Summarization of Contents
Information for your safety and comfort
Safety Instructions
Read safety instructions carefully and follow all warnings and instructions marked on the product.
Special Notes on LCD Monitors
Explains normal LCD behaviors like screen flicker, uneven brightness, pixel defects, and afterimages.
Cleaning Your Monitor
Provides guidelines for cleaning the monitor, including unplugging it first and using a soft cloth.
Tips and Information for Comfortable Use
Finding Your Comfort Zone
Tips for adjusting viewing angle, using a footrest, and maintaining posture for comfort.
Unpacking
Adjusting the Base
Instructions on how to attach and secure the monitor base for stable positioning.
Screen Position Adjustment
Guide to adjusting the monitor tilt for optimal viewing, up to 15 degrees up or 3 degrees down.
Connecting the Adapter and AC Power Cord
Steps for connecting the AC adapter and power cord to the monitor and outlet.
Power Saving
Explanation of the monitor's power saving mode and LED indicator behavior.
Troubleshooting
VGA Mode Troubleshooting
Troubleshooting steps for 'No picture visible' and 'Unstable picture' issues in VGA mode.
DVI/HDMI Mode Troubleshooting
Troubleshooting steps for 'No picture visible' issues in DVI/HDMI modes.
Installation
Connecting the Video Cable
Instructions for connecting VGA, DVI, or HDMI cables between the monitor and computer.
Connecting the Audio Cable
Connects an audio cable to the monitor's audio port (for Audio-Input Models).
Connecting the Adapter
Connects the AC power adapter to the monitor and a grounded AC outlet.
Powering On the Monitor and Computer
Specifies the correct sequence for powering on the monitor and computer.
User Controls
Panel Controls
Overview of the monitor's physical buttons, their functions, and indicator lights.
Using the OSD Menus
Picture Menu
Adjusts picture quality settings like brightness, contrast, position, and color temperature.
OSD Menu
Adjusts OSD menu location, H/V position, and OSD timeout settings.
Setting Menu
Adjusts general settings like Wide Mode, DDC/CI, input source, language, and reset options.
Information Menu
Displays basic information about the LCD monitor, including resolution and serial number.
Display Data Channel (DDC)
Connector Pin Assignment
Details pin assignments for 15-pin and 24-pin display signal cables.
19-Pin Color Display Signal Cable
Details pin assignments for the 19-pin color display signal cable.
