Page 1: Table Of Contents
Appendix Printing Data through Infrared Communication Printing Photographs Directly from a PictBridge Compliant Device Printing Photographs Directly from a Canon Bubble Jet Direct compatible Digital Camera Notes on Handling the Interface Between the Devices (for Windows Users) For Further Details... - Page 2 ® International ENERGY STAR Program ® As an ENERGY STAR Partner, Canon Inc. has determined that this product meets the ENERGY STAR guidelines for efficiency. ® The International ENERGY STAR Office Equipment Program is a global program that promotes energy saving through the use of computer and other office equipment.
-
Page 3: Preface
Power Cord * A USB cable is necessary to connect the printer with your computer. Recommended specification is Canon or other computer manufacture cable, up to 5 meters in length. Introduction This Quick Start Guide uses the following symbols to indicate important information. Always observe the instructions indicated by these symbols. -
Page 4: Setting Up
Setting Up 1 Preparing the Printer Place the printer on a flat surface. Remove the shipping materials from the printer. 2 Connecting the Printer and Power Supply Universal AC adapter Power cord Power cord specifications differ for each country. • Never attempt to plug the power cord into the power outlet or unplug the power cord when your hands are wet. -
Page 5: Installing The Print Head
Follow the steps below to install the printer driver correctly. Plug the power cord into the Universal AC Adapter. Plug the DC plug into the printer. Plug the power cord into the power outlet. 3 Installing the Print Head Open the Paper Support and the Paper Output Slot Cover as shown. -
Page 6: Print Head
Press the Lock Button, then raise the Lock Lever Lock Lever. Do not touch internal parts other than the Lock Lever. Lock Button Remove the Protective Cap from the Print Head. Print Head Nozzles • Do not touch the Print Head Nozzles. -
Page 7: Installing The Ink Tanks
Lock the Print Head into place by lowering the lever. Press down the Lock Button until it clicks. Do not touch the Lock Lever once the Print Head has been installed. 4 Installing the Ink Tanks • For safety reasons, store ink tanks out of the reach of small children. •... -
Page 8: Loading Paper
Press the until it clicks into place. Use the same procedure to install the color ink tank in the front slot. Close the Print Head Cover. Wait until the preparatory operation is complete: it takes about 2 minutes. 5 Loading Paper Loading A4 (Letter) Size Plain Paper Paper Support Paper... -
Page 9: Installing The Printer Driver
6 Installing the Printer Driver Use USB cable. Recommended: Canon or other computer manufacturer cable, up to 5 meters in length. Installing the Printer Driver – Windows • When performing infrared communication, requirements for using the computer must be satisfied. -
Page 10: The Screen
Turn off the printer. Turn on the computer and start Windows. If any applications automatically run, quit them. Disable any virus detection programs. Do NOT turn the printer on at this stage. Place the Setup Software & User’s Guide CD-ROM in the CD-ROM drive. •... - Page 11 When the screen shown on the left appears, ensure that the printer is connected to the computer. When performing infrared communication, make the IrDA port of each other’s device stand opposite to each other. Distance between IrDA ports should be 80 cm or less.
- Page 12 When the screen shown on the left appears, click Exit. If a message prompting you to restart the computer appears, click Restart. If ruled lines are displaced or the print result is unsatisfactory, align the Print Head. Refer to “Aligning the Print Head” in the User’s Guide. •...
- Page 13 Installing the Printer Driver – Macintosh • Do not remove or insert the USB cable during installation, as this may result in the computer or printer not operating normally. • Before installing the driver, disable all virus detection programs and automatically loading programs or remove them from your system folder.
- Page 14 Follow the instructions displayed on the screen. When the screen shown on the left is displayed, click Easy Install. When you select Easy Install, the items included in the CD-ROM are installed automatically. To select particular items to install, click Custom Install and follow the instruction on the screen.
-
Page 15: Basic Operations
• If you detect smoke, unusual smells or strange noises around the printer, immediately switch the printer off and always unplug the printer. Contact your local Canon service representative. • To avoid injury, never put your hand or fingers inside the printer while it is printing. -
Page 16: Basic Print Settings
Click this for a more detailed explanation of the functions in the tab (This may not appear in Windows XP or Windows 2000. If this happens, click Start and select All Programs (or Programs), Canon iP90 and Guide). (6) ? Click this to change the cursor shape to “?”. -
Page 17: Printing With Macintosh
Printing with Macintosh Adjusting the print settings according to your needs allows you to produce better quality prints. Printing Open the Page Setup dialog box in your application. On the File menu, click Page Setup. Check the application’s user’s manual for the actual procedures. Specify the page setup, then click OK. -
Page 18: Page Setup
Page Setup Use the Page Setup dialog box to specify the Paper Size settings. Select paper size you wish to use. Basic Print Settings For the best print quality, specify the minimum requirement settings in the Print dialog box. Select Quality &... -
Page 19: Print Head Maintenance
Print Head Maintenance If Blurring Occurs or If a Specific Color Does Not Print Perform Print Head cleaning to improve the print quality. Ensure that the printer is turned on and follow the instructions below. Windows Open the printer driver settings screen and click the Maintenance tab. Click Cleaning. (1) Click Start and select Control Panel, Printers and Other Hardware and Printers and Faxes (For non-Windows XP users, click Start, and then select Settings and Printers). - Page 20 Install the new ink tank. Close the Print Head Cover when finished. When you enable the low ink warning, reset the ink counter of the ink tank installed. Refer to the User’s Guide for more detailed procedures and information about maintenance.
-
Page 21: Appendix
Appendix Printing Data through Infrared Communication If you have a computer, PDA or mobile phone with an Infrared Port for wireless data communication, you can print data with a cordless connection with the printer. You can also print images, an address book, schedule, or memos received from a PDA (Personal Digital Assistance) or mobile phone in a specified format through infrared communication. -
Page 22: Requirements For Infrared Communication With The Mobile Phone
You can select the media type, page size, layout, and borderless printing in the Canon iP90 Setup Utility when printing from a PDA or mobile phone. Before using the Canon iP90 Setup Utility, you must connect this printer to your computer with a USB cable and install the printer driver and the Canon iP90 Setup Utility. - Page 23 Canon Utilities, Canon iP90 Setup Utility and Canon iP90 Setup Utility. Macintosh Open the Applications folder, and then double-click the Canon iP90 Setup Utility folder and the Canon iP90 Setup Utility icon. Specify the paper size and layout. Changing the Photo Print Settings (1) Click Infrared / Bluetooth connection Print Settings tab.
-
Page 24: Performing Infrared Communication
Changing the Document Print Settings (1) Click Infrared / Bluetooth connection Print Settings tab. (2) Click Change on Document Print Settings. The Document Printing dialog box appears. (3) Select the printing type for the document. Bible, Mini 6-hole, A5 paper are used for a personal organizer. -
Page 25: Printing Photographs Directly From A Pictbridge Compliant Device
• Canon Bubble Jet Direct allows you to print photos from a Canon Bubble Jet Direct compatible (PictBridge incompatible) digital camera or digital camcorder without a computer by simply connecting the digital camera or digital camcorder to this printer. -
Page 26: Connecting To A Pictbridge Compliant Device
To connect a PictBridge compliant device to this printer, use the USB cable supplied with the device. Do not connect any equipment other than PictBridge compliant devices or Canon Bubble Jet compatible camera to the Direct Print Port of the printer. If you do so, electric shock, fire, or damage to the device could result. -
Page 27: Default Device Settings
The settings explained on the following pages cannot be made on some devices. If any setting cannot be made, the default setting explained above is used. Names of settings that are displayed on the Canon PictBridge compliant device are used in the description given below. - Page 28 Fast Photo Photo Paper Pro *1 This size can be selected only for Canon PictBridge compliant devices (Note that it can not be selected for some models). *2 This paper is exclusively used to print photo seals. When printing on sticker paper, select “10x15cm/4"x6"”...
-
Page 29: Printing Photographs Directly From A Canon Bubble Jet Direct Compatible Digital Camera
Printing Photographs Directly from a Canon Bubble Jet Direct compatible Digital Camera The following is a list of media types that can be set on a Canon Bubble Jet Direct compatible digital camera along with their limitations when connected to this printer. -
Page 30: Notes On Handling The Interface Between The Devices (For Windows Users)
Notes on Handling the Interface Between the Devices (for Windows Users) If installation of the printer driver does not proceed as explained in this Quick Start Guide, there may be a problem of interface between the computer and the printer. Try reinstalling the printer driver. -
Page 31: For Further Details
For more information, refer to the User’s Guide. The User’s Guide is an HTML manual you can browse through on your computer. User’s Guide Contents • Printer parts and their function • Using the Canon iP90 Setup Utility • Further printing techniques • Troubleshooting • Printing media •... - Page 32 BJ Printer Driver Systems Requirements For Windows • Use a computer equipped on which Windows XP, Windows 2000, Windows Me, or Windows 98 can operate. • USB* interface or IrDA ver 1.1 • CD-ROM drive • Available hard-disk space for printer driver installation (including temporary files) Windows XP/Windows 2000: 150MB Windows Me/Windows 98: 65MB...
-
Page 35: Regulatory Information
Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or modifications should be made, you could be required to stop operation of the equipment. Canon U.S.A., Inc. One Canon Plaza Lake Success, NY 11042... - Page 36 The following ink tanks are compatible with this printer. For details on ink tank replacement, refer to “Print Head Maintenance” in this guide. QA7-3464-V01 ©CANON INC.2005 PRINTED IN VIETNAM...
