SERVICE MANUAL
Ver. 1.4 2006.03
TE
L 13942296513
System
Compact disc digital audio system
Laser diode properties
Emission duration: Continuous
Laser output: Less than 44.6 µW (This output is the value measured at a
distance of 200 mm from the objective lens surface on the optical pick-up
block with 7 mm aperture.)
Power requirements
• Two LR6 (size AA) batteries: 1.5 V DC × 2
• AC power adaptor (DC IN 4.5 V jack):
220 V, 50 Hz (NE005: EE,EU8/NE006: EU8, EE, E18)
120 V, 60 Hz (C&SA, MX)
Dimensions (w/h/d) (without projecting parts and controls)
Approx. 139.8 × 28.8 × 139.8 mm
Mass (excluding accessories)
Approx. 200 g
Operating temperature
5°C - 35°C
MPEG Layer-3 audio coding technology and patents licensed from
Fraunhofer IIS and Thomson.
Design and specifications are subject to change without notice.
Supplied accessories
AC power adaptor (1)
(NE005: EE, EU8/NE0050: C&SA, MX/NE006: EU8, EE, E18)
Headphones (1)
Remote control (1) (supplied with D-NE006 only)
