What does the light by the diag button mean?
This light, which is green when lit, is located next to the diag button
on the PRO/100 device. It should be OFF for 10 Mbps systems and ON
for 100 Mbps systems.
How should switches be set?
For Token Ring PRO print servers only
Network speed
Autosense speed
Set for 4 Mbps
Set for 16 Mbps
For Ethernet PRO and PRO/100 print servers
Doesn't apply. Switches are reserved for future use.

Printing problems

Can't print (start here for most problems)
Parallel port speed may be incorrect. Parallel port speed should match
the printer speed. See the following table.
Parallel Port
Speed
Low
Medium
High
Software
To set port speed:
• In Netport Manager, click the Properties button.
• Using telnet, access the Telnet main menu and choose
Port Configuration.
• From your web browser, enter the IP address of your
NetportExpress print server and choose Properties.
Printer is off or is offline. Make sure the printer is operational. Print a
self-test page to make sure.
NetportExpress print server may not be configured correctly. Check
Status in Netport Manager.
34
Switch 1
Up
Down
Down
Type of printer using that speed
HP LaserJet 3* or lower, dot matrix, or inkjet
printers
Default setting. HP LaserJet 4* or equivalent, most
other printers
HP LaserJet 5si* (24 ppm) or faster printers
Use only if no other speed works.
Switch 2
Up
Down
Up
