Automatic configuration

The charger communicates with
the sensor at regular intervals. The
fast charge cycle is controlled by data
exchanged between the PI sensor
and the charger, and a series of safety
mechanisms controls the termination
of the fast charging current.
The PS sensors do not
communicate with the charger. A
constant charge current of 58 mA is
then set up by the charger regardless
of the battery temperature.
Simrad
Kongsberg Maritime AS
Strandpromenaden 50
P.O.Box 111
N-3191 Horten, Norway
Simrad PI Charger
Typical sensor (PI Depth)
(A) = Negative charging / fastening lug
(B) = Positive charging / fastening lug
(C) = Communication link
(D) = Location of sensor lamp
(E) = Water switch sensor
(F) = Water pressure sensor
Telephone: +47 33 03 40 00
Telefax: +47 33 04 29 87
www.simrad.com
simrad.sales@simrad.com
A
A
(CD012206H)
E
F
164681 / Rev.D / June 2007
C
B
D
B
