Panasonic NE-1064F Owner's Manual

Panasonic NE-1064F Owner's Manual

Commercial microwave oven
Hide thumbs Also See for NE-1064F:

Advertisement

Quick Links

Download this manual
Owner's Manual
Commercial Microwave Oven
Model No.
Please read these instructions carefully before using this product and save this manual for future use.
For microwave oven safety reference, please visit FDA's webpage at:
http://www.fda.gov/radiation-emittingproducts/resourcesforyouradiationemittingproducts/ucm252762.htm
© Panasonic Corporation 2020
NE-1064F_AUH_OI.indd
1
NE-1064F
2020/11/13
11:29:08

Advertisement

loading
Need help?

Need help?

Do you have a question about the NE-1064F and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic NE-1064F

Summary of Contents for Panasonic NE-1064F

  • Page 1 Commercial Microwave Oven Model No. NE-1064F Please read these instructions carefully before using this product and save this manual for future use. For microwave oven safety reference, please visit FDA’s webpage at: http://www.fda.gov/radiation-emittingproducts/resourcesforyouradiationemittingproducts/ucm252762.htm © Panasonic Corporation 2020 NE-1064F_AUH_OI.indd 2020/11/13 11:29:08...
  • Page 2 Service Information Serial No. The serial number of this product may be found on the side of the oven. To locate a convenient service agent call Dealer’s Name 1-888-350-9590 Dealer’s Address www.panasonic.com/cmo Date of Purchase - 2 - NE-1064F_AUH_OI.indd 2020/11/13 11:29:08...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS Your microwave oven is a cooking device and you should use as much care as you use with a stove or any other cooking device. When using this electric appliance, basic safety precautions should be followed, including the following: WARNING 14.
  • Page 4 Using a lower voltage a grounding wire with a grounding plug. The plug must will cause slow heating. Panasonic is NOT responsible be plugged into an outlet that is properly installed and for damage resulting from the use of the oven with grounded.
  • Page 5 How Does The Microwave Work? Absorption Microwaves are a form of high frequency radio waves similar to those used by a radio including AM, FM and During heating, microwaves will be absorbed by food. CB. They are, however, much shorter than radio waves; They penetrate to a depth of about to 1 inches.
  • Page 6 Safety Precautions General Use Food 1. DO NOT tamper with or make any adjustments or 1. HEATING TIMES given in the cooking guide are repairs to door, control panel housing, safety interlock APPROXIMATE. Factors that may affect heating are: switches or any other part of the oven. starting temperature, altitude, volume, size, and shape DO NOT remove outer panel from oven.
  • Page 7 Outline Diagram (1) Digital Display Window (see below) (2) Memory Pads (3) POWER LEVEL Selector Pad (4) PROG Pad (5) DOUBLE QUANTITY (x 2) Pad (6) START Pad (7) STOP/RESET Pad (8) Control Panel (9) Door Safety Lock System (10) Oven Window (11) Oven Lamp (12) Splash Guard/Light Diffuser (13) Warning Label...
  • Page 8 How to Operate Before Operating Make sure the oven is connected to a properly grounded electrical outlet. When the door is closed, the display is still blank. When the door is opened, the display shows “0”. For the detail operation, see the page on each feature. This oven is preset at the factory for the following: 1.
  • Page 9 How to Operate HEATING Open the door and place food in the oven cavity. Close the door. “0” must be showing in the display window. A. Manual Single Stage Heating: This feature gives the user maximum flexibility to set the oven to desired heating time and power level. Ideal for menus that require various heating requirements. Example: To heat for 2 minutes at High Power Display Window •...
  • Page 10 How to Operate C. Programmed Heating: Example: 1 stage; Memory Pad 9 to heat for 3 minutes at HIGH Power Display Window • Press the Memory Pad 9. In Program Lock Mode oven will start without pressing START Pad. See page 14. •...
  • Page 11 How to Operate Programming ― DO NOT OPEN THE DOOR ― Display Window The display window MUST be blank before programming can begin. If any indicator light is illuminated in the digital Display Window: close the door, press STOP/RESET Pad and wait 1 minute until the Display goes blank.
  • Page 12 How to Operate B. Programming Memory Pads for 2 or 3 Stage Heating: Example: To program for 2 minutes at DEFROST for 2 stage heating using Memory Pad Number 5 Display Window 1. Complete Steps 1 to 4 on page 11. •...
  • Page 13 How to Operate C. DOUBLE QUANTITY (x 2) Pad ― For Multiple Portion Heating: Your oven is factory set to automatically double the programmed time for Multiple Portion Heating. You can change appropriate time for DOUBLE QUANTITY. NOTE: “Program Lock” should be cancelled. (See page 14.) Example: To program 30 seconds at HIGH power as multiple portion heating of Memory Pad Number 2 (display must be blank) Display Window...
  • Page 14 How to Operate Other Features A. To Activate Program Lock: Display Window This procedure “Locks” the control panel Memory Pads into their programmed heating times and power levels. DO NOT OPEN THE DOOR. The Display Window must be blank before the Program Lock feature can be activated. •...
  • Page 15 How to Operate C. To Read Program List: Allows you to review all currently programmed Pad Number, heating time and power level for each stage. Display Window 1. Open the door. • While pressing the STOP/RESET Pad, press and hold the START Pad. The Beep Tone setting will show in the display window.
  • Page 16 How to Operate D. To Select Beep Tone Options: The Beep Tone can be set, ON or OFF. Display Window 1. Open the door. • Press the PROG Pad. The display will not change. • Press the Memory Pad 0. •...
  • Page 17 Self Diagnostics Failure Code Explanation This oven monitors its operation and displays a Failure Code in the display window when a problem occurs. What to do when a failure code appears: CODE CAUSE WHAT TO DO * Overcooked food * Press STOP/RESET Pad to stop beep. * Temperature of exhaust air too high * Unplug oven and wait at least 30 minutes before reconnecting.
  • Page 18 Notes - 18 - NE-1064F_AUH_OI.indd 2020/11/13 11:29:19...
  • Page 19 Technical Specifications NE-1064F Power Source 120 V, 60 Hz, single phase Required Power 13.4 A 1,500 W Output* 1,000 W Frequency 2,450 MHz Outer Dimensions ″ x 14 ″ x 12″ (W x D x H) (510 mm x 360 mm x 306 mm) Cavity Dimensions 13″ x 13″ x 8...
  • Page 20 Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102-5490 Panasonic Corporation Web Site: http://www.panasonic.com H00036P21AP A1120-0 Printed in Vietnam NE-1064F_AUH_OI.indd 2020/11/13 11:29:19...
