Summarization of Contents
GENERAL INSTALLATION PROCEDURE
System Design
The success of any car stereo system relies on system design, execution, and setup.
Mounting and Wiring Guidelines
Proper mounting for heat dissipation and routing cables to avoid electrical noise.
Power and Ground Connections
Using sufficient gauge power/ground cable and proper connection techniques for amplifiers.
Safe Connection & Power Up Procedure
Step-by-step guide for safe connection sequence and powering on the audio system.
AMPLIFIER FEATURE DESCRIPTIONS
MT OLYMPUS Series Overview
Unique series features, channel stability, input sensitivities, and crossover filters.
Model-Specific Features
Details X-OVER, SUBSONIC FILTER, PARAMETRIC EQ for specific amplifier models like BOLTAR, JUPITER, HERCULES.
BOLTAR / COLOSSUS PRO 2-CHANNEL AMPLIFIER APPLICATIONS
Full Range Stereo Application
Basic application for 2-channel amplifiers for full range stereo output.
Mono Bridging Application
Illustrates the basic mono bridging method for Hifonics amplifiers.
JUPITER 4-CHANNEL AMPLIFIER APPLICATIONS
4-Channel Full Range System
Shows how to use 4-channel amplifiers as discrete 4-channel full range units.
2 or 3-Channel System
Demonstrates using 4-channel amplifiers for 3-channel systems via mono bridging.
MULTI-AMPLIFIER APPLICATIONS
Front/Rear High Pass with Mono Sub Bass
Combining amplifiers for a full system with front/rear highs and mono sub bass.
HERCULES / ATLAS MONO AMPLIFIER APPLICATIONS
Single Amp Basic Application
Single amp installation procedure for Hercules/Atlas mono amplifiers.
Dual Amp Installation Procedure
Linking two Hercules/Atlas amps for single or dual subwoofer applications.
COLOSSUS DUAL MONO AMPLIFIER APPLICATIONS
Basic Application Overview
Overview of Colossus Dual Mono Block amplifiers' capabilities and configurations.
Independent Channel Operation
Using channels L & R independently for separate subwoofer applications.
Bridged Channel Operation
Bridging channels L & R for single subwoofer applications.
SETTING UP SYSTEMS AFTER INSTALLATION FOR BEST PERFORMANCE
BOLTAR/COLOSSUS PRO / JUPITER Setup
Specific settings for X-OVER, PARAMETRIC EQ, PHASE, and Level Control for these models.
HERCULES/ATLAS/COLOSSUS Setup
Specific settings for Phase, Subsonic, PARAMETRIC BASS EQ, Low Pass, and Level Control.
TROUBLESHOOTING A SYSTEM
Amplifier Diagnostics & Protection
Explains the PROTECT LED and diagnostic system for amplifier faults.
System Operation Issues
Addresses overheating, low output power, blown fuses, and system not turning on.
Noise & Interference Problems
Diagnosing and resolving hiss, electrical interference, and ticking/whine issues.
