ASSEMBLY INSTRUCTIONS
12 ft.
15 ft.
18 ft.
READ THROUGH AND UNDERSTAND ALL THE STEPS TO THIS INSTALLATION BEFORE
ATTEMPTING TO INSTALL EITHER YOUR POOL OR YOUR DECK.
IF YOUR POOL IS ALREADY INSTALLED IT MAY BE NECESSARY TO LOWER THE WATER
LEVEL IN YOUR POOL DOWN TO 2' TO ENABLE YOU TO PROPERLY INSTALL THIS DECK.
Part # 420867
DECKS
DO NOT DIVE OR JUMP into your pool. Your pool is approximately 4' deep.
It is not designed for diving or jumping. If you dive or jump into your pool
you run the risk of permanent injury or death. Alert all visitors and family
of this and point out all warning labels supplied.
ADULT SUPERVISION REQUIRED
END
R A HWAY, N E W J E RS E Y 07 065- 4891
DANGER
3 13 R E G IN A AV E NU E
Phone: (732) 574-1500
Fax: (732) 574-1551
www.swimnplay.com
E-mail: info@swimnplay.com
Advertisement
Related Manuals for Swim'n Play end deck
Summary of Contents for Swim'n Play end deck
- Page 1 ASSEMBLY INSTRUCTIONS 12 ft. 15 ft. 18 ft. READ THROUGH AND UNDERSTAND ALL THE STEPS TO THIS INSTALLATION BEFORE ATTEMPTING TO INSTALL EITHER YOUR POOL OR YOUR DECK. IF YOUR POOL IS ALREADY INSTALLED IT MAY BE NECESSARY TO LOWER THE WATER LEVEL IN YOUR POOL DOWN TO 2’...
-
Page 2: Local Codes
GENERAL Take time to follow the instructions and do things right the fi rst time. Read all instructions prior to starting. Before you start, check to see that you have the correct number of parts. Use your parts list which is broken down by carton. The manufacturer reserves the right to revise, change or modify construction of their product. -
Page 3: Assembly Drawings
During assemly please note that the ledges on the pool are to be removed where the deck meets the pool. The extension on the front of the deck will replace your pool legde. Please refer to Step 7. LADDER 18’ END DECK LADDER ASSEMBLY DRAWINGS (VIEWED FROM ABOVE) 15’... - Page 4 #2a & #2b CLOSE-UP #4 CLOSE-UP #3 POOL NUTS 1/4” x 20 1/4” x 20 x 1/2” HEX NUT TRUSS HEAD SCREW 15’ END DECK & 18’ END DECK 12’ END DECK CLOSE UP #2b NUTS CORNER POST BRACKET LONG POST 1/2”...
- Page 5 DECK TOP NUTS CLOSE-UP #3 DECK TOP NUTS CLOSE-UP #5 Finally, attach another Long Square Post for the Ladder on either side of your deck in the location illustrated for your deck on the prior page. Choose the location of your ladder depending on which side of the deck will provide the most convenient access to the pool.
- Page 6 Posts (including the Post for the Ladder) using 1/2” Sheet Metal Screws as shown at right. NOTE: On the 12’ End Deck, you must now attach 1 side of remaining 72½” Bottom Support Channel to the outside Posts nearest the pool. See right.
- Page 7 CLOSE-UP #7 CLOSE-UP #7 CLOSE-UP #7 POOL CLOSE UP #8 1/4” x 20 1/4” x 20 x 1/2” HEX NUT TRUSS HEAD SCREW 15’ END DECK & 18’ END DECK 12’ END DECK BOTTOM OF POST ANGLE SUPPORT BOTTOM SUPPORT CHANNEL 1/2”...
- Page 8 CLOSE-UP #13 CLOSE-UP #12 CLOSE-UP #10 POOL CLOSE UP #11 1/4” x 20 1/4” x 20 x 1/2” HEX NUT TRUSS HEAD SCREW 15’ END DECK & 18’ END DECK 12’ END DECK ANGLE SUPPORT 1/2” SHEET METAL SCREW DECK 1”...
- Page 9 DECK CLOSE UP #12 IMPORTANT: ONLY HAND TIGHTEN SCREWS AT THIS TIME For the 15’ and 18’ Decks assemble the Center Patio to the already assembled deck sec- tions using the 1” Round Head Screws and Hex Nuts. For the 12’ Decks assemble the two outside deck sections together using the 1” Round Head Screws and Hex Nuts.
- Page 10 LOCATION A LOCATION C LOCATION A 12’ END DECK For the 12’ End Deck attach the two 75” Bottom Angles to the bottom of the Posts as shown. Use 1/2” Sheet Metal Screws but only hand tighten at this time.
- Page 11 In the locations marked “Location A” (see the previous page), attach Angle Support Bars to the top of the Post and Deck as illustrated in Close-up #16 at right. Also attach Angle Support Bars to the bottom of the Post and the Bottom Support Channel as illustrated in Close-up #17 at right.
- Page 12 This will enable the deck to mount closer to the pool. VIEW FROM ABOVE PLATES CUT COVER 18’ END DECK VIEW FROM ABOVE PLATES CUT COVER 15’ END DECK CUT COVER 12’ END DECK...
- Page 13 a) Assemble and mount the “Ground to Deck” Ladder to the deck using instructions packed inside it’s carton. b) Assemble and mount In-Pool Ladder using instructions packed inside it’s carton. FENSURROUND INSTRUCTIONS Use the illustrations below for reference during the assembly of the Fence Posts as described on the next page.
- Page 14 GENERAL ASSEMBLY ILLUSTRATION Use the General Assembly Illustration below for reference as you assemble the Fensurround. STANDARD POST END POST FENCE BRAKET INSERTED CORNER POST THROUGH POST Before assembling your pool, drill the required holes 7¾” in the Verticals. Simply place the bracket 7¾” from the top of the Vertical. Then, using the Post Bracket as a template, drill through the Vertical using a 5/16”...
- Page 15 Take the Verticals and attach two Fence Post Brackets to each Vertical using the 1/4 x 20 x 3/4” Screws and Washers and Hex Nuts provided as shown. You may now assemble your pool. Assemble the Square Fence Post to the Post Bracket using the ¼”...
- Page 16 Use the illustrations below for reference during attaching the sections of Fence to the Fence Posts as described on the next page.
- Page 17 END POST CORNER POST Attach the Straight Fence Brackets to the top of the Standard Posts simply by inserting the shorter end through the slots in the Post until it stops. Next, press one Post Cap to the top of each Post. Using the illustration for your size deck on the previous page, assemble the Fence Postions.
-
Page 18: Warning Labels
Using the Latch, Latch Bar and Hinges as templates, drill the holes in the locations as illustrated at the bottom. Drill a 5/32 hole for the Latch Bar and Self Closing Hinges. Drill a 7/64 hole for the Latch. Mount the Hinges and the Gate using 1/2” long Self-Tapping Screws so that the Gate swings on to the deck in the direction of the rear fence.
