Panasonic NE-1064C Service Manual

Service Manual
t
m e n
p l e
S u p
Please fi le and use this Supplement Service Manual together with following Service Manual.
NE-1024T/TC, 1054T/TC, 1064T/TC,ORDER NO. TAMC0103001C2.
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicans.Any attempt to service or repair
the products or products dealt with in this service information by anyone else could result in serious injury or death.
Specifi cation:
Models
NE-1064F APH
NE-1064C CPH
Specifi cations
Power Source: 120V AC Single Phase,60Hz
Power Requirement:
Output:
Microwave Frequency: 2450MHz
6 min.Rotary
Timer:
99 min.99sec. ······································································ for NE-1064F/C & NE-1054F/C
20
Outside Dimensions:
510mm (W) X 360mm (D) X 306mm (H)
13'' (W) X 13'' (D) X 8
Oven Cavity Dimensions:
330mm (W) X 330mm (D) X 205mm (H)
Weight:
PbF This product with PbF
Note:
* NE-1064F APH is based upon NE-1064T APH,the specifi cation and appearance is same, and the main difference is the manufacturer.
* NE-1064C CPH is based upon NE-1064TC CPH,the specifi cation and appearance is same, and the main difference is the manufacturer.
* NE-1054F APH is based upon NE-1054T APH,the specifi cation and appearance is same, and the main difference is the manufacturer.
* NE-1054C CPH is based upon NE-1054TC CPH,the specifi cation and appearance is same, and the main difference is the manufacturer.
* NE-1024F APH is based upon NE-1024T APH,the specifi cation and appearance is same, and the main difference is the manufacturer.
* NE-1024C CPH is based upon NE-1024TC CPH,the specifi cation and appearance is same, and the main difference is the manufacturer.
NE-1064T APH
NE-1064TC CPH
1500W (13.4A)
1000W *
······································································ for NE-1024F/C
1 3
/ '' (W) X 14 / '' (D) X 12" (H)
8 16
1
/ " (H)
16
Approx. 34 lbs /15.4 kg
Specifi cations subject to change without notice.
* IEC705-88 Test Procedure
®
WARNING
!
NE-1054F APH NE-1054T APH
NE-1054C APH NE-1054TC CPH
1500W (13.4A)
1000W *
Approx. 34 lbs /15.4 kg
© 2007 Panasonic Home Appliance Microwave
Oven (Shanghai) Co., Ltd. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
ORDER NO. PHAMOS0702020S1

Microwave Oven

NE-1064F
NE-1064C
NE-1054F
NE-1054C
NE-1024F
NE-1024C
APH (USA)
CPH (CANADA)
NE-1024F APH NE-1024T APH
NE-1024C CPH NE-1024TC CPH
1500W (13.4A)
1000W *
Approx. 34 lbs /15.4 kg
E10
