Summarization of Contents
PRECAUTIONS
If you notice any abnormality
Turn off amplifier if abnormal smells, smoke, dropped objects, or visible damage occur.
Do not open
Contains no user-serviceable parts. Do not attempt to disassemble or modify internal parts.
Water and Fire Warnings
Avoid rain, dampness, liquids, and open flames near the product to prevent damage or fire.
Hearing Loss
Turn amplifier ON last and OFF first to prevent hearing loss and speaker damage.
CAUTION
Location and Connection
Place on stable surface, keep from children, avoid corrosive environments, disconnect cables before moving.
Handling Cautions
Avoid inserting fingers into openings, match amplifier power to speaker capacity, avoid clipping and distortion.
NOTICE
Handling and Maintenance
Avoid dust, vibration, extreme temperatures, placing face down, touching drivers, and ensure correct impedance matching.
Connectors
Use only Neutrik NL4 plugs for speakON connectors.
Information
About This Manual
Illustrations are for instructional purposes; company names are trademarks.
About Disposal
Product contains recyclable components; contact local authorities for disposal.
Main Features
Included Accessories
Lists items included with the product, such as the Owner's Manual.
Optional Accessories (sold separately)
Lists optional accessories like wheels and speaker covers available for purchase.
Functions
Dual Pole Sockets
Compatible with 35 mm diameter poles and M20 screws for mounting.
Feet Cups
For aligning stacked speakers by their rubber feet.
Wheel Mounting Screws
Used for installing optional SPW-1 wheels; removing them causes air leaks.
Input/Parallel Jacks
speakON jacks (Neutrik NL4) for connecting input and parallel signals, wired to 1+/1- contacts.
Output Jack
speakON jack for full-range speakers or cardioid mode, receiving signals via 2+/2- and routing to 1+/1-.
Connection
Wiring
How to wire speakON plugs for CXS and output jacks, including full-range or cardioid mode signals.
Parallel Connection of Speakers
Connect CXS units in parallel, ensuring amplifier load impedance compatibility (4 ohms total for two units).
Invalid Connection
Warning against connecting multiple signals to input/parallel jacks simultaneously to prevent short circuits.
Selection and Settings of Processors and Amplifiers
Basic Setting Example
Illustrates two methods for connecting a CXS and full-range speaker to a 2-channel amplifier.
Specifications
General Specifications
Details system type, frequency range, impedance, power rating, sensitivity, dimensions, and connectors.
