Appendices
52
English
RS232 Commands and Protocol
Function List
RS232 Pin Assignments
3
2
I/O (From
Pin no.
Name
Projector Side)
1
TXD
2
RXD
3
GND
1
9
5
Pin no.
1
2
OUT
3
IN
4
GND
5
6
7
8
9
8
7
6
4
3
2
1
Spec.
(from projector side)
N/A
RXD
TXD
N/A
GND
N/A
N/A
N/A
N/A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Optoma EH1020
Summary of Contents for Optoma EH1020
-
Page 1: Rs232 Commands And Protocol Function List
Appendices RS232 Commands and Protocol Function List RS232 Pin Assignments Spec. Pin no. (from projector side) I/O (From Pin no. Name Projector Side) English... -
Page 2: Rs232 Protocol Function List
Appendices RS232 Protocol Function List --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Baud Rate : 9600 Note : There is a <CR> after all ASCII commands Data Bits: 8 0D is the HEX code for <CR> in ASCII code Parity: None Stop Bits: 1 Flow Control : None UART16550 FIFO: Disable Projector Return (Pass): P Projector Return (Fail): F... - Page 3 = 0 (a=30) ~ 10 (a=31 30) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ~XX82 1 7E 30 30 38 32 20 31 0D Logo Optoma ~XX82 2 7E 30 30 38 32 20 32 0D User ~XX83 1 7E 30 30 38 33 20 31 0D...
- Page 4 FW version e : Display mode 0/1/2/3/4/5/6/7/8 None/Presentation/Bright/Movie/sRGB/User1/User2/ Blackboard/Classroom ~XX151 1 7E 30 30 31 35 31 20 31 0D Model name n:1=EH1020 ~XX108 1 7E 30 30 31 30 38 20 31 0D Lamp Hours OKbbbb bbbb: LampHour ~XX108 2...
