC,5 1205-002813 IC-CODEC .5V,365mW,0to+70C,TR,AC97 HD Audio Soun ICS954305D,QFN,72P,10x10mm,PLASTIC,3.465V Multi 1205-002799 IC-CLOCK GENERATOR ,1.155W,0to+70C,TP,- SLG84450VTR,QFN,72P,10x10mm,PLASTIC,3.46 Multi 1205-002801 IC-CLOCK GENERATOR 5V,-,0to+70C,TP,- TPS793475DBVR,SOT- 1203-002972 IC-POSI.FIXED REG.
  • Page 150 10. Electrical Partlist Option SEC code Location Name Spec. Unit External 945PM,64Bit,FCBGA,1466P,37.5x37.5mm,667MH 0904-002051 U613 IC-MEMORY CONT. model z,TR,PLASTIC,1.05V,2W,-55to+150C,32Bit, SC452IMLTRT,MLP,44P,7x7mm,PLASTIC,0.3/6.5 1203-003898 U614 IC-POWER SUPERVISOR V,-,-40to+125C,-,1.97/2.03V,TP MAX8632ETI+T,QFN,28P,5x5mm,PLASTIC,0.7/5.5 1203-004005 U615 IC-PWM CONTROLLER V,2.86W,-40to+85C,-,1.98/2.02V,TR EMC6N300,SSOP,24P,8.65x5.99mm,PLASTIC,5.5 1209-001531 U616 IC-TEMP. TRANSDUCER V,-,0to+85C,TP 7SZ08,2-INPUT AND 0801-002628 U617 IC-CMOS LOGIC GATE,SC70,5P,49MIL,SINGLE,TP,CMOS,1.8/5.5V ,0V,-40to+85C,150mW...
  • Page 151 10. Electrical Partlist Option SEC code Location Name Spec. Unit 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005...
  • Page 152 Location Name Spec. Unit G72M G72M,64Bit,BGA,820P,33x33mm,500MHz,TR,BA 0904-002076 U502 IC-GRAPHIC CONT. model G72M-V G72M- 0904-002077 U502 IC-GRAPHIC CONT. model V,64Bit,BGA,820P,33x33mm,500MHz,TR,BARE SAMSUNG K4J52324QC,GDDR3,512Mbit,8x2Mx32Bit,FBGA,1 1105-001688 IC-VIDEO RAM 128MB SAMSUNG K4J52324QC,GDDR3,512Mbit,8x2Mx32Bit,FBGA,1 1105-001688 U501 IC-VIDEO RAM 128MB SAMSUNG K4J52324QC,GDDR3,512Mbit,8x2Mx32Bit,FBGA,1 1105-001688 U504 IC-VIDEO RAM 128MB SAMSUNG...
  • Page 153 - This Document can not be used without Samsung's authorization - 8. System Block Diagram 8-1 Block Diagram...
  • Page 154 - This Document can not be used without Samsung's authorization - 8. System Block Diagram 8. 시스템 블록도...
  • Page 155 - This Document can not be used without Samsung's authorization - 8. System Block Diagram...
  • Page 156 - This Document can not be used without Samsung's authorization - 8. System Block Diagram...
  • Page 157 - This Document can not be used without Samsung's authorization - 8. System Block Diagram...
  • Page 158 - This Document can not be used without Samsung's authorization - 9. System Wire Diagram 9-1. R65 Top Right Left speaker speaker Ontop board Touch-pad IF board Speaker cable Ontop cable Touchpad cable Touchpad FFC 9-2. R65 Bottom LCD conn...
  • Page 159 - This Document can not be used without Samsung's authorization - 9. System Wire Diagram 9-3. P50 Top Left Right speaker speaker Ontop board FingerPrint Touch-pad IF board board 9-4. P50 Bottom LCD conn (J605) To SIO cable (J609) To FAN...
  • Page 160 - This Document can not be used without Samsung's authorization - 9. System Wire Diagram 9-5. R65 LCD 9- 3...

Table of Contents
