To know how your fishing gear behaves is vital for efficient
fishing. The PI system provides you with vital information
such as the stability of the doors (door spread sensors),
quality of your catch (catch sensors), efficiency of your bottom
trawl (bottom contact sensor) or correct time of purse seining
(depth/sink rate sensor). In addition the PI system has a built
in echosounder all in a compact cabinet.
The cabinet comes in three sizes PI32 (6"), PI44 (10")
and the PI54 (15") where the PI32 can receive data from
3 sensors and the PI44/54 can receive data from 6 sensors
at the same time. The quality of Simrad echosounders is
recognized all over the world and now it is integrated in the
PI system. Important features like bottom expansion, shift
function, pulse length and White Line are standard.
The PI44/54 has a built in 1kW
dual frequency echosounder.
You can choose between 38,
50 or 200 kHz where two
frequencies can be shown at
the same time.
New crystal clear 10 and 15 inch screens.
Bottom trawl with 4m trawl height,
decreasing with 1m/min. Door
spread is 80,8m, increasing with
2m/min. Catch sensor 1 has not
been triggered yet. Catch sensor
2 is triggered and has been for
19 min during last haul.
The split screen is showing sensor
information, surface temperature
and echosounder image. The echo-
sounder displays bottom expansion
and trawl markers.
