Thank You
for your purchase of one of the finest outboards available.
You have made a sound investment in boating pleasure.
Your outboard has been manufactured by Mercury Marine, a
world leader in marine technology and outboard
manufacturing since 1939. These years of experience have
been committed to the goal of producing the finest quality
products. This led to Mercury Marine's reputation for strict
quality control, excellence, durability, lasting performance,
and being the best at providing after the sale support.
Please read this manual carefully before operating your
outboard. This manual has been prepared to assist you in
the operation, safe use, and care of your outboard.
All of us at Mercury Marine took pride in building your
outboard and wish you many years of happy and safe
boating.
Again, thank you for your confidence in Mercury Marine.
EPA Emissions Regulations
Outboards sold by Mercury Marine in the United States are
certified to the United States Environmental Protection
Agency as conforming to the requirements of the regulations
for the control of air pollution from new outboard motors.
This certification is contingent on certain adjustments being
set to factory standards. For this reason, the factory
procedure for servicing the product must be strictly followed
and, wherever practicable, returned to the original intent of
the design. Maintenance, replacement, or repair of the
emission control devices and systems may be
performed by any marine engine repair establishment or
individual.
Engines are labeled with an Emission Control Information
decal as permanent evidence of EPA certification.
The engine exhaust from this product contains chemicals
known to the state of California to cause cancer, birth
defects or other reproductive harm.
eng
WARNING
!
