CP-1 Digital Audio Environment Processor

Make sure INPUT LEVEL on the CP-1 front panel is turned up. Check the

connections on the rear and make sure signal is going into the CP-1. Check

SOURCE and MONITOR switches and try toggling them in and out.

Check the batteries and make sure that they are inserted correctly. Make

sure that the infrared receiver on the CP-1 front panel above the POWER

switch is not obstructed. If the remote control unit is still not functioning,

RESTORE DEFAULTS as described below.

First verify that signal is coming into the CP-1 by observing the Input Level

meters. Increase VOLUME using the Remote Control and check the Front/

Back and Left/Right balances. Make sure that the rear panel Output Level

controls are turned up. Check all other equipment settings and connections

and verify that the amplifier(s) being fed by the CP-1 are operational.

Adjust the contrast (relative brightness) of the display using the procedure

described on the Quick Reference Guide, and on Page 13 of the Owner's

Manual. If the display is showing strange characters, RESTORE DEFAULTS

as described below.

If severe power surges or sags cause problems with CP-1 memory storage,

or you simply want to start with a clean slate in the User registers, you can

restore factory presets into the User registers with the following procedure.

(This will erase any programs you have stored in the User register, so you

may want to note any settings you wish to re-use before proceeding.)

Turn CP-1 power OFF. While pressing PARAM on the Remote Control,

turn power ON. (Make sure your hand does not block the infrared receiver

on the CP-1 front panel.) Continue holding down PARAM until the display

reads:

Release PARAM and press EFFECT MUTE to clear and reload User regis-

ters, and to restore all factory settings of Volume, Balance, Contrast,

Configuration, etc. The display will read:

Press PARAM to restore normal operation. (Remember to check the LCD

contrast and Configuration settings, since they will have been reset to

factory defaults.)

If you cannot solve functional problems through these procedures, consult

your dealer or Lexicon/Customer Service Department. DO NOT, UNDER

ANY CIRCUMSTANCES, OPEN THE UNIT. DOING SO WILL VOID

YOUR WARRANTY, AND MODIFICATIONS MAY RENDER THE

UNIT UNSERVICEABLE.

** TEST MODE **

PRM Key To Exit

RESTORE DEFAULTS
