Summarization of Contents
General Information and Safety
Receipt of Goods
Inspect the stove carefully upon delivery and report any damage to the transport company within seven days.
Cool Hands
Use the provided stove glove to safely open the hot fire-door handle.
Manufacturer's Assurance
Product manufactured according to type approval documentation.
Planning Application
Notify local planning authority before installing a stove and chimney.
Inspection
Installation must be inspected by a chimney sweep before the stove is used.
Guarantee Terms
Read guarantee terms to understand requirements for coverage.
Chimney Requirements
Minimum flue diameter 150mm, minimum height 3.5m. Inspect existing chimneys.
Distance from Combustible Surfaces
Maintain specified distances from walls and furnishings to prevent fire.
Load-Bearing Structure
Stove can be placed on ordinary floors; consult chimney sweep for uncertainty.
Fireplace Base Requirements
Stove must be placed on a fireproof base of specified material and dimensions.
Included Items
Delivery includes stove and connection inserts; options available.
Assembly Instructions
Stove Placement
Select a central location for even heat distribution; ensure horizontal floor surface.
Top Connection Assembly
Follow chimney supplier instructions for fitting adapter pipe and flue modules.
Ball/Plummet Stop
Ensure plummet stop is fitted inside the stove insert for chimney sweeping.
Cutting Hole in Chimney
Chisel out chimney hole slightly larger than insert for cementing.
Connecting to Existing Chimney
Steps for connecting stove to a proprietary modular or masonry chimney.
Design Specifications
Details on color, materials, output, efficiency, and weight for different models.
Technical Information
Combustion Air Supply
Air feed to hearth may be direct, via outdoor connection, or indirect.
Outdoor Air Connection
Details on connecting an external air supply for combustion.
Output Control
Explanation of primary air-feed control for open, closed, economy, and nominal positions.
Distances from Wall Surfaces
Diagrams showing required clearance from combustible walls and fire barriers.
Ash Disposal
Procedure for emptying the ash tray, ensuring no embers remain.
Model Dimensions and Features
Camina Art Suprême
Description of the Art Suprême model with two side glass panels.
Camina Art Grace
Description of the Art Grace model with a warming compartment.
Camina Art Etage
Description of the Art Étage model with soapstone panels and decorative grill.
Camina Art Pierre
Description of the Art Pierre model with heat-storage soapstone casing.
Camina Art Moderne
Description of the Art Moderne model with heat-storage soapstone casing.
User Guide and Maintenance
Fuel Selection and Use
Guidelines on suitable fuels, log size, moisture content, and burn rates.
Lighting the Fire
Step-by-step instructions for starting and managing the fire.
Fuel Replenishment
Advice on adding logs to maintain optimal burning and heat.
Everyday Stove Use
Tips for daily operation and adjusting air feed for desired output.
Important Notes
Information on initial smells, gasket checks, cleaning, glass soot, and chimney fires.
