Summarization of Contents
Air Filter and Front Panel Service
Standard Air Filter Removal
Steps to detach standard air filters, including orientation and interchangeability.
Photocatalytic Air Purifier Filter Removal
Procedure to remove specialized air-purifying filters from the unit frame.
Front Panel Removal
Steps to release rotary shafts and remove the main front panel assembly.
Front Grille Service
Service Cover Detachment
Instructions for removing the service cover, noting its optionality for grille removal.
Front Grille Removal
Detailed steps for removing the front grille, including screws, covers, and hooks.
Electrical Box Service
Initial Electrical Box Disassembly Steps
Steps for removing screws, drip proof plate, clamp, and earth wire.
Component and Harness Disconnection
Detaching thermistor, terminal board, wire fixture, and various connectors/harnesses.
Final Electrical Box Removal
Releasing final connectors, screws, and lifting the electrical box from the frame.
Printed Circuit Board (PCB) Service
Signal Receiver PCB Removal
Steps to remove the signal receiver PCB, shield plate, and terminal board.
Intelligent Eye Sensor PCB Removal
Procedure to remove the Intelligent Eye sensor PCB and its associated ASSY.
Display PCB Removal
Steps to detach the display PCB, including harness and connector.
Control PCB Removal
Steps to remove the control PCB, including wires and terminals.
Horizontal Blade and Air Outlet Service
Horizontal Blade Removal
Steps to release and remove the main horizontal blades (large and small).
Air Outlet Assembly Removal
Procedure to detach air outlet assemblies using rear hooks.
Fan Guard Removal
Steps to unfasten hooks and remove fan guards from the unit.
Swing Motor Service
Horizontal Blade Swing Motor Removal
Steps to detach swing motors for horizontal blades, including rods and screws.
Vertical Blade Swing Motor Removal
Procedures for removing swing motors for vertical blades, including link covers and rods.
Indoor Heat Exchanger Service
Indoor Heat Exchanger Preparation
Steps including drain hose, piping, and frame detachment, with safety precautions.
Indoor Heat Exchanger Detachment
Procedures to release auxiliary piping, screws, hooks, and lift the heat exchanger.
Fan Motor and Rotor Service
Fan Motor Component Disassembly
Steps to remove side plate, fixing plate, and fan motor harness.
Fan Motor and Rotor Removal
Procedures to loosen rotor screw, remove motor, and then the rotor, with reassembly notes.
Vertical Blade Assembly Service
Vertical Blade Assembly Detachment
Steps to unfasten hooks and remove vertical blade assemblies.
