C-Nav 1000 Hardware Reference Manual
Dgnss navigation satellite systems
Hide thumbs
1
2
3
Table Of Contents
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
page
of
99
Go
/
99
Contents
Table of Contents
Troubleshooting
Bookmarks
Table of Contents
Contact Information
Notices
Revision History
Table of Contents
List of Tables
List of Figures
Chapter 1 Overview
C-Nav and Global Navigation Satellite Systems
Traditional Differential GNSS Positioning
Sources of GNSS Error
Measuring GNSS Accuracy
Common Values Used with GNSS
Table 1-1: Common Accuracy Measures Used with GPS
C-Nav Subscription Service
C-Navc2 Subscription Service
How to Access the C-Nav Subscription Service
L-Band Correction Signal
Figure 1-1: C-Nav Corrections Service Network Coverage
Table 1-2: L-Band Correction Identifiers and Modes
Table 1-3: C-Nav3050 Satellites Firmware Version 1.0.1.5 and Earlier
Table 1-4: C-Nav3050 Satellites Firmware Version 2.0.22.0 and Later
Chapter 2 Installation Guide
C-Nav Antenna Installation Notice
Standard Antenna Installation
Antenna Location
Figure 2-1: C-Nav3050 Antenna Properly Installed on Mast
Antenna Installation
Figure 2-2: C-Nav3050 Antenna on Mast - Hose Clamp Installation
Figure 2-3: C-Nav Antenna Mounting Pole Dimensions
Coaxial Cable
Cable Route
Coaxial Cable Installation
Figure 2-4: C-Nav3050 Antenna TNC Connector
Figure 2-5: C-Nav3050 Antenna and Coaxial Cable
Lightning Protection
GNSS Receiver
Table 2-1: Acceptable Coaxial Cable Lengths
Chapter 3 C-Nav DGNSS Hardware Specifications
C-Nav3050
C-Nav3050 Receiver
Figure 3-1: C-Nav3050 Base Plate Dimensions Without Mounting Brackets
Figure 3-2: C-Nav3050 Base Plate Dimensions with Mounting Brackets
Table 3-1: C-Nav3050 Physical and Environmental
Table 3-2: C-Nav3050 I/O Messages
Table 3-3: C-Nav3050 Connector Assignments
C-Nav3050 Antennas
Table 3-4: C-Nav3050 Standard, Base, and Airborne Antenna Specifications
Figure 3-3: C-Nav3050 Standard GNSS Antenna Offset
Figure 3-4: C-Nav3050 Standard (P/N NAV82-001020-3001) Antenna Dimensions
Figure 3-5: C-Nav3050 Airborne (P/N NAV82-001022-3001LF) Antenna Dimensions
Figure 3-6: C-Nav3050 Base (P/N NAV82-001021-3001LF) Antenna Dimensions
Figure 3-7: C-Nav3050 Standard & Airborne Antenna Radiation Pattern
Figure 3-8: C-Nav3050 Base Antenna Radiation Pattern
C-Nav1010
C-Nav1010 Receiver
Figure 3-9: C-Nav1010 Receiver Without Mounting Brackets
Figure 3-10: C-Nav1010 Receiver with Mounting Brackets
Table 3-7: C-Nav1010 Physical and Environmental
Table 3-8: C-Nav1010 I/O Messages
Table 3-9: C-Nav1010 Connector Assignments
C-Nav1010 Antennas
Table 3-10: C-Nav1010 Standard Antenna Specifications
Figure 3-11: C-Nav1010 Power Supply
Table 3-11: C-Nav1010 L-Band Antenna Specifications (45° - 25°)
Figure 3-12: C-Nav1010 Standard Antenna Dimensions
Figure 3-13: C-Nav1010 Standard Antenna Radiation Pattern
Figure 3-14: C-Nav1010 L-Band Antenna Dimensions (45° - 25°)
Figure 3-15: C-Nav1010 NAV82-001018-0001LF Antenna Mounting (45° - 25°)
Table 3-12: C-Nav1010 L-Band Antenna Specifications (<25°)
Figure 3-16: C-Nav1010 NAV82-001018-0001LF Radiation Pattern (45° - 25°)
Figure 3-17: C-Nav1010 NAV82-001003-0001LF Antenna and Mounts (<25°)
Figure 3-18: C-Nav1010 NAV82-001003-0001LF Radiation Pattern (<25°)
C-Nav2050
C-Nav2050 Receiver
Figure 3-19: C-Nav2050 Front View
Figure 3-20: C-Nav2050 Top View
Table 3-13: C-Nav2050 Physical and Environmental
Table 3-14: C-Nav2050 I/O Messages
Table 3-15: C-Nav2050 Connector Assignments
Figure 3-21: C-Nav2050 Power Supply
Figure 3-22: C-Nav2050 RS-232 to DP RS-422 MOXA Converter (MOXTCC-801)
Figure 3-23: C-Nav2050 Isolation Mount Adaptor
C-Nav2050 Antennas
Table 3-16: C-Nav2050 Standard Antenna
Table 3-17: C-Nav2050 Airborne Antenna
Figure 3-24: C-Nav2050 Standard Antenna Phase Center Dimensions
Figure 3-25: C-Nav2050 Antenna Dimensions [Inches (MM)]
Figure 3-26: C-Nav2050 Airborne Antenna Dimensions
Figure 3-27: C-Nav2050 Standard & Airborne Antenna Radiation Patterns
Figure 3-28: C-Nav2050 Antenna Mounting Pole Adaptor Dimensions
Table 3-18: C-Nav2050R Antenna
Figure 3-29: C-Nav2050R Antenna Dimensions and Mounts
Figure 3-30: C-Nav2050R Antenna Radiation Pattern
Figure 3-31: C-Nav2050R Antenna LNA Wide-Band Response
C-Nav1000
C-Nav1000 Receiver
Figure 3-32: C-Nav1000 Receiver Front View (MM)
Figure 3-33: C-Nav1000 Receiver Top View (MM)
Figure 3-34: C-Nav1000 Receiver Clearance Area
C-Nav1000 Display
Figure 3-35: C-Nav1000 RS-422 to DP RS-232 MOXA Converter (MOXTCC-801)
Figure 3-36: C-Nav1000 Display Front View (MM)
Figure 3-37: C-Nav1000 Display Top View (MM)
C-Nav1000 Antennas
Figure 3-38: MGL-4 (H-Field) Antenna
Figure 3-39: MGL-3 Antenna and Mounting Pole
C-Nav1000 Display Mounting Options
Figure 3-40: Gimbal Mount Clearance Area
Figure 3-41: Panel Mount Frame Dimensions (MM)
Figure 3-42: Clearance Distance Behind the Display (Panel Mount)
Figure 3-43: Panel Mount Hole Dimensions (MM)
Figure 3-44: Panel Mounting C-Nav1000 Display
Figure 3-45: C-Nav1000 Display Panel Mounted
IALA GPS System
IALA Receiver (MBX-3S, MBX-4)
Figure 3-46: MBX-4 Receiver with Mounting Bracket (Top Mounted)
Figure 3-47: Bottom-View MBX-4 with Mounting Bracket (Bottom Mounted)
Figure 3-48: IALA Receiver Mounting Bracket Dimensions
IALA Whip Antenna Dimensions
C-Navigator II
C-Navigator II Control and Display Unit
Figure 3-49: C-Navigator II Display (Front View)
Figure 3-50: C-Navigator II Side-Panel Connectors
Figure 3-51: C-Navigator II Power Supply
C-Navigator II Mounting Options
Figure 3-52: RAM 100 75 VESA Base (W/ Steel Reinforce) / RAM-D-246U-IN1
Figure 3-53: RAM Double Socket Arms
Figure 3-54: RAM 11" X 3" Base (W/ Steel Reinforce) / RAM-D-111B-IN1U (Left)
Figure 3-55: Flat Screen Table Stand (for C-Navigator II) / CHIFSB018BLK
Figure 3-56: Tilting VESA Wall Mount (for C-Navigator II) / PEEST630
Figure 3-57: Front Mount Kit (for C-Navigator II) / SYNIWO-6710-7CRBR2
Figure 3-58: 19" Mounting Kit (for C-Navigator II) / SYNIWO-6710-7CBR9
Figure 3-59: C-Navigator II (Side USB-Port Model) Outline Diagram (MM)
Figure 3-60: C-Navigator II Cut-Out Diagram (MM)
Figure 3-61: C-Navigator II Rev. a (Front USB-Port Model) Outline Diagram (MM)
C-Navigator II LCD Touch-Screen Care and Cleaning
Chapter 4 Hardware Accessories
Huber + Suhner Lightning Protectors
Model No. 3403.17.0045 Specifications
Model No. 3403.17.0045 Dimensions
Figure 4-1: Huber + Suhner Model No. 3403.17.0045
Model No. 3402.17.0070 Specifications
Model No. 3402.17.0070 Dimensions
Figure 4-2: Huber + Suhner Model No. 3402.17.0070
Huber + Suhner Lightning Protector Mounting Instructions
MOXA Converters
Tcc-80I
TCC-80I Specifications
TCC-80I Dimensions
Tcc-82
Figure 4-3: Moxa TCC-80I Converter Dimensions
TCC-82 Specifications
TCC-82 Dimensions
Figure 4-4: TCC-82 Converter Dimensions
Times-Microwave LMR400 Coaxial Cable
LMR400 Specifications
LMR400 Connectors
Figure 4-5: LMR400 Attenuation Vs. Frequency Graph
Figure 4-6: LMR400 Connectors
Chapter 5 Technical Reference and Interface Guide
Coaxial Cable
Terminating Coaxial Cable (Times Microwave Systems)
Figure 5-1: Components for Termination of Coaxial Cable
Figure 5-2: Prep/Strip Tool (Large End)
Figure 5-3: Duburring Tool
Figure 5-4: Prep/Strip Tool (Smaller End)
Figure 5-5: RMA Flux Application
Figure 5-6: Soldering
Figure 5-7: Connector Installation
Figure 5-8: Ferrule Crimping
Coax-Seal® Weather Sealant Installation
Figure 5-9: RG-59U Coaxial Cable
Figure 5-10: Coaxial Cable with Barrel Connector
Figure 5-11: Coax-Seal Roll
Figure 5-12: Coax-Seal Application
Figure 5-13: Coaxial Cable Fully Sealed
Figure 5-14: Coax-Seal Cross-Section
Table 4-1: Coax-Seal Product Specifications
Chapter 6 Glossary
Troubleshooting
Abbreviations
Definitions
Figure 6-1: DTE to DCE RS-232 Pin Assignments
Advertisement
Quick Links
1
Contact Information
2
C-Nav and Global Navigation Satellite Systems
3
Troubleshooting
Download this manual
DGNSS Systems Hardware Guide
www.cnavgnss.com
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Need help?
Do you have a question about the 1000 and is the answer not in the manual?
Ask a question
Questions and answers
Related Manuals for C-Nav 1000
Car Navigation system C-Nav 1000 R4 Installation Manual
Gnss receiver (82 pages)
Car Navigation system C-Nav IALA Hardware Reference Manual
Dgnss navigation satellite systems (99 pages)
Summarization of Contents
Chapter 1 Overview
GNSS Systems and Accuracy
Explains C-Nav system, DGNSS, error sources, accuracy measures, and values.
C-Nav Subscription Service
Details the global distribution of SBAS corrections for high-precision positioning.
Accessing C-Nav Subscription Service
Provides steps and information needed for subscribing to C-Nav services.
L-band Correction Signal Identification
Identifies L-band identifiers for tracking and decoding C-Nav GNSS/GPS corrections.
Chapter 2 Installation Guide
Antenna Installation Notice and Guidelines
Provides critical guidance for hardware installation for optimal performance and safety.
Standard Antenna Installation Procedures
Details critical antenna placement for good system performance and optimal location selection.
Coaxial Cable Management and Installation
Covers proper routing, installation, and termination of coaxial cables for communication.
Lightning Protection and Receiver Installation
Advises on surge protection, receiver mounting, and location selection for GNSS systems.
Chapter 3 C-Nav DGNSS Hardware Specifications
C-Nav3050 Product Specifications
Details physical, environmental, I/O, and antenna specs for the C-Nav3050 receiver.
C-Nav1010 Product Specifications
Provides physical, environmental, I/O, and antenna specs for the C-Nav1010 receiver.
C-Nav2050 Product Specifications
Lists physical, environmental, I/O, and antenna specs for the C-Nav2050 receiver.
C-Nav1000 Product Specifications
Covers C-Nav1000 receiver, display, and antenna specifications and mounting.
IALA GPS System Receiver Details
Details operational and mechanical specs for the IALA Receiver MBX-3S/MBX-4.
C-NaviGator II Hardware and Mounting
Covers C-NaviGator II unit specs, connectors, power, mounting options, and screen care.
Chapter 4 Hardware Accessories
Huber + Suhner Lightning Protectors
Provides specifications and mounting instructions for Huber + Suhner lightning protectors.
MOXA Converters and LMR400 Cable
Details specs for MOXA converters and LMR400 coaxial cable, including connectors.
Chapter 5 Technical Reference and Interface Guide
Coaxial Cable Termination and Sealing
Step-by-step guide for terminating coaxial cables and using Coax-Seal for weatherproofing.
Chapter 6 Glossary
Troubleshooting GNSS Performance and Settings
Offers guidance on improving GNSS accuracy, resolving common issues, and managing settings.
Troubleshooting Common Issues
Addresses intermittent GPS loss, interference, cable issues, and correction availability.
Abbreviations and Definitions
Provides a comprehensive list of abbreviations and technical definitions used in the manual.
Table of Contents
Print
Rename the bookmark
Delete bookmark?
Delete from my manuals?
Login
Sign In
OR
Sign in with Facebook
Sign in with Google
Upload manual
Upload from disk
Upload from URL
Need help?
Do you have a question about the 1000 and is the answer not in the manual?
Questions and answers
