Denon DCM-270 Specification

NEW MODEL INFORMATION
High Performance CD Auto Changer with HDCD Decoder
The DCM-370, a 5-disc carrousel CD changer equipped with an HDCD decoder, lets you play both regular CDs and those that
have been recorded in the HDCD format, to enjoy exceptionally high sound quality. The DCM-370 includes a Coaxial Digital Out
put to accommodate a wide range of uses and a Remote Control IN/OUT interface that enables integrated remote controller.
The DCM-370 and DCM-270 both feature DENON's newly-developed 5-disc changer mechanism for smooth, quiet operation.
HDCD Decoder (DCM-370)
HDCD represents encoding/decoding technology that dras-
tically reduces digital recording distortion while retaining com-
patibility with the existing CD format. HDCD uses Peak
Extension and Low-level Extension technology to convert 24-
bit data to the 16-bit data format of existing CDs without sac-
rificing the high quality of 24-bit sound. This technology pre-
vents the sound from becoming distorted during peak peri-
ods, and boosts the low-level signals to improve the S/N ratio
for a substantially richer dynamic range.
Advanced Multilevel Noise Shaping DAC
The DCM-370/270 feature a Multilevel Noise Shaping
DAC. This multi-level modulation powerfully removes the
adverse effects of jitter, and because it is built into the output
amp, a clean analog output with supressed high-frequency
interference can be directly obtained.
8-Times Oversampling Digital Filter
Increasing the oversampling frequency by a factor of eight
makes possible an extraordinary degree of attenuation and
reduces frequency irregularities in the audio range to an
absolute minimum.
Remote Control IN/OUT (DCM-370)
When the DCM-370 is cable connected to an amplifier or
receiver that supports the Remote Control IN/OUT feature, you
can operate the DCM-370 via the remote sensor on the amplifier
or receiver. This feature is very handy when the DMC-370 is
placed in another room.
Synchronized Recording Function
Full Selection of Program Playback
Both the DCM-370/270 let you combine up to 32 tracks
from the five or fewer CDs which are loaded.
DENON ELECTRONICS
DIVISION OF DENON CORPORATION (USA)
222 NEW ROAD, PARSIPPANY, NEW JERSEY 07054, USA
TEL: 973-396-0810 www.del.denon.com
DENON CANADA INC.
17 DENISON STREET, MARKHAM ONTARIO, CANADA L3R 1B5
TEL: 905-475-4085
DCM-370/270
DCM-270
3-Mode Random Playback
Full Random / Program Random /Disc Sequential Random
Intelligent Disc Scan
The Disc Skip button can rotate the carousel tray clockwise
or counter-clockwise when searching for a disc. (Counter-
clockwise rotation is operable only by remote controller.)
Coaxial Digital Output (DCM-370)
20-Selection Music Calendar Display
Large, Easy-to-use-read FL Display
Specification
Audio Section
Frequency response............ 2 Hz - 20 kHz ..... 2 Hz - 20 kHz
Dynamic range .................... 100 dB ................ 98 dB
Signal-to-noise ratio ............ 112 dB ................ 108 dB
Total harmonic distortion ..... 0.0025 % ............ 0.0030 %
Channel separation ............. 98 dB .................. 96 dB
Line out level (Variable)....... 0.2 - 2.0 V rms.... 0.2 - 2.0 V rms
Digital Output....................... Coaxial ............... —
General (DCM-370/270)
Power supply....................... AC 120 V, 60 Hz
Power consumption............. 15 W
Dimensions ......................... 434 (W)x 116 (H) x 398 (D) mm
Weight ................................. 6.0 kg, 13.2 lbs
LABRADOR, S.A. DE C.V.
ZAMORA NO. 154, COL. CONDESA, MEXICO, D.F.C.P. 06140
TEL: 286-5509/79
NIPPON COLUMBIA CO., LTD.
14-14,AKASAKA 4-CHOME, MINATO-KU, TOKYO 107-8011, JAPAN
Denon Home Page Address: http://www.denon.co.jp
5-Disc CD Auto Changer
DCM-370 DCM-270
17.1" (W)x 4.6" (H) x 15.7" (D)
*Design and specifications are subject to change without notice.
