INSTRUCTION MANUAL
DIGITAL STORAGE OSCILLOSCOPE
DCS-9700 SERIES
DCS-9730
DCS-9720
DCS-9710
DCS-9707
DCS-9730D
DCS-9720D
DCS-9710D
DCS-9707D
B71-0206-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCS-9707D and is the answer not in the manual?

Questions and answers

Related Manuals for TEXIO DCS-9707D

Summary of Contents for TEXIO DCS-9707D

  • Page 1 INSTRUCTION MANUAL DIGITAL STORAGE OSCILLOSCOPE DCS-9700 SERIES DCS-9730 DCS-9730D DCS-9720 DCS-9720D DCS-9710 DCS-9710D DCS-9707 DCS-9707D B71-0206-11...
  • Page 2 ■ About a trademark, a registered trademark A company name and the brand name mentioned in this instruction manual are the trademark or the registered trademark of each company or group in each country and region. ■ About this instruction manual When copying the part or all of contents of this instruction manual, seek the copyright holder.

  • Page 3: Table Of Contents

    Table of Contents USING THE PRODUCT SAFELY...........Ⅰ-Ⅴ 1. GETTING STARTED ..............1 1-1. Main Features ..............1 1-2. Accessories ................3 1-3. Panel Overview ..............4 1-3-1. Front Panel ..................4 1-3-2. Rear Panel ..................10 1-3-3. Display..................... 12 1-4. Set Up ................14 1-4-1.
  • Page 4 2-1-30. Search – Pulse Width ..............39 2-1-31. Search - Runt ................39 2-1-32. Search – Rise/Fall Time ..............40 2-1-33. Zoom Key ..................40 2-1-34. Option Key ..................41 2-2. Default Settings ..............42 2-3. Built-in Help ............... 43 3.
  • Page 5 4-3-1. Display Waveform as Dots or Vectors ..........82 4-3-2. Set the Level of Persistence ............83 4-3-3. Set the Intensity Level ..............83 4-3-4. Set the Waveform Intensity Type ............ 84 4-3-5. Select Display Graticule ..............85 4-3-6. Freeze the Waveform (Run/Stop) ............ 85 4-3-7.
  • Page 6 4-8-6. Demo Outputs ................116 5. OPTIONAL SOFTWARE and APPS.......... 118 5-1. Applications ............... 118 5-1-1. Overview ..................118 5-1-2. Running Applications ..............118 5-1-3. Uninstalling Applications..............118 5-1-4. Using Go-NoGo ................119 5-2. Optional Software .............. 123 5-2-1. Activating Optional Software ............123 5-2-2.
  • Page 7 9-8. GP-IB Functionality Check ..........159 9-9. Web Server Overview ............161 10. MAINTENANCE ..............163 10-1. How to use SPC function ..........163 10-2. Vertical Accuracy Calibration ..........164 10-3. Probe Compensation ............165 11. APPENDIX ................167 11-1. DCS-9700 Specifications ..........167 11-1-1.
  • Page 8 USING THE PRODUCT SAFELY ■ Preface To use the product safely, read this instruction manual to the end. Before using this product, understand how to correctly use it. If you read this manual but you do not understand how to use it, please ask us or your local dealer.
  • Page 9 USING THE PRODUCT SAFELY WARNING CAUTION ■ Do not remove the product’s covers and panels Never remove the product’s covers and panels for any purpose. Otherwise, the user’s electric shock or fire may be incurred. ■ Warning on using the product Warning items given below are to avoid danger to user’s body and life and avoid the damage or deterioration of the product.
  • Page 10 USING THE PRODUCT SAFELY ■ Warning item on Grounding If the product has the GND terminal on the front or rear panel surface, be sure to ground the product to safely use it. ■ Warnings on Installation environment ● Operating temperature and humidity Use the product within the operating temperature indicated in the “rating”...
  • Page 11 USING THE PRODUCT SAFELY ■ Warning Item for the Measurement ● When you measure a part of a high voltage, be careful not to touch a hand to a measurement part directly. There is a risk of an electric shock. ●...
  • Page 12 USING THE PRODUCT SAFELY ■ Input / Output terminals Maximum input to terminal is specified to prevent the product from being damaged. Do not supply input, exceeding the specifications that are indicated in the "Rating" column in the instruction manual of the product. Also, do not supply power to the output terminals from the outside.

  • Page 13: Getting Started

    Model name Frequency Input Real-time bandwidth channels Sampling Rate DCS-9707 70MHz 2GSa/s DCS-9710 100MHz 2GSa/s DCS-9720 200MHz 2GSa/s DCS-9730 300MHz 2GSa/s DCS-9707D 70MHz 2GSa/s DCS-9710D 100MHz 2GSa/s DCS-9720D 200MHz 2GSa/s DCS-9730D 300MHz 2GSa/s This instruction manual has been described as the Note 4ch model.
  • Page 14 • Features 8 inch TFT SVGA display. • All models feature a real-time sampling rate of 2GSa/s and an equivalent time sampling rate of 100GSa/s. • Deep memory: 2M points record length. • Waveform capture rate of 80,000 waveforms per second. •...

  • Page 15: Accessories

    Passive GTP-070B-4 70MHz(DCS-9707 / DCS-9707D) probe GTP-150B-4 150MHz(DCS-9710 / DCS-9710D) GTP-250A-2 250MHz(DCS-9720 / DCS-9720D) GTP-350A-2 350MHz(DCS-9730 / DCS-9730D) Options Option Number Description DS2-LAN Ethernet & SVGA output DS2-GPIB GP-IB Interface DS2-FGN DDS Function Generator DS2-08LA 8-Channel Logic Analyzer card with...

  • Page 16: Panel Overview

    1-3. Panel Overview 1-3-1. Front Panel 4ch Model Autoset, Run / Stop, Variable knob Function and Select Single and Default keys settings Horizontal VARIABLE controls Measure Cursor Test Acquire Autoset Hardcopy Hardcopy Key Display Help Save / Recall Utility Run / Stop HORIZONTAL Single TIME /DIV...
  • Page 17 8” SVGA TFT color LCD. 800 x 600 resolution, LCD Display wide angle view display. Menu Off Menu Off Key Use the Menu Off key to hide the onscreen menu system. Option Option Key The Option key is used to access any installed options, such the Logic Analyzer option.
  • Page 18 Function Keys The Function keys are used to enter and configure different functions on the DCS-9700 . Measure Configures and runs automatic Measure measurements. Cursor Configures and runs cursor Cursor measurements. Test Configures and runs applications. Test Acquire Configures the acquisition mode, Acquire including Segmented Memory acquisition.
  • Page 19 TIME/DIV TIME/DIV The Time/Div knob is used to Knob change the horizontal scale. Zoom Press Zoom in combination with Zoom the horizontal Position knob. Play/Pause The Play/Pause key allows you to view each search event in succession – to effectively “play” through each search event.
  • Page 20 VOLTS/DIV Sets the vertical scale of the VOLTS/DIV Knob channel. EXT TRIG External Trigger Accepts external trigger signals Input (page 95). Input impedance: 1MΩ Voltage input: ±15V(peak), EXT trigger capacitance:16pF. MATH Math Key Use the math key to set and configure math functions.
  • Page 21 Demo Demo and The Demo outputs are Probe multifunction outputs that can be Compensation configured for probe Outputs compensation, as a trigger output or as a basic waveform generator for demonstration purposes. (FM signal, UART, I C, SPI). By default, the 3 Demo outputs are configured as: 1: Trigger output 2: FM waveform...

  • Page 22: Rear Panel

    1-3-2. Rear Panel RS-232C USB Device USB Host port port port Module Slot 1 Calibration output Module Slot 2 Ser. No. Label LINE VOLTAGE AC 100 240V RANGE CAUTION FREQUENCY 60Hz TO AVOID ELECTRIC SHOCK THE POWER CORD PROTECTIVE GROUNDING CONDUCTOR MUST BE CONNECTED TO GROUND.
  • Page 23 Module Slots The module slots are used to install the optional modules: DS2-LAN : Ethernet and SVGA DS2-GPIB : GP-IB DS2-08LA : 8 channel logic analyzer DS2-16LA : 16 channel logic analyzer DS2-FGN :Function generator Power Input Power cord socket accepts AC Socket mains, 100 ~ 240V, 50/60Hz.

  • Page 24: Display

    1-3-3. Display Channel Memory bar Trigger Status Acquisition mode Indicators Date and time Analog Trigger position Trigger level Waveforms Waveform Digital frequency waveforms Trigger configuration Channel status Horizontal status Analog Shows the analog input signal waveforms. Waveforms Channel 1: Yellow Channel 2: Blue Channel 3: Pink Channel 4: Green...
  • Page 25 Memory Bar The ratio and the position of the displayed waveform compared with the internal memory (page 87). Trigger Status Triggered. Pre-trigger. Not triggered, display not updated. Trigger stopped. Also appears in Run/Stop (page 46). Roll mode. Auto trigger mode. For trigger details, see page 95.

  • Page 26: Set Up

    1-4. Set Up 1-4-1. Tilt Stand Tilt To tilt, pull the legs forward, as shown below. Stand To stand the scope upright, push the legs back under the casing as shown below.

  • Page 27: Module Installation

    1-4-2. Module Installation Background The DCS-9700 has a number of optional modules that can be installed into the module slots on the rear panel. These modules must be installed before power up. The modules are not hot-swappable. Please Note ensure the power is off before connecting or disconnecting any of the modules from the rear panel.

  • Page 28: Software Installation

    1-4-3. Software Installation Background The DCS-9700 has optional software packages to expand the functionality of the standard DCS- 9700 .An activation key is required to activate any optional software. A different activation key is required for each optional software package. For the latest files and information regarding the optional software packages, see our website or contact your nearest distributor.

  • Page 29: First Time Use

    POWER 2. Press the POWER key. The display becomes active in ~ 30 seconds. : ON : OFF The DCS-9700 recovers the state right before the Note power is turned OFF. The default settings can be recovered by pressing the Default key on the front panel.
  • Page 30 Demo POSITION Demo 6. Capture Press the Autoset key. A square Autoset Signal (Autoset) waveform appears on the center of the screen. For Autoset details, see page 45. 7. Select Vector Press the Display key, and set the Display Waveform display to Vector on the bottom menu.

  • Page 31: How To Use This Manual

    8. Compensate Turn the adjustment point on the probe to make Probe the square waveform edge flat. Under Over Normal Compensation Compensation 9. Start Continue with the other operations. Operation Measurement: page 44 Configuration: page 70 Save/Recall: page 125 File Utilities: page 141 Apps.: page 118 Hardcopy key: page 147 Remote Control: page...
  • Page 32 Menu item Menu item Menu item Active Optional Parameter parameter parameters When the user manual says to “select” a value Selecting a Menu Item, from one of the side menu parameters, first press Parameter or the corresponding menu key and use the Variable Variable knob to either scroll through a parameter list or to increase or decrease a variable.
  • Page 33 Example 2 For some variables, a circular arrow icon indicates that the variable for that menu key can be edited with the Variable knob. 1. Press the desired menu key to select it. The circular arrow will become highlighted. 2. Use the Variable knob to edit the value. Toggling a Menu Parameter 1.
  • Page 34 1. To reduce the side menu, press the corresponding bottom menu that brought up the side menu. For example: Press the Source soft-key to reduce the Source menu. Reduce Lower Menu GDS-2204A Digital Storage Oscilloscope VARIABLE 200 MHz 2 GS/s Visual Persistence Oscilloscope Measure Cursor...
  • Page 35 GDS-2204A Digital Storage Oscilloscope VARIABLE 200 MHz 2 GS/s Visual Persistence Oscilloscope Measure Cursor Test Hardcopy Display Help Save/Recall HORIZONTAL POSITION Select 1. Press the Menu Off key to Search Zoom Set/Clear reduce the side menu, press VERTICAL POSITION POSITION POSITION POSITION again to reduce the bottom...

  • Page 36: Quick Reference

    2. QUICK REFERENCE This chapter describes the DCS-9700 menu tree, shortcuts to major operations, built-in Help access, and default factory settings. Use them as a handy reference to get a quick access to the functionality. 2-1. Menu Tree / Operation Shortcuts 2-1-1.

  • Page 37: Acquire Key

    2-1-2. Acquire Key Sets the acquisition mode. Acquire Reset H Record Sample rate Mode Segments Length Position to 0s XXXMSPS Sample Auto OFF(YT) Peak Detect Sin(x)/x Short Triggered Average 2,4,8,16,32,64, 128,256 Digital Filter Off, 1% ~ 49% of sample rate, Segments Goes to the Segments menu 2-1-3.

  • Page 38: Autoset Key

    2-1-4. Autoset Key Automatically finds the signal and sets the horizontal and vertical scale. Autoset Mode Undo Autoset Fit Screen AC Priority 2-1-5. CH1 ~ 4 Key Set the channel input parameters. Position/ Set to 0 Coupling Impedence Invert Bandwidth Expand by Probe xxxV...

  • Page 39: Display Key

    2-1-7. Display Key Set the display properties. Display Dot Vector Persistence Intensity Waveform Graticule Time Gray Waveform Intensity Full Vector 0%~100% Color 100ms~10s Grid Infinite Cross Hair Graticule Intensity VPO Off 10%~100% Frame Clear Persistence 2-1-8. Help Key Turn help mode On/Off. Help...

  • Page 40: Math Key

    2-1-9. Math Key Standard math and FFT functions. MATH Advanced Math Math Source 1 Operator Source 1 CH1~CH4 CH1~CH4 d/dt ∫dt Ref1~Ref4 Ref1~Ref4 √ Operator f(x) Vertical Source dBV RMS CH1~CH4 × Linear RMS Ref1~Ref4 ÷ Window f(x) Source 2 Source 2 Hanning Edit f(x)

  • Page 41: Measure Key

    2-1-10. Measure Key Display automatic measurements either individually or as voltage/current, time or delay measurement groups. Measure Remove Gating Display All High-Low Statistics Measurement Measurement Statistics Select Source Auto Measurement (Full Record) CH1~CH4 Pk-Pk Math Remove High-Low: Screen D0~D15 Histogram (best Measurement Mean &...

  • Page 42: Hardcopy Key

    2-1-11. Hardcopy Key Hardcopy Print screen images or save a waveform, screen image or setup (depending on the assigned function). 2-1-12. Run/Stop Key Run/stop signal acquisition. Run/Stop 2-1-13. REF Key R1ON/OFF R2ON/OFF R3ON/OFF R4ON/OFF Vertical Vertical Vertical Vertical Vertical scale Vertical scale Vertical scale Vertical scale...

  • Page 43: Save/Recall Key

    2-1-14. Save/Recall Key Save and recall images, waveforms and panel setups. Edit labels for reference and setup files. Save/Recall Recall Edit File Recall Save Image Save Waveform Save Setup Setup Waveform Label File Format Label For From From Edit Label Edit Label CH1~CH4 CH1~CH4...

  • Page 44: Test Key

    2-1-15. Test Key Use the Go-NoGo application as well as other optional software. Test APP. Go-NoGo Unistall Go-NoGo Goes to the Go-NoGo menu 2-1-16. Test Key – Go-NoGo Compare Reference GoNo NG When Violating Enable Break Mode Source Auto Enter Stop Tolerance Disable...

  • Page 45: Trigger Type Menu

    2-1-17. Trigger Type Menu Menu Type Edge Goes to the Edge Trigger menu Delay Goes to the Pulse Width Trigger Pulse Width menu Video Goes to the Video Trigger menu Others Goes to the Pulse Runt Trigger menu Pulse Runt Goes to the Rise and Fall menu Rise &...

  • Page 46: Trigger Pulse Width Menu

    2-1-20. Trigger Pulse Width Menu Type Source Polarity When Threshold Mode Holdoff Pulse Width CH1~ CH4 > Auto -XX~XXV 10.0ns ~ 10.0s Normal < Set to TTL Set to AC Line ≠ D0~D15 1.4V Minimum Set to ECL EXT Probe EXT Probe >...

  • Page 47: Trigger Rise & Fall Menu

    2-1-23. Trigger Rise & Fall Menu Type Source Slope When Threshold Mode Holdoff Rise & Fall Auto > High CH1~ CH4 10.0ns~10.0s -XX~XXV Normal < Set to EXT Probe ≠ Minimum Volt -XX~XXV Current Set to TTL 10.0ns~10.0s Alternate 1.4V Set to ECL -1.3V Attenuation...

  • Page 48: Utility Key

    2-1-25. Utility Key Utility Data & File Utilities Language System Hardcopy Demo Output Time System Year Function USB Device Demo Mode English Create Folder Info 2XXX Print Port Analog Trad. Chinese Save Month Day UART Simp. Chinese Rename Ethernet Jan~Dec Ink Saver Korean 01~31...

  • Page 49: Utility Key - I/O

    2-1-26. Utility Key – I/O USB Device RS-232C Ethernet Socket Server Port Computer Baud Rate Server Back Space Printer 2400, 4800, 9600, 19200, DHCP/BOOTP Current Port 38400, 57600, 3000 115200 Stop Bit Select Port Save Now 1, 2 0 to 65535 Parity Set Port Even...

  • Page 50: Utility Key - Wave Generator - Demo Outputs

    2-1-28. Utility Key – Wave Generator - Demo Outputs Demo Output Demo Mode Analog UART Demo 1 Demo 1 Demo 1 Demo 1 SCLK SCLK Trigger Output Demo 2 Demo 2 Demo 2 Demo 2 Demo 3 Demo 3 Demo 3 Demo 3 Frequency 1~200kHz...

  • Page 51: Search - Pulse Width

    2-1-30. Search – Pulse Width Set the Search Function for pulse width events. Search Search Search Type Source Polarity When Threshold CH1~ CH4 Search Search > -XX~XXV Edge D0~D15 < Set to TTL Pulse Width Save All ≠ Runt 1.4V Marks Rise/Fall Time Set to ECL...

  • Page 52: Search - Rise/Fall Time

    2-1-32. Search – Rise/Fall Time Set the Search function for rise and fall time events. Search Search Search Type Source Slope When Threshold Search Search > High CH1~ CH4 Edge -XX~XXV < Pulse Width Save All ≠ Runt -XX~XXV Marks Rise/Fall Time Set to TTL 10.0ns~10.0s...

  • Page 53: Option Key

    2-1-34. Option Key Accesses the functions in the Option menu. Option Logic Function Analyzer Generator Logic Goes to the Logic Analyzer menu Analyzer Function Goes to the Function Generator menu Generator Goes to the options I/O menu *Note: Any option that is not installed will be grayed-out.

  • Page 54: Default Settings

    2-2. Default Settings The default factory installed settings can be Default recalled at any time by pressing the Default key. Acquire Mode: Sample XY: OFF Interpolation: Sin(x)/x Sample rate: 2GSPS Record Length: Auto Display Mode: Vector Persistence: 240ms Waveform intensity: 50% Graticule intensity: 50% Waveform visuals: Gray Graticule: full Channel Scale: 100mV/Div...

  • Page 55: Built-In Help

    2-3. Built-in Help The Help key accesses a context sensitive help menu. The help menu contains information on how to use the front panel keys. Panel Operation 1. Press the Help key. The Help display changes to Help mode. 2. Use the Variable knob to scroll up and down through the Help contents.

  • Page 56: Measurement

    3. MEASUREMENT 3-1. Basic Measurement This section describes the basic operations required in capturing and viewing the input signal. For more detailed operations, see the following chapters. Cursor Measurement → from page 59 • Configuration → from page 70 • Before operating the oscilloscope, please see the Getting Started.

  • Page 57: Autoset

    3-1-2. Autoset Background The Autoset function automatically configures the panel settings to position the input signal to the best viewing condition. The DCS-9700 automatically configures the following parameters. • Horizontal scale • Vertical scale • Trigger source channel There are two operating modes for the Autoset function: Fit Screen Mode and AC Priority Mode.

  • Page 58: Run/Stop

    Fit Screen Mode AC Priority Limitation Autoset does not work in the following situations. • Input signal frequency is less than 20Hz • Input signal amplitude is less than 30mV The Autoset key (page 45) does NOT automatically Note activate the channels to which input signals are connected.

  • Page 59: Horizontal Position/Scale

    Freeze Press the Single key to go into Single Single Waveform by the Single Trigger mode. The Single Trigger Single key turns bright white. Mode In the Single Trigger mode, the scope will be put into the pre- trigger mode until the scope encounters the next trigger point.

  • Page 60: Vertical Position/Scale

    Display bar The display bar indicates how much of the waveform is displayed on the screen at any given time. Changes to timebase will be reflected on the display bar. Fast Medium Slow Stop mode In the Stop mode, the waveform size changes according to the scale.

  • Page 61: Automatic Measurement

    The vertical scale indicator for each channel on the bottom of the display changes accordingly. 3-2. Automatic Measurement The automatic measurement function measures and updates major items for Voltage/Current, Time, and Delay type measurements. Measurements can be made with both the analog channels and the digital channels*, however the digital channels are only limited to a select number of time measurements.
  • Page 62 Voltage/Curren Pk-Pk Difference between positive t Measurement (peak to and negative peak. (=max − min) peak) Positive peak. Negative peak. Amplitude Difference between the global high and value and the global low value, measured over the entire waveform or gated region. (=high − low) High Global high voltage.
  • Page 63 ROVShoot Rise overshoot FOVShoot Fall overshoot RPREShoot Rise preshoot FPREShoot Fall preshoot Time Frequency Frequency of the waveform. Measurement Period Waveform cycle time. (=1/Freq) RiseTime The time required for the leading edge of the first pulse to rise from the low reference value to the high reference value.
  • Page 64 Time between: Source 1 first falling edge and Source 2 first rising edge. Time between: Source 1 first falling edge and Source 2 first falling edge. Time between: Source 1 first rising edge and Source 2 last rising edge. Time between: Source 1 first rising edge and Source 2 last falling edge.

  • Page 65: Add Measurement

    3-2-2. Add Measurement The Add Measurement function allows you to add up to eight automatic measurement items on the bottom of the screen from any channel source. 1. Press the Measure key. Measure Measurement 2. Press Add Measurement from the Item bottom menu.

  • Page 66: Remove Measurement

    1. To set the source, press either the Source1 or Source2 key from the side menu and choose the source. Source 2 is only applicable for delay measurements. Range CH1~ CH4, Math*, D0~D15** *The math source cannot include any digital (D0~D15) inputs.

  • Page 67: Display All Mode

    3. Choose one of the gating modes from the side menu: Off (full record), Screen, Between Cursors Cursors On If Between Cursors is selected, the Page 59 Screen cursor positions can be edited by using the cursor menu. 3-2-5. Display All mode Display All mode shows and updates all items from Voltage and Time type measurements.

  • Page 68: High Low Function

    Delay Delay type measurement is not available in this Measurements mode as only one channel is used as the source. Use the Individual measurement mode (page 53) instead. Digital Channels Only Frequency, Period, +Width, -Width and Duty Cycle measurements are supported for digital channels.

  • Page 69: Statistics

    3. Select the type of High-Low settings from the side menu. High-Low Settings: Histogram, Min-Max, Auto Restore Default To return to the default High-Low High-Low settings, press Set to Defaults. Settings 3-2-7. Statistics Background The Statistics function can be used to view a number of statistics for the selected automatic measurements.
  • Page 70 Standard The variance of the currently Deviation measured value from the mean. The standard deviation equals the squared root of the variance value. Measuring the standard deviation can, for example, determine the severity of jitter in a signal. The number of samples used to determine the standard deviation can be user-defined.

  • Page 71: Cursor Measurement

    3-3. Cursor Measurement Horizontal or vertical cursors are used to show the position and values of waveform measurements and math operation results. These results cover voltage, time, frequency and other math operations. When the cursors (horizontal, vertical or both) are activated, they will be shown on the main display unless turned off.
  • Page 72 Select Units 6. To change the units of the horizontal position, press H Unit. S, Hz, % (ratio), ˚(phase) Units Phase or Ratio 7. To set the 0% and 100% ratio or the 0˚ and 360˚ phase references Reference for the current cursor positions, press Set Cursor Positions As 100%.

  • Page 73: Use Vertical Cursors

    Cursor Time, rectangular, polar co- ordinates, product, ratio. Cursor Time, rectangular, polar co- ordinates, product, ratio. Delta (difference between cursors) Example Horizontal cursors 3-3-2. Use Vertical Cursors Panel Operation/ 1. Press the Cursor key twice. Cursor Range 2. Press V Cursor from the bottom menu if it is not already selected.
  • Page 74 Range Upper cursor movable, lower cursor position fixed Lower cursor movable, upper cursor position fixed Upper and lower cursor movable together 4. The cursor position information appears on the top left hand side of the screen. Time: cursor 1, cursor 2 Voltage/Current: cursor1, cursor2 Delta (difference between cursors) dV/dt or dI/dt...
  • Page 75 Frequency/Time: cursor1, cursor2 dB/V: cursor1, cursor2 Delta (difference between cursors) d/dt Example Horizontal cursors Vertical cursors XY Mode XY mode cursors measure a number of X by Y measurements. Cursor Rectangular, polar co-ordinates, product, ratio. Cursor Rectangular, polar co-ordinates, product, ratio. Delta (difference between cursors)

  • Page 76: Math Operation

    Example Vertical cursors Horizontal cursors 3-4. Math Operation 3-4-1. Overview Background Math operation runs addition, subtraction, multiplication, division, FFT, or certain advanced math functions for waveform manipulations using the input signals or reference waveforms (Ref1~4) and shows the result on the display. The resulted waveform characteristics can be measured using the cursors.

  • Page 77: Addition/Subtraction/Multiplication/Division

    Amplitude resolution Not good Suitable for..Frequency measurement on periodic waveforms Hamming FFT Frequency Good Window resolution Amplitude resolution Not good Suitable for..Frequency measurement on periodic waveforms Rectangular FFT Frequency Very good Window resolution Amplitude resolution Bad Suitable for..Single-shot phenomenon (this mode is the same as having no window at all)

  • Page 78: Fft

    Example Math Source 1 Source 2 Position and To move the math waveform vertically, Unit press the Position key from the side menu and use the Variable knob to set the position. –12.00 Div ~ +12.00 Div Range To change the unit/div settings, press Unit/div, then use the Variable knob to change the unit/div.
  • Page 79 4. Press the Vertical Units key from the side menu to select the vertical units used. Range Linear RMS, dBV RMS 5. Press the Window key from the side menu and select the window type. Range Hanning, Hamming, Rectangular, and Blackman. 6.

  • Page 80: Advanced Math

    MATH Clear FFT To clear the FFT result from the display, press the Math key again. 3-4-4. Advanced Math Background The advanced math function is used to perform a number of advanced math functions such as differentiation or integration of a source waveform. The f(x) source function (as used in the FFT function) can also be set from the advanced menu.

  • Page 81: Edit F(X)

    To select the vertical scale of the math waveform, press Unit/div and use the Variable knob. MATH Clear Advanced To clear the advanced math result Math from the display, press the Math key again. 3-4-5. Edit F(x) Background The f(x) source is a user-defined math function that can be used as a source waveform for the FFT or advanced math functions.

  • Page 82: Configuration

    4. CONFIGURATION 4-1. Acquisition The Acquisition process samples the analog input signals and converts them into digital format for internal processing. 4-1-1. Select Acquisition Mode Background The acquisition mode determines how the samples are used to reconstruct a waveform. Sample This is the default acquisition mode.

  • Page 83: Digital Filter

    Example Sample Peak Detect Average (256 times) 4-1-2. Digital Filter Background The digital filter function can remove unwanted components, such as noise, from the desired signal. The filtering only functions during continuous acquisition using either the Sample or Peak detect mode.

  • Page 84: Show Waveform In Xy Mode

    4. Press Digital Filter and set the digital frequency using the Variable knob. Turn the Variable knob fully anticlockwise to turn the digital filter off. 4-1-3. Show Waveform in XY Mode Background The XY mode maps the input of channel 1 to the input of channel 2.
  • Page 85 X-Y mode is split into two windows. The top window shows the signals over the full time range. The bottom window shows XY mode. To move the X Y waveform position, use the vertical position knob: Channel 1 knob moves the X Y waveform horizontally, Channel 2 knob moves the X Y waveform vertically.

  • Page 86: Set The Sampling Mode

    4-1-4. Set the Sampling Mode Background The DCS-9700 has two types of sampling modes: ET (Equivalent Time) and Sin(x)/x interpolation. Equivalent time sampling is able to achieve a sample rate of 100GSa/s when sampling periodic waveforms. Sin(x)/x interpolation uses a sinc interpolation formula to reconstruct a continuous signal between sampled points.

  • Page 87: Set The Record Length

    4-1-5. Set the Record Length Background The number of samples that can be stored is set by the record length. Record length is important in an oscilloscope as it allows longer waveforms to be recorded and/or allows higher sampling rates to be achieved when equivalent time sampling is used.

  • Page 88: Segmented Memory Acquisition

    4-2. Segmented Memory Acquisition The advanced segmented memory utility allows the scope memory to be divided into different segments. Each time the scope is triggered, it only acquires data for one segment of memory at a time. This allows you to use the full potential of the scope one segment at a time.

  • Page 89: Run Segmented Memory

    2. Press Segments on the bottom menu. 3. Press Select Segments and set the number of segments from the side menu. Logic Type Threshold Num of Seg 1~2048 Set to Maximum Sets to 0 segments Set to Minimum Sets to 2048 segments 4-2-3.

  • Page 90: Navigate Segmented Memory

    4. When the scope has finished acquiring segments, press the Segments Stop key from the bottom menu. Alternatively, press the Run/Stop key again. Run/Stop The Stop Indicator will be shown when in the Stop mode. The scope is now ready to navigate or analyze the acquired segments.

  • Page 91: Display All

    Segments This function will either perform Measure statistics calculation on the segments or tabulate a list of the measurement results. Segments Provides configuration information Info common for all the acquired memory segments. 4-2-6. Display All Operation 1. Press Analyze Segments from the bottom menu.

  • Page 92: Automatic Measurement

    4-2-7. Automatic Measurement Note To use automatic measurements with the segmented memory, automatic measurements must first be selected from the Measure menu before a segment is run. Digital channels cannot be used with this function. Setup Press the Measure key and select Measure any single source measurement from the Add Measurement menu.
  • Page 93 Statistics This function will bin the measurement results of Results the selected automatic measurement into a user- defined number of bins. This allows you to easily view statistics for a large number of segments. Setup 1. To select the number of bins for the statistics, press Divided by and select the number of bins with the Variable knob.

  • Page 94: Segment Info

    4-2-8. Segment Info Operation 1. Press Analyze Segments from the bottom menu. Note: This key will only be available in the Stop mode. 2. Press Segments Info. 3. A table showing all general setting information for the segmented memory acquisitions is shown on the display.

  • Page 95: Set The Level Of Persistence

    4-3-2. Set the Level of Persistence Background The persistence function allows the DCS-9700 to mimic the trace of a traditional analog oscilloscope. A waveform trace can be configured to “persist” for designated amount of time. Panel Operation 1. Press the Display menu key. Display 2.

  • Page 96: Set The Waveform Intensity Type

    Example Waveform Intensity 0% Waveform Intensity 100% Graticule Intensity 10% Graticule Intensity 100% 4-3-4. Set the Waveform Intensity Type Background The intensity gradient of a signal can be set to grayscale or color. If intensity is set to color, the intensity gradient is analogous to a thermal color gradient where high intensity areas are colored red and low intensity areas are colored blue.

  • Page 97: Select Display Graticule

    Example 4-3-5. Select Display Graticule Panel Operation 1. Press the Display menu key. Display 2. Press Graticule from the bottom menu. 3. From the side menu choose the graticule display type. Full: Shows the full grid; X and Y axis for each division. Grid: Show the full grid without the X and Y axis.

  • Page 98: Turn Off Menu

    2. The waveform and the trigger freezes. The trigger indicator on the top right of the display shows Stop. 3. To unfreeze the waveform, Run/Stop Run/Stop press the Run/Stop key again. The Run/Stop key turns green again and acquisition resumes. 4-3-7.

  • Page 99: Horizontal View

    4-4. Horizontal View This section describes how to set the horizontal scale, position, and waveform display mode. 4-4-1. Move Waveform Position Horizontally Panel Operation The horizontal position knob moves POSITION the waveform left/right. As the waveform moves, a position indicator on the on the top of the display indicates the horizontal position of the waveform in memory.

  • Page 100: Select Waveform Update Mode

    Horizontal Time base position Run Mode In Run mode, the memory bar and waveform size keep their proportion. When the time base becomes slower, roll mode is activated (if trigger is set to Auto). Stop Mode In Stop mode, the waveform size changes according to the scale.

  • Page 101: Zoom Waveform Horizontally

    Roll mode Select Roll 1. Press the Trigger Menu key. Menu Mode Manually 2. Press Mode from the bottom menu and select Auto (Untriggered Roll) from the side menu. 4-4-4. Zoom Waveform Horizontally Background When in Zoom mode, the screen is split into 2 sections.
  • Page 102 To reset the horizontal position, press H Position/Set to 0. TIME/DIV Zoom To increase the zoom range, use the TIME/DIV knob. The zoom time base (Z) at the bottom of the screen will change accordingly. Move the Zoom Use the Horizontal Position knob to POSITION Window pan the zoom window horizontally.

  • Page 103: Vertical View (Channel)

    4-5. Vertical View (Channel) This section describes how to set the vertical scale, position, and coupling mode. 4-5-1. Move Waveform Position Vertically POSITION Panel Operation 1. To move the waveform up or down, turn the vertical position knob for each channel. 2.

  • Page 104: Input Impedance

    2. Press Coupling repeatedly to toggle the coupling mode for the chosen channel. Range DC coupling mode. The whole portion (AC and DC) of the signal appears on the display. AC coupling mode. Only the AC portion of the signal appears on the display.

  • Page 105: Limit Bandwidth

    4-5-6. Limit Bandwidth Background Bandwidth limitation puts the input signal into a selected bandwidth filter. This function is useful for cutting out high frequency noise to see a clear waveform shape. The bandwidth filters available are dependent on the bandwidth of the oscilloscope model. Panel Operation 1.

  • Page 106: Select Probe Type

    Example If the vertical scale is changed when the Expand function is set to ground, the signal will expand from the ground level*. The ground level does not change when the vertical scale is changed. If the vertical scale is changed when the Expand function is set to center, the signal will expand from the center of the signal.

  • Page 107: Set The Deskew

    3. Press Attenuation on the side menu and use the Variable knob to set the attenuation. Alternatively, press Set to 10X. Range 1mX ~1kX (1-2-5 step) The attenuation factor adds no influence on the Note real signal. It just changes the voltage/current scale on the display.
  • Page 108 Falling edge trigger Delay The Delay trigger works in tandem with the edge trigger, by waiting for a specified time(duration) or number of events before the edge trigger starts. This method allows pinpointing a location in a long series of trigger events. Note: when using the delay trigger, the edge trigger source can be any one of the channel inputs, the EXT input or the AC line.

  • Page 109: Trigger Parameter Overview

    Rise and Fall Trigger on rising and or falling edges, below or over a specified rate. The threshold can also be specified. Thresholds Rate (time) Timeout Triggers when the signal stays high, low or either for a designated amount of time. The trigger level determines when a signal is high or low.
  • Page 110 Single The DCS-9700 acquires Single a waveform once when a trigger event occurs, then stops acquiring. Press the Single key to acquire a waveform again. Coupling DC coupling. (Edge, Delay) AC coupling. Blocks DC components from the trigger circuits. HF reject High frequency filter above 100kHz LF reject Low frequency filter below 5kHz...
  • Page 111 When Sets the pulse width (10ns ~ 10s) and the (Pulse Width) triggering condition. > Longer than Equal to ≠ < Shorter than Not equal to Threshold Sets the amplitude threshold level for the pulse (Pulse Width) widths. Threshold –XXV ~ +XXV, user-set level Set to TTL 1.4V Set to ECL -1.3V Set to 50% Sets the threshold to 50%...

  • Page 112: Setup Holdoff Level

    Timer 10nS~10.0 Sets the amount of time that a signal (Timeout) must stay high or low for the timeout trigger. 4-6-3. Setup Holdoff Level Background The holdoff function defines the waiting period before the DCS-9700 starts triggering again after a trigger point. The holdoff function ensures a stable display if there are a number points in a periodic waveform that can be triggered.

  • Page 113: Setup Trigger Mode

    4-6-4. Setup Trigger Mode Background The trigger mode can be set to Normal or Auto (untriggered roll). The triggering mode applies to all the trigger types. See page 88. Panel Operation 1. Press the Trigger menu key. Menu 2. Press Mode from the bottom menu to change the triggering mode.

  • Page 114: Using Advanced Delay Trigger

    9. Toggle Noise Rejection On or Off from the side menu. Range On, Off 10. From the bottom menu press Slope to toggle the slope type. Range Rising edge, falling edge, either 11. To set the external trigger level, select Level from the bottom bezel menu.

  • Page 115: Using Pulse Width (Glitch) Trigger

    Range 1 ~ 65535 events Set to Minimum 4-6-7. Using Pulse Width (glitch) Trigger Panel Operation 1. Press the trigger Menu key. Menu 2. Press the Type key from the lower bezel menu. 3. Select Pulse Width from the side menu.

  • Page 116: Using Video Trigger

    4-6-8. Using Video Trigger Panel Operation 1. Press the trigger Menu key. Menu 2. Press the Type key from the lower bezel menu. 3. Select Video from the side menu. The video trigger indicator appears at the bottom of the display. From left: source, video standard, field, line, coupling 4.

  • Page 117: Pulse Runt Trigger

    4-6-9. Pulse Runt trigger Panel Operation 1. Press the trigger Menu key. Menu 2. Press the Type key from the lower bezel menu. 3. Select Others → Pulse Runt from the side menu. The Pulse and Runt indicator appears at the bottom of the display.

  • Page 118: Using Rise And Fall (Slope) Trigger

    4-6-10. Using Rise and Fall (slope) Trigger Panel Operation 1. Press the trigger Menu key. Menu 2. Press the Type key from the lower bezel menu. → 3. Select Others Rise and Fall from the side menu. The Rise and Fall indicator appears at the bottom of the display.

  • Page 119: Using The Timeout Trigger

    4-6-11. Using the Timeout Trigger Panel Operation 1. Press the trigger Menu key. Menu 2. Press the Type key from the lower bezel menu. → 3. Select Others Timeout from the side menu. The Timeout indicator appears at the bottom of the display.

  • Page 120: Search

    4-7. Search The search feature can be used to search for events on both the analog and digital input channels. The events that can be searched for are similar to the events that are used for the trigger system. The only difference is that the search feature uses the measurement threshold levels rather than the trigger level to determine events.

  • Page 121: Copying Search Event To/From Trigger Events

    3. Press Search Type from the bottom menu and select the type of search. The search events are configured in the same fashion as the trigger events. Please see the trigger configuration settings for details: Event Types: Edge, Pulse Width, Pulse Runt, Rise/Fall Time, Logic*, Bus* *Requires the Logic Analyzer option.

  • Page 122: Search Event Navigation

    4-7-3. Search Event Navigation Background When using the search feature, each event can be searched for according to the event settings. Operation 1. Turn Search on and set the appropriate search type. 2. Search events are marked by hollow white triangles at the top of the graticule.

  • Page 123: Setting/Clearing Single Search Events

    4-7-5. Setting/Clearing Single Search Events Background In addition to searching for search events based on Search Type settings, custom search marks can be created with the Set/Clear key. Set Search Event 1. Navigate to a point of interest using POSITION the horizontal position knob or some other method.
  • Page 124 Zoom window Zoom time Horizontal base position TIME/DIV Zoom To increase the zoom range, use the TIME/DIV knob. The zoom time base (Z) at the bottom of the screen will change accordingly. Scroll Speed To alter the scrolling speed of the zoom window, press the Zoom Position key to toggle the scrolling speed.

  • Page 125: System Info / Language / Clock

    4-8. System Info / Language / Clock This section describes how to set the interface, beeper, language, time/date, and probe compensation signal. 4-8-1. Select Menu Language Parameter The following is a list of the languages available by default. Language selection may differ according to the region.

  • Page 126: Erase Memory

    4-8-3. Erase Memory Background The Erase Memory function will erase all internal waveforms, setup files and labels from internal memory. Erased Items Waveform 1~20, Setting memory 1~20, Reference 1~4, Labels Panel Operation 1. Press the Utility key. Utility 2. Press System from the lower menu.

  • Page 127: Turn The Buzzer On/Off

    4-8-4. Turn the Buzzer On/Off Panel Operation 1. Press the Utility key. Utility 2. Press System from the lower menu. 3. Press Buzzer to toggle the buzzer sound on or off. 4-8-5. Set Date and Time Panel Operation/ 1. Press the Utility key. Utility Parameter 2.

  • Page 128: Demo Outputs

    4-8-6. Demo Outputs Demo Background The Demo outputs on the front panel are multi- function outputs that can be configured as a probe compensation output, a trigger output signal or to output a number of waveforms for demonstration purposes. Waveforms Mode Demo Outputs Outputs...
  • Page 129 3. Press Demo Mode from the side menu and select the mode for the Demo outputs. The actual output waveform for each demo output is listed in the side menu. Trigger Output Usage: Note To use the DEMO 1 Trigger Output signal, an input signal should first be connected to one of the input channels (CH1, 2, 3 or 4), otherwise no Trigger Output signal will be shown.

  • Page 130: Optional Software And Apps

    5. OPTIONAL SOFTWARE and APPS. 5-1. Applications 5-1-1. Overview Background The APP. function allows different applications to be run. Included Go/No-Go The Go/No-Go application can be Applications used to set threshold boundaries for input signals. Go/No-Go checks if a waveform fits inside a user-specified maximum and minimum amplitude boundary (template).

  • Page 131: Using Go-Nogo

    2. Press APP. from the bottom menu. 3. Scroll through each application using the Variable knob. 4. When the desired application is highlighted, press Uninstall to begin the uninstallation. Press ×2 again to confirm. 5-1-4. Using Go-NoGo Background The Go-NoGo test checks if a waveform fits inside a user-specified maximum and minimum boundary.
  • Page 132 Set Go-NoGo Select the Go-NoGo conditions (NG When) and Conditions actions when a Go-NoGo condition has been met (Violating). 1. Press NG When from the bottom menu and select the NoGo conditions: Enters: Sets the NoGo condition to when the input signal stays within the limit boundary.
  • Page 133 2. Press Go Back to return to the previous menu. Set Boundary 1. To set the Go-NoGo boundary Tolerance tolerance, press Reference Mode. Auto Tolerance 2. To set the boundary tolerance as a percentage offset from the source waveform, press Auto Tolerance VARIABLE and use the Variable knob.
  • Page 134 Results When Go-NoGo is running, the pass/fail ratio is displayed in the bottom right-hand corner. The first digit represents the number of failed tests, and the right hand digit represents the number of tests. Maximum Tolerance position Ratio: fail / test Minimum position Exit the...

  • Page 135: Optional Software

    5-2. Optional Software 5-2-1. Activating Optional Software Background The DCS-9700 has optional software packages to expand the functionality of the standard DCS- 9700 . An activation key is required to activate any optional software. A different activation key is required for each optional software package. For the latest files and information regarding the optional software packages, see our website or contact your nearest distributor.

  • Page 136: Uninstalling Optional Software

    5-2-3. Uninstalling Optional Software Background Optional software packages such can be uninstalled from the system menu. Panel Operation 1. Press the Utility key. Utility 2. Press System from the bottom menu. 3. Press more 1 of 2 from the side menu.

  • Page 137: Save/Recall

    6. SAVE/RECALL 6-1. File Format/Utility 6-1-1. Image File Format Format DSxxxx.bmp or DSxxxx.png Contents The display image is 800 by 600 pixels. The background color can be inverted (Ink saver function). Each image file is saved to the current file path as a bitmap or PNG file. 6-1-2.
  • Page 138 CSV-formatted files can be stored in either a short- memory format or a long-memory format: Detail CSV, Fast CSV, LM Detail CSV and LM Fast CSV. Detail CSV will record both the horizontal and vertical sample points of the waveform. All the points are recorded in scientific notation for analog data.
  • Page 139 • • Vertical position Horizontal units • • Horizontal scale Horizontal position • • Horizontal mode Sampling period • • Firmware Time • • Mode Vertical data • Horizontal data Contents: The following information is included in the Fast Fast CSV CSV waveform files, where applicable: •...

  • Page 140: Setup File Format

    6-1-4. Setup File Format Format DSxxxx.set (proprietary format) The setup file saves or recalls the following settings. • • Contents Acquire Mode • • Sample rate Sample mode • Digital Filter • Record Length • • Display Mode Graticule • Persistence intensity •...

  • Page 141: Create/Edit Labels

    6-2. Create/Edit Labels Overview Reference files, Setup files and the analog input channels can have individual file labels set. For the analog channels and reference waveforms, the file label can be displayed next to the channel/reference indicator. The file labels are also obviously used to identify reference files, setup files or channels when saving or recalling waveforms and setups.
  • Page 142 4. To choose a preset label, Press User Preset from the side menu and choose a label. Labels ACK, AD0, ANALOG, BIT, CAS, CLK, CLOCK, CLR, COUNT, DATA, DTACK, ENABLE, HALT, INT, IN, IRQ, LATCH, LOAD, NMI Edit Label 1. Press Edit Character to edit the current label.

  • Page 143: Save

    To cancel the editing the label and return to the previous menu, press Cancel. Display Label To display the currently selected file label on the screen next to its respective indicator, toggle Label Display to On. Conversely, if you want to remove the currently selected file label from the display, toggle Label Display to Off.

  • Page 144: Save Image

    6-3-2. Save Image Images can be saved either using the Save/Recall key or by using the Hardcopy key. To save images using the Hardcopy key, see the hardcopy section on page 147. Panel Operation 1. To save to USB, connect a Front Rear Host...

  • Page 145: Save Waveform

    The file will not be saved if the Note power is turned off or the USB drive is taken out before the message ends. USB File Utility To edit the USB flash drive contents (create/ delete/ rename files and folders) or to edit the default file path, press File Utilities from the side menu.

  • Page 146: Save Setup

    6. Press Save Now to confirm saving. When completed, a message appears at the bottom of the display. The file will not be saved if the Note power is turned off or the USB drive is taken out before the message ends.

  • Page 147: Recall

    5. Press Save Now to confirm saving. When completed, a message appears at the bottom of the display. The file will not be saved if the Note power is turned off or the USB drive is taken out before the message ends.

  • Page 148: Recall Default Panel Setting

    6-4-2. Recall Default Panel Setting Panel Operation 1. Press the Default key. Default 2. The screen will update with the default panel settings. Setting Contents The following is the default (factory) setting contents. Acquire Mode: Sample XY: OFF Sample mode: Sinc Sample rate: 2GSPS Digital filter: Off Record Length: Auto...

  • Page 149: Recall Waveform

    6-4-3. Recall Waveform Panel Operation 1. For recalling from an Front Rear external USB flash drive, Host connect the drive to the front or rear panel USB port. Only one host connection, front or rear, is allowed Note at a time. The USB Device port on the rear panel cannot be used concurrently with the USB Host port on the rear panel.

  • Page 150: Recall Setup

    USB File Utility To edit USB flash drive contents (create/ delete/ rename files and folders) or to set the file path, press File Utilities. For details, see page 141. 6-4-4. Recall Setup Panel Operation 1. (For recalling from an Front Rear external USB flash drive) Host...

  • Page 151: Reference Waveforms

    USB File Utility To edit USB flash drive contents (create/ delete/ rename files and folders) or to set the file path, press File Utilities. For details, see page 141. Edit Label To edit labels for Setup files, press Edit label. For more details on editing labels, see page 129.
  • Page 152 Vertical Press Vertical repeatedly from the Navigation side menu to choose to edit the vertical position or Unit/Div. Use the Variable knob to edit the values. Horizontal Press Horizontal repeatedly from the Navigation side menu to choose to edit the Time/Div or the horizontal position.

  • Page 153: File Utilities

    7. FILE UTILITIES The file utilities are used each time files need to be saved to internal or external memory. The file utilities can create directories, delete directories, rename files as well as copy files from internal memory to USB. BMP and PNG image files can be previewed in the file system.
  • Page 154 VARIABLE 4. Use the Variable knob to move the file cursor up and down. Image files have an automatic preview. Use the Select key to choose a file or directory or to set the file path. Select • Selecting an image file will Note Menu Off allow you to view the image at...

  • Page 155: Create Folder

    7-2. Create Folder Panel Operation 1. Press the Utility key. Utility 2. Press File Utilities from the bottom menu. 3. Use the Variable knob and select key to navigate the file system. Create Folder 4. Press Create Folder to make a new directory at the selected location.

  • Page 156: Rename File

    7-3. Rename File Panel Operation 1. Press the Utility key. Utility 2. Press File Utilities from the bottom menu. 3. Use the Variable knob and select key to choose a file to rename. 4. Press Rename when a file is chosen.

  • Page 157: Delete File

    7-4. Delete File Panel Operation 1. Press the Utility key. Utility 2. Press File Utilities from the bottom menu. 3. Use the Variable knob and select key to navigate the file system to choose a file. 4. Press Delete to delete the selected file.
  • Page 158 5. Press Copy to USB to copy the selected file to the USB drive. If the same file name already exists on the USB Note drive, it will be copied over.

  • Page 159: Hardcopy Key

    8. HARDCOPY KEY The Hardcopy key is used as quick-save or quick-print key. The Hardcopy key can be assigned either to printout screenshots or to save files. When assigned to “Print” the screen image can be printed to a PictBridge compatible printer using the USB device port. To reduce the amount of printer ink used for each print, images can be printed using the Ink Saver function.

  • Page 160: Print Output

    8-2. Print Output Ensure the USB port has been configured to the printer before trying to print, see page 147. Panel Operation 1. Press the Utility key. Utility 2. Press Hardcopy from the bottom menu. 3. On the side menu, press Function and select Print.
  • Page 161 2. Press the Utility key. Utility 3. Press Hardcopy from the bottom menu. 4. On the side menu, press Function to select Save. 5. Press Assign Save To and select which type of file will be saved when the Hardcopy key is pressed. File Type: Image, Waveform, Setup, All Hardcopy...

  • Page 162: Remote Control Config

    4. Connect the USB cable to the rear panel device port. 5. When the PC requests for the USB driver or ‘Unknown device’ listed in Device Manager, install TEXIO-CDC.inf attached CD. You must have administrator account to install Note driver.

  • Page 163: Configure Rs-232C Interface

    9-2. Configure RS-232C Interface RS-232C Connector DB-9, Male Configuration Baud rate 2400, 4800, 9600, 19200, 38400, 57600, 115200 Parity None, Odd, Even Data bit 8 (fixed) Stop bit 1, 2 Panel Operation 1. Press the Utility key. Utility 2. Press I/O from the bottom menu. 3.

  • Page 164: Configure The Ethernet Interface

    PC Connection Use a Null Modem connection as shown in the diagram below. Pin2 RxD Pin2 Pin3 TxD Pin3 Pin5 GND Pin5 9-3. Configure the Ethernet Interface Ethernet MAC Address Domain Name Configuration Instrument Name DNS IP Address User Password Gateway IP Address Instrument IP Subnet Mask...
  • Page 165 6. Use the Up and Down arrows on the side menu to navigate to each Ethernet configuration item. Items MAC Address, Instrument Name, User Password, Instrument IP Address, Domain Name, DNS IP Address, Gateway IP Address, Subnet Mask Note: HTTP Port is fixed at 80. VARIABLE 7.

  • Page 166: Configure Socket Server

    9-4. Configure Socket Server The DCS-9700 supports socket server functionality for direct two- way communication with a client PC or device over LAN. By default, the Sockets Server is off. Configure 1. Configure the IP address for the Page 152 Socket Server DCS-9700.

  • Page 167: Configure Gp-Ib

    9-5. Configure GP-IB To use GP-IB, the optional module, DS2-GPIB, Note must be installed. Please see page 15 for installation details. Connection 1. Connect a GP-IB cable from a PC to the installed GP-IB module. Configure GP-IB 2. Press the Utility key. Utility 3.

  • Page 168: Usb/Rs-232C Functionality Check

    Key in this query command via the terminal Check application. *idn? This should return the Manufacturer, Model number, Serial number, and Firmware version in the following format. TEXIO, DCS-97xx, PXXXXXX, V1.00 For further details about remote control and remote Note commands, please see the DCS-9700 programming manual.

  • Page 169: Socket Server Functionality Check

    9-7. Socket Server Functionality Check NI Measurement To test the socket server functionality, National and Automation Instruments Measurement and Automation Explorer Explorer can be used. This program is available on the NI website, www.ni.com. Operation 1. Start the NI Measurement and Automation Explorer (MAX) program.
  • Page 170 5. Select the IP address that corresponds to the DCS-9700 and click Next. 6. The DCS-9700 will now appear under Network Devices in the Configuration Panel. Functionality 7. Click the Open Visa Test Panel to send a Check remote command to the DCS-9700.

  • Page 171: Gp-Ib Functionality Check

    *IDN? query. 12. The manufacturer, model number, serial number and firmware version will be displayed in the buffer. For example: TEXIO, DCS-9720, P930116, V1.00 For further details about remote control and remote Note commands, please see the DCS-9700 programming manual.
  • Page 172 *IDN? is written in the Send String: text box. Click on the Query button to send the *IDN? query to the instrument. 8. The String Received text box will display the query return: TEXIO, DCS-9720,PXXXXXX,V1.XX (manufacturer, model, serial number, version)

  • Page 173: Web Server Overview

    9. The function check is complete. 9-9. Web Server Overview Background The DCS-9700 has an inbuilt web server that can be used to: • view the system information (Welcome Page) • set/view the network configuration settings (Network Configuration) • remotely view the current display image on the unit (Get Display Image) •...
  • Page 174 2. Enter the IP address of the DCS-9700 unit into the address bar of a web browser. For example: http://172.16.20.255 3. The DCS-9700 web browser welcome page appears.

  • Page 175: Maintenance

    10. MAINTENANCE Two types of maintenance operations are available: calibrate vertical accuracy, and compensate the probe. Run these operations when using the DCS-9700 in a new environment. 10-1. How to use SPC function Background Signal Path Compensation (SPC) is used to compensate the internal signal path due to ambient temperature.

  • Page 176: Vertical Accuracy Calibration

    10-2. Vertical Accuracy Calibration Panel Operation 1. Press the Utility key. Utility 2. Press System from the bottom menu. 3. Press more 1 of 2 from the side menu. 4. Press Self Cal on the side menu. 5. Press Vertical on the side menu. 6.

  • Page 177: Probe Compensation

    10-3. Probe Compensation Panel Operation 1. Connect the probe between the Channel 1 input and the probe compensation output (Demo 3 output, by default set as 2Vp-p, 1kHz square wave) on the front panel. Set the probe attenuation to x10. 2.
  • Page 178 Under Over Normal Compensation Compensation...

  • Page 179: Appendix

    DC ~ 70MHz (–3dB) 20MHz DCS-9710 4 + Ext DC ~ 100MHz (–3dB) 20MHz DCS-9720 4 + Ext DC ~ 200MHz (–3dB) 20MHz/100MHz DCS-9730 4 + Ext DC ~ 300MHz (–3dB) 20MHz/100MHz/200MHz DCS-9707D 2 + Ext DC ~ 70MHz (–3dB) 20MHz DCS-9710D 2 + Ext DC ~ 100MHz (–3dB) 20MHz...
  • Page 180 Trigger Source CH1 ,CH2, CH3, CH4, Line, EXT, D0-D15 Trigger Mode Auto (supports Roll Mode for 100 ms/div and slower), Normal, Single Trigger Type Edge, Pulse Width(glitch), Video, Pulse Runt, Rise & Fall(slope), Timeout, Alternate, Event-Delay(1~65535 events), Time-Delay(duration,10nS~10S), Logic*, Bus**with Logic Analyzer Option Holdoff range 10nS to 10S Coupling...
  • Page 181 Measurement Automatic 36 sets: Pk-Pk, Max, Min, Amplitude, High, Measurement Low, Mean, Cycle Mean, RMS, Cycle RMS, Area, Cycle Area, ROVShoot, FOVShoot, RPREShoot, FPREShoot, Frequency, Period, RiseTime, FallTime, +Width, -Width, Duty Cycle, +Pulses, -Pulses, +Edges, - Edges, FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF, Phase Voltage difference between cursors ( ∆V) Cursors...
  • Page 182 Threshold TTL, CMOS, ECL, PECL, User Defined selections User-defined ±10V Threshold Range Maximum ±40V Input Voltage Minimum ±500mV Voltage Swing Vertical 1 bit Resolution Miscellaneous Multi-language Available menu On-line help Available Time clock Time and Date ,Provide the Date/Time for saved data Dimensions 380mmX220mmX145mm...

  • Page 183: Probe Specifications

    11-2. Probe Specifications 11-2-1. GTP-070B-4 Applicable to: DCS-9707/DCS-9707D Position X10 Attenuation Ratio 10:1 Bandwidth DC to 70MHz 10MΩ when used with Input Resistance oscilloscopes with 1MΩ input. Input Capacitance 14.5pF to 17.5pF Compensation Range 10pF to 35pF ≤600Vpk, Derating with frequency Max.

  • Page 184: Gtp-250A-2

    47pF plus oscilloscope capacitance Max. Input Voltage 300V CAT I, 150V CAT II (DC + peak AC) derating with frequency. Safety EN61010-031 CAT II 11-2-4. GTP-350A-2 Applicable to: DCS-9730/DCS-9730D Position X10 Attenuation Ratio 10:1 Bandwidth DC to 350MHz Rise Time 1.0nS 10MΩ...

  • Page 185: Dcs-9700 Dimensions

    11-3. DCS-9700 Dimensions 144.4 134.0 VARIABLE Measure Cursor Test Acquire Autoset Hardcopy Display Help Save/Recall Utility Run/Stop HORIZONTAL Single TIME/DIV POSITION Select Search Zoom Default Set/Clear VERTICAL TRIGGER POSITION POSITION LEVEL POSITION POSITION MATH Menu Menu Off 50 % VOLTS/DIV VOLTS/DIV VOLTS/DIV VOLTS/DIV...

  • Page 186: Faq

    11-4. FAQ • I connected the signal but it does not appear on the display. • I want to remove the (Measurement result / FFT result / Help contents) from the display. • The waveform does not update (frozen). • The probe waveform is distorted. •...
  • Page 187 The accuracy does not match the specification. Make sure the device is powered On for at least 30 minutes, within +20°C~+30°C. This is necessary to stabilize the unit to match the specification. For more information, contact your local dealer or TEXIO TECHNOLOGY at www.texio.co.jp / info@texio.co.jp.
  • Page 188 7F Towa Fudosan Shin Yokohama Bldg., 2-18-13, Shin Yokohama, Kohoku-ku, Yokohama, Kanagawa, 222-0033, Japan. http://www.texio.co.jp/...

Table of Contents
