  • Page 1 ...is all you need HIGH POWER AMPLIFIER SERIES...
  • Page 2 170dB. Please observe all local sound ordinances while listening to your EXCURSION System. EXCURSION Intl. acceptss no liability for hearing loss, bodily injury, or property damage due to the result of use or missuse of this product.
  • Page 3 HXA SPECIFICATIONS...

  • Page 4: Front Panel Layout

    EXCURSION FRONT PANEL LAYOUT Fig 1. 4-ch amplifier panel layout 90RMS x 4CH HIGH POWER MINI CAR AMP Fig 2. 2-ch amplifier panel layout Fig 3. Mono amplifier panel layout 12 13...

  • Page 5: Rear Panel Layout

    REAR PANEL LAYOUT Fig 1. 4-ch amplifier panel layout (HXA65 / HXA 85 - 8GA SPK and 4GA POWER allen screw Terminal) Fig 2. 2-ch amplifier panel layout (HXA30 / HXA 40 - 8GA SPK and 4GA POWER allen screw Terminal) Fig 3.

  • Page 6: Control Functions

    The Gain controle will match the amplifiers sensitivity to the provided source unit signal voltage. 5. X-Over Mode Switch This Switch select between 3 Options of operating frequency range of your Excursion Amplifer 5.1 HPF - High Pass filter the unwanted low frequency range from your audio signal.

  • Page 7: Installation Precautions

    WARNING: HXA Amplifiers need external Fuse not less than 12inch (30cm) from Power terminal. Please follow the maximum Fuse recommendation from Excursion HXA Specifications. See Page 2 Note: We have designed 4GA+0GA Terminals to fit Hollywood Energetic HPST Adapters = DUAL IN.

  • Page 8: Wiring Diagram

    EXCURSION WIRING DIAGRAM Fig 1. HXA 45 / HXA 65 / HXA 85 wiring ( 4 Channel Mode) RCA LOW LEVEL or SPEAKER HIGH LEVEL signals via optional XML Adapter 90RMS x 4CH HIGH POWER MINI CAR AMP...
  • Page 9 WIRING DIAGRAM Fig 2. HXA 45 / HXA 65 / HXA 85 wiring ( 3 Channel Mode) RCA LOW LEVEL or SPEAKER HIGH LEVEL signals via optional XML Adapter 90RMS x 4CH HIGH POWER MINI CAR AMP...
  • Page 10 EXCURSION WIRING DIAGRAM Fig 3. HXA 20 / HXA 30 / HXA 40 wiring ( 2 Channel Mode) RCA LOW LEVEL or SPEAKER HIGH LEVEL signals via optional XML Adapter...
  • Page 11 WIRING DIAGRAM Fig 4. HXA 20 / HXA 30 / HXA 40 wiring ( 1 Channel Mode) RCA LOW LEVEL or SPEAKER HIGH LEVEL signals via optional XML Adapter...
  • Page 12 EXCURSION WIRING DIAGRAM Fig 5. HXA 1K / HXA 2K / HXA 3K / HXA 4K / HXA 5K wiring ( 1 Channel Mode) 8Ohm 8Ohm 8Ohm 8Ohm * Equivalent impedance load can not be less according minimum load of the individual HXA Mono Amplifier model.
  • Page 13 WIRING DIAGRAM Fig 5. HXA 1K / HXA 2K / HXA 3K / HXA 4K / HXA 5K wiring ( 2 Amplifier BRIDGE Mode - SIGNAL and SPEAKER ) RCA LOW LEVEL signals or SPEAKER HIGH LEVEL via optional (XML) RCA Adapter MASTER SLAVE 4Ohm Min Load : HXA1K...

  • Page 14: Troubleshooting

    EXCURSION TROUBLE SHOOTING Symptom Possible Remedy Amplifier Check to make sure you have a good ground connec on. will not Check that there is ba ery power on the (+)terminal . power up Check all fuses, replace if necessary .
  • Page 15 EXCURSION Intl. offers limited warranty on EXCURSION products under normal use on the following terms: EXCURSION Amplifiers are to be free of defects in material and workmanship for a period of one year This warranty applies only to EXCURSION products sold to consumers by Authorizied EXCURSION Dealers in Germany.
  • Page 16 ...is all you need EXCURSION - A Division of CHPW All Rights reserved - Intl. Trademark No: 010 640 597 Friedrich-Ebert-Str. 42 - D-92637 Weiden / Germany Tel: (+49) 961-416 04 20 - Fax: (+49) 961-46 04 41 EASCA UROPEAN...
