Summarization of Contents
General Information
Quality and Safety
Ensuring compliance with safety regulations DIN 19045 and material standards DIN 4102.
Warranty Information
Details the 24-month warranty period for production defects.
Care Instructions
Guidance on protecting and cleaning the screen fabric and maintenance-free parts.
MAGNUM 210, 300, 360 Systems
Details for MAGNUM 210, 300, 360 systems regarding mounting and load.
MAGNUM 360 Elektromat Drive
Information on connecting the Elektromat motor for MAGNUM 360.
Methods of Installation
QuickMount Brackets
System for mounting INLINE roll-up screens, included as standard.
Mounting Plate for Ceiling Mounting
Optional mounting plates for INLINE screens for ceiling mounting.
Universal Mounting Brackets
Standard brackets for INLINE SK16x16cm and MAGNUM SK21x21cm casings.
Wall / Ceiling Brackets
Versatile brackets for INLINE SK16x16cm, usable for wall or ceiling mounting.
Wall Brackets VARIO
Adjustable wall brackets for INLINE SK9x8.5cm and SK12.5x12cm with T-slots.
Ceiling Brackets VARIO
Adjustable ceiling brackets for INLINE SK9x8.5cm and SK12.5x12cm with T-slots.
Recessed Box for Suspended Ceilings
Pre-installable recessed box for ceiling integration, minimum height 92mm.
Recessed Box with Mounting Set for Suspended Ceiling
Details for installing the recessed box with mounting set for suspended ceilings.
Projection Screen for Ceiling Integration
Screen designed for ceiling integration, easily dismounted.
Mounting Set VARIO for Suspended Ceiling
Components for attaching the screen for ceiling integration in suspended ceilings.
Electrical Installation
Single Control - 230V (House Wiring)
Wiring instructions for individual 230V motor control in domestic installations.
Media Control Panel (Dry Contact)
Requirements for controlling screens via media control panel, needing a motor control unit.
Wiring and Control System Rules
Guidelines to prevent overload and destruction of limit switches and motors.
Stop Position Adjustment
Motor Left / Fabric Back & Motor Right / Fabric In Front
Adjusting stop positions for motor left (back fabric) and motor right (front fabric).
Motor Left / Fabric In Front & Motor Right / Fabric Back
Adjusting stop positions for motor left (front fabric) and motor right (back fabric).
Accessories
Inis Uno Wall Switch
Wall switch for controlling a motor drive; surface and flush mounted.
Centralis Uno IB Media Control
Motor control unit-switch combination with fuse, programmable positions.
CD 1x1 N Motor Control Unit
Motor control unit with dry contacts and fuse for DIN-rail mounting.
SOMFY Radio Control Sets
Radio remote control sets with receivers and transmitters for flush or surface mounting.
Operating Instructions
Crank Mechanism
Manual operation instructions for the crank mechanism.
Spring-Roller Mechanism with SOFT-REWIND
Instructions for unwinding and rewinding the spring-loaded roller mechanism.
