Simrad SR70 Catch Monitoring Receiver Installation Manual The purpose of this manual is to provide the descriptions and procedures required to install the SR70 Catch Monitoring Receiver and set it up to interface the TV80. • About this manual, page 5 •... - Page 4 Support information If you require maintenance or repair, contact your local dealer. You can also contact us using the following address: simrad.support@simrad.com. If you need information about our other products, visit https: //www.simrad.com.
- Page 5 SR70 Receiver Unit ........................ 6 Scope of supply........................7 System diagram........................9 Support information ......................10 INSTALLING THE SR70 USING ITS MOUNTING BRACKETS..13 CABLE PLAN ................14 LIST OF SR70 CABLES ............... 15 SETTING UP SUMMARY.............. 16 TECHNICAL SPECIFICATIONS............ 19 SR70 OUTLINE DIMENSIONS.............
- Page 6 Simrad SR70 Catch Monitoring Receiver 423852/A...
-
Page 7: About This Manual
The installation shipyard must provide all necessary design and installation drawings, as well as the relevant work standards and mounting procedures. If required, all documents provided by the shipyard for the physical installation of the SR70 must be approved by the vessel’s national registry and corresponding maritime authority and/or classification society. -
Page 8: Simrad Sr70
The SR70 operates on 110 to 230 VAC. SR70 main parts identification The rear part of the SR70 is fitted with connectors for up to four hydrophones, Ethernet interface, and AC and DC power. LED indicators provide status information about the hydrophones connected and the receiver performance. -
Page 9: Scope Of Supply
This is the order number. The number identifies a complete unit and relevant accessories packed in its shipping container. Optional items The items are not included with the SR70 delivery, and must be ordered separately. Optional items Order number Part number... - Page 10 Simrad SR70 Catch Monitoring Receiver Related topics System diagram, page 9 423852/A...
-
Page 11: System Diagram
Installation Manual System diagram The system diagram identifies the main components of a basic SR70 system. The basic system configuration consists of a SR70, two hydrophones, and a computer where the Simrad TV80 software runs. Display Computer + TV80 SR70 Catch Monitoring Receiver Hydrophone (The SR70 Catch Monitoring Receiver allows you to connect four hydrophones.) -
Page 12: Support Information
Simrad SR70 Catch Monitoring Receiver Support information If you need technical support for your Simrad SR70 you must contact your local dealer, or one of our support departments. A list of all our offices and dealers is provided on our website. - Page 13 Installation Manual • : Kongsberg Underwater Technology Inc / Simrad Fisheries Company name • : 19210 33rd Ave W, Suite A, Lynnwood, WA 98036, USA Address • : +1 425 712 1136 Telephone • : +1 425 712 1193 Telefax •...
- Page 14 Simrad SR70 Catch Monitoring Receiver China • : Kongsberg Maritime China Ltd Company name • : 555 Chuanqiao Road, China (Shanghai) Pilot Free Trade Zone, 201206, China Address • : +86 21 3127 9888 Telephone • : +86 21 3127 9555 Telefax •...
-
Page 15: Installing The Sr70 Using Its Mounting Brackets
You must be equipped with a standard set of tools. This tool set must comprise the normal tools for electronic and electromechanical tasks. Context If you mount the SR70 on a bulkhead, position the unit so that all the connectors are facing down. Ensure maximum physical distance between the receiver unit and the power supply unit. -
Page 16: Cable Plan
Simrad SR70 Catch Monitoring Receiver Cable plan The cables are used to connect the SR70 to the computer and to the hydrophone or hydrophones. Display Computer + TV80 SR70 Catch Monitoring Receiver Hydrophones Cables identified with an asterisk (*) are system or commercial cables. These cables are provided with the SR70 delivery or the relevant item. -
Page 17: List Of Sr70 Cables
Installation Manual List of SR70 cables A set of cables is required to connect the SR70 units to each other, and to the relevant power source(s). Additional cables are required to connect the SR70 to peripheral devices. Computer cables Cable... -
Page 18: Setting Up Summary
Simrad SR70 Catch Monitoring Receiver Setting up summary Before a new SR70 Catch Monitoring Receiver can be put to use, it must be set up for operation. Prerequisites The Receiver Unit must be connected to the computer using an Ethernet line. - Page 19 Installation Manual Inspect the quality of reception identifying the cleanest frequencies. Select the hydrophone icon on the corresponding “block diagram” to open the dialog box. Hydrophone Setup Select the icon, under the Hydrophone icon to access the Spectrum Spectrum dialog box. The graph in the dialog box provides you with information about the Spectrum...
- Page 20 Simrad SR70 Catch Monitoring Receiver Select the gear you wish to use. page is located at the left of the dialog Select Gear Installation box. Select one or more catch monitoring sensors, and place them on the chosen gear. To open the...
-
Page 21: Technical Specifications
Installation Manual Technical specifications These technical specifications summarize the main functional and operational characteristics of the SR70 Catch Monitoring Receiver. Note At Kongsberg Maritime, we are continuously working to improve the quality and performance of our products. The technical specifications may be changed without prior notice. -
Page 22: Sr70 Outline Dimensions
Simrad SR70 Catch Monitoring Receiver SR70 outline dimensions Download the source drawing from the SR70 pages on https://www.simrad.com. 423852/A... -
Page 23: Overview Of Frequency Selection
If many acoustic systems are used simultaneously, due care must be taken to prevent acoustic interference between the different instruments. Make sure you do not have any interfering channel if you have a PI Receiver working simultaneously with an SR15 or SR70 Receiver. Kongsberg Maritime Catch monitoring sensors communicate on a frequency range from 40 to 50 kHz. - Page 24 ©2020 Kongsberg Maritime...
