Illustrated Parts List

7000 Watt
Home Generator
System
IPL No. 209234 Rev.C (03/19/2010)
ModeL
040315-0

Advertisement

loading
Need help?

Need help?

Do you have a question about the 040315-0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GE 040315-0

Summary of Contents for GE 040315-0

  • Page 1: Illustrated Parts List

    Illustrated Parts List ModeL 040315-0 7000 Watt Home Generator System IPL No. 209234 Rev.C (03/19/2010)
  • Page 2 exploded View & Illustrated Parts List - Main Unit Item Part # description B191860GS CRADLE 194568GS DUCT 193536GS TRAY-OIL DRAIN 191793GS ADAPTER-ENGINE ALTERNATOR 194728GS KIT-HARDWARE ADAPTER B4300GS BOLT 96796GS WASHER 208103GS SEAL 10 2830598SM TAPTITE 11 187365HGS HHCS-5/16-24 x 9.84 12 207270GS DEFLECTOR-MUFFLER 13 193475GS...
  • Page 3 exploded View & Illustrated Parts List - enclosure Item Part # description Item Part # description 192441AGS PAD-MOUNTING 15 * NUT-5/16-18, FLANGE SERRATED T191852GS BASE 16 200409GS DECAL 208198GS PANEL-SIDE 17 B4300GS BOLT 208197GS PANEL 18 195642GS DECAL 208199GS PANEL-SIDE 19 186643GS DECAL T208787GS...
  • Page 4 exploded View - Control Panel...
  • Page 5 Illustrated Parts List - Control Panel Item Part # description Item Part # description 207903GS BOX-CONTROL PANEL 30 193291GS REGULATOR-NG/LPG 207176GS BOARD-CIRCUIT 31 186151GS FITTING T207012GS PANEL-ACCESS 32 186148GS HOSE-FLEX NG/LPG T201825GS PANEL-CONTROL 33 205955GS FITTING 192445GS SCREW 34 T207901GS SUPPORT RAIL 208789GS BREAKER-CIRCUIT 30A...
  • Page 6 exploded View & Illustrated Parts List - Alternator Item Part # description 209599GS ADAPTER-ALTERNATOR 195430GS ROTOR 206542GS STATOR 193336GS RBC (with O-Ring p/n 189197GS) 86308KGS BOLT 66386GS ASSY-BRUSH 66849GS TAPTITE 81917GS 10 193472GS HARNESS-WIRING 11 192906GS COVER-REAR BEARING 12 74908GS TAPTITE 13 65791GS BEARING...
