MediCrystal B09TDH6VGL Quick Start Manual

EN
FIRM BLACK 7-GEMS MULTIPOLAR MAGNETIC PHOTON SINGLE MAT
SIZE: 40"x76" (100x190 cm)
‹
HEATING AREA: 40"x61" (100x154 cm)
‹
FIR HEAT ADJUSTABLE: 86–158°F (30–70°C)
‹
2 BIMETAL SENSORS
‹
3 THERMOSTAT SENSORS
‹
24 pcs
NEW 3-IN-1 BIO-STIMULATION LEDS
‹
6 MAGNETIC COILS; 10 MULTIPOLAR MAGNETS
‹
14 kg (30.9 lbs) OF CRUSHED CRYSTALS:
‹
AMETHYST/SODALITE/WHITE CRYSTAL/YELLOW
AVENTURINE/GREEN AVENTURINE/RED AGATE/
JASPER RED (~1.8 kg/4 lbs of each crystals)
HEATING POWER: 300W
‹
VOLTAGE: 110–120V, 60 Hz
‹
46.3 lbs (21 kg)
TOTAL WEIGHT:
‹
21
layers
LED 1: 660 nm
LED 2: 850 nm
Red Agate
LED 3: 980 nm
Jasper Red
Layer 1 – High-quality heat-resistant black eco-suede, elegant, soft, comfortable,
1
durable, and easy to clean, featured with MediCrystal® Logo on the top.
Layer 2 – Heat-resistant mesh fabric with elegant embroidery to fix crystals by no glue
2
artisan sewing process.
Layer 3 – High Grade «A-AB» crushed to 2-10 mm and tumbled natural, not chemically
3
treated Amethyst, Sodalite, Yellow and Green Aventurine, Red Agate, Jasper Red and White
crystals. Hot crystals and gems release heating Far InfraRed (FIR) rays and Negative Ions.*
Layer 4 – Bio-Stimulation Photon 3-in-1 Red, NIR, MIR LEDs. NEW Photon Light comes with
3 LEDs inside. Each lamp is with one Visible Red Monochromatic 660 Nm and two invisible
Near-Infrared and/or Mid-Infrared 800-1200 Nm light emission diodes.
Layer 5 – Bamboo carbon fiber cotton with high mineral content accumulating heat for
5
even thermal distribution.
Layer 6 – Non-woven functional fabric layer for increased release of Negative Ions.
6
Layer 7 – Oxford waterproof fabric layer to protect inner mat sensors and heating systems
7
from moisture and sweat.
Layer 8 – Electronic-wave proof copper fiber fabric EMI (Electro-Magnetic Interceptor)
8
layer for primary shielding user from any remaining electromagnetic fields (EMF).
Layer 9 – Aluminum foil EMI layer blocking EMFs and uniformly distributing the heat to
9
the upper layer with gemstones.
Layer 10 – Durable 0.2 mm non-woven glass fiber fabric layer for heating wire fixing and
10
protection.
Layer 11 – Unique heating wires in double silicon insulation twice shielded with copper
11
and foil to eliminate EMFs.
All products, controllers, specifications and data, and a set of items packaged in a box are subject to change without notice to improve the devices' reliability, function, or design.
QUICKSTART GUIDE
single
mat
Yellow aventurine
Natural Sodalite
18
19
20
21
Please, check for the details of the most updated products at the
MEDICRYSTAL® SINGLE MAT SET INCLUDES:
CARRY AND STORAGE printed owner's
BAG for your mat
L-40PVUB
operational
CONTROLLER
with wires
Mat electrical connector for controller plug.
A tight connection between the Mat and the
controller is essential to avoid errors and faults
1
3
2
5
6
7
8
9
11
10
14
Green aventurine
15
16
Natural Crystals are fixed
with mesh fabric on all the surfaces of
the Mat from edge to edge
Layer 12 – Thermostat sensors measure temperature in the different multilayer structure
points and report to the controller. This is the current Mat's temperature that you can see
on the controller display. The temperature sensors help to maintain a consistent heat level
throughout the Mat as set by the user. They are also a part of the overheat protection
controller system.
Layer 13 – Bimetal switches for emergency overheat protection with automatic power
shut-off feature if the controller overheats protection system fails, and the Mat heats up to
80°C or 176°F.
Layer 14 – Cotton fabric laminated with yellow mud accumulating heat, discharging
14
Negative Ions, naturally releasing Far InfraRed rays.
Layer 15 – Charcoal fabric layer releasing Far InfraRed (FIR) Rays and Negative Ions,
15
decomposing and deodorizing smell.
Layer 16 – Pure aluminum foil FIR reflection blocks heat from being conducted downwards
16
and assists other layers in distributing and continually releasing the heat evenly.
Layer 17 – Magnetic coils.
Layer 18 – Non-woven fabric layer for heat absorption and preservation.
18
Layer 19 – Compressed non-woven cotton padding with Multipolar Magnetic Side Logo
19
for thermal protection and increased comfort.
Layer 20 – Powerful 14,500 Gauss (1.45 Tesla) Quadrupole Magnets generating Alternating
20
Pole Static Magnetic field. Deep magnetism penetration is minimum of 1.5 inches (35 мм)
on the top side of the mat and 2 inches (50 mm) on the rear Multipolar Magnetic Side.
Layer 21 – Waterproof polyester peach skin or oxford fabric for durability, tension
21
resistance, and protection from moisture, dirt, and wear.
www.MediCrystal.com
1 or 2 valuable toppers permeable
guide for IONS, FIR RAYS, and magnetic:
HIGH ABSORPTION BREATHABLE
WATERPROOF MULTILAYER
PROTECTION COVER TO KEEP
3D AIR MESH PAD
TO CUSHION MAT AND
PROVIDE BODY SUPPORT
DISTRIBUTING STONES
11
Artisan sewing
and mesh fabric
White crystals
Natural Amethyst
website.
110-120V
MAT CLEAN
and/or
PRESSURE
EMF
FREE
HEATING
SYSTEM
Reveals crystals' powers and
brings natural forces into your
home*
Provides a restful and calming
setting in the middle of mod-
ern civilization*
Creates an energized envi-
ronment to feel inspired and
happy*
The controller provides the
choice of four magnetism pro-
grams with 4, 8, 10, or 14 Hz
Quadrupolar Static Disk Magnets
with four quadrants alternating
south and north pole magnetic
fields. 12"x0.24" (28x6 mm)
heat-resistant highest N50M grade
rare-earth magnets naturally
generate permanent multipole
magnetism without electricity.
