GENERAL
Installation of this above ground pool is not extremely hard
or confusing, but it is a big job. The secret to installing a
pool so that it will give you years of pleasure is to take the
time to follow instructions and do things right the first time.
Your pool warranty is void if these instructions are not
followed 100%. Read all instructions including accessories
such as filters, pumps, skimmers, decks, etc. prior to
starting. Before you start, check to see that you have the
correct number of parts. Use your parts list which is broken
down by carton. The manufacturer reserves the right to
revise, change, or modify construction of its pools.
NOTE: If a power drill is used during installation,
it should be a variable speed drill used on low
setting. Torque should not exceed 39 inch pounds.
FAILURE TO COMPLY COULD RESULT IN SCREWS STRIPPING OUT.
3 13 R E G I NA AV ENU E, RA H WAY, N E W JE RS E Y 07 065- 4891
Phone: (732) 574-1500 • Fax: (732) 574-1551 • www.swimnplay.com • E-mail: info@swimnplay.com
ROUND
POOL
ASSEMBLY
INSTRUCTIONS
DANGER
DO NOT DIVE OR JUMP
into your pool. Your pool is
approximately 4' deep. It is
not designed for diving
or jumping. If you dive or jump
into your pool you run the risk
of permanent injury or death.
ADULT SUPERVISION REQUIRED
KEEP A CLEAR SPACE
OF AT LEAST 4 FEET
AROUND THE POOL
TO ELIMINATE
THE POSSIBILITY
OF CLIMBING
INTO THE POOL
Part# 420363-21
Alert all visitors
and family of
this and point
out all warning
labels supplied.
