REMVR185KIT
Remote Control Kit
WB
TUN/CH
VOL
MODE
SAT
BND
Screw
Mounting the Base
1. Detach remote from base/strap by pressing the release button and pull-
ing up.
2. Remove the two screws on the base that appear when the remote is
removed.
3. Position strap around steering wheel, and pull tight. Replace plate and
screws.
4. Insert battery (Lithum 2032 3-volt) into remote contol, and reinstall the
remote onto the base/strap.
Installing the IR Sensor
Select a mounting location close to the steering wheel, and drill a 21/64 hole for the 3.5
mm. jack to pass through. Route the infrared sensor wire through the hole, secure the sen-
sor with double-sided sticky tape and connect to the car radio via the 3.5 mm. jack on the
back of the unit.
Strap
Volume
Mode
Band
Satellite
Steering Wheel Remote Control
This remote control mounts to the steering wheel and operates the basic functions of the car
radio, including volume, tuning, mode, band, satellite and weather band.
Infrared Sensor
3.5 mm Jack
(21/64 hole or 9.2 mm drill
Weather Band
Tuning/Channel
WB
TUN/CH
VOL
MODE
SAT
BND
VR185
Release Button
Strap
