MediCrystal B09TDJZY36 Quick Start Manual

EN
FLEXIBLE TAN 5-GEMS MULTIPOLAR MAGNETIC PHOTON MEDIUM PAD
SIZE: 55x120 cm (22"x48")
‹
HEATING AREA: 55x95 cm (22"x38")
‹
FIR HEAT ADJUSTABLE: 86–158°F (30–70°C)
‹
1 BIMETAL SENSOR
‹
2 THERMOSTAT SENSORS
‹
18 pcs
NEW 3-IN-1 BIO-STIMULATION LEDS
‹
6 MULTIPOLAR MAGNETS
‹
4.5 kg (9.9 lbs) OF CRUSHED CRYSTALS:
‹
AMETHYST/ GREEN AVENTURINE/
WHITE CRYSTAL/RED AGATE/YELLOW
AVENTURINE (~0.9 kg/2 lbs of each crystals)
HEATING POWER: 140–150W
‹
VOLTAGE: 110–120V, 60 Hz
‹
6.6 kg (14.6 lbs)
TOTAL WEIGHT:
‹
Natural Amethyst
20
layers
LED 1: 660 nm
LED 2: 850 nm
LED 3: 980 nm
Red Agate
Green aventurine
Layer 1 – High-quality heat-resistant coffee tan eco-suede, elegant, soft, comfortable,
1
durable, and easy to clean, featured with MediCrystal® Logo on the top.
Layer 2 – Heat-resistant mesh fabric with elegant embroidery to fix crystals by no glue
2
artisan sewing process.
Layer 3 – High Grade «A-AB» crushed to 2-10 mm and tumbled natural, not chemically
3
treated Amethyst, Yellow and Green Aventurine, Red Agate and White crystals. Hot crystals
and gems release heating Far InfraRed (FIR) rays and Negative Ions.*
Layer 4 – Bio-Stimulation Photon 3-in-1 Red, NIR, MIR LEDs. NEW Photon Light comes with
3 LEDs inside. Each lamp is with one Visible Red Monochromatic 660 Nm and two invisible
Near-Infrared and/or Mid-Infrared 800-1200 Nm light emission diodes.
Layer 5 – Bamboo carbon fiber cotton with high mineral content accumulating heat for
5
even thermal distribution.
Layer 6 – Non-woven functional fabric layer for increased release of Negative Ions.
6
Layer 7 – Oxford waterproof fabric layer to protect inner mat sensors and heating systems
7
from moisture and sweat.
Layer 8 – Electronic-wave proof copper fiber fabric EMI (Electro-Magnetic Interceptor)
8
layer for primary shielding user from any remaining electromagnetic fields (EMF).
Layer 9 – Aluminum foil EMI layer blocking EMFs and uniformly distributing the heat to
9
the upper layer with gemstones.
Layer 10 – Durable 0.2 mm non-woven glass fiber fabric layer for heating wire fixing and
10
protection.
Layer 11 – Unique heating wires in double silicon insulation twice shielded with copper
11
and foil to eliminate EMFs.
All products, controllers, specifications and data, and a set of items packaged in a box are subject to change without notice to improve the devices' reliability, function, or design.
QUICKSTART GUIDE
medium
pad
Mat electrical connector for controller plug. A tight connection
between the Mat and the controller is essential to avoid errors
and faults
White crystals
19
18
20
Please, check for the details of the most updated products at the
MEDICRYSTAL® PAD SET INCLUDES:
CARRY AND STORAGE printed owner's
BAG for your mat
L-40PT
operational
CONTROLLER
with wires
1
3 2
5
6
7
8
9
11
10
14
15
16
17
Natural Crystals are fixed
with mesh fabric on all the surfaces of
the Mat from edge to edge
Layer 12 – Thermostat sensors measure temperature in the different multilayer structure
points and report to the controller. This is the current Mat's temperature that you can see
on the controller display. The temperature sensors help to maintain a consistent heat level
throughout the Mat as set by the user. They are also a part of the overheat protection
controller system.
Layer 13 – Bimetal switches for emergency overheat protection with automatic power
shut-off feature if the controller overheats protection system fails, and the Mat heats up to
80°C or 176°F.
Layer 14 – Cotton fabric laminated with yellow mud accumulating heat, discharging
14
Negative Ions, naturally releasing Far InfraRed rays.
Layer 15 – Charcoal fabric layer releasing Far InfraRed (FIR) Rays and Negative Ions,
15
decomposing and deodorizing smell.
Layer 16 – Pure aluminum foil FIR reflection blocks heat from being conducted downwards
16
and assists other layers in distributing and continually releasing the heat evenly.
Layer 17 – Non-woven fabric layer for heat absorption and preservation.
17
Layer 18 – Compressed non-woven cotton padding for thermal protection and increased
18
comfort.
Layer 19 – Powerful 14,500 Gauss (1.45 Tesla) Quadrupole Magnets generating
19
Alternating Pole Static Magnetic field. Deep magnetism penetration is minimum of 1.5
inches (35 мм) on the top side of the mat and 2 inches (50 mm) on the rear Multipolar
Magnetic Side. Multipole magnetization provides the optimal circulation of equal amounts
of magnetic field flow from both the north and south poles.
Layer 20 – Waterproof polyester peach skin or oxford fabric with Multipolar Magnetic Side
20
Logo for durability, tension resistance, and protection from moisture, dirt, and wear.
www.MediCrystal.com
1 or 2 valuable toppers permeable
guide for IONS and FIR RAYS:
HIGH ABSORPTION BREATHABLE
WATERPROOF MULTILAYER
PROTECTION COVER TO KEEP
MAT CLEAN
3D AIR MESH PAD
TO CUSHION MAT AND
PROVIDE BODY SUPPORT
DISTRIBUTING STONES
PRESSURE
11
Artisan sewing
and mesh fabric
Yellow aventurine
website.
110-120V
and/or
EMF
FREE
HEATING
SYSTEM
Reveals crystals' powers and
brings natural forces into your
home*
Provides a restful and calming
setting in the middle of mod-
ern civilization*
Creates an energized envi-
ronment to feel inspired and
happy*
A great complement to mas-
sage, yoga, and reiki*
Quadrupolar Static Disk Mag-
nets with four quadrants alter-
nating south and north pole
magnetic fields. 12"x0.24"
(28x6 mm) heat-resistant
highest N50M grade rare-earth
magnets naturally generate
permanent multipole magne-
tism without electricity.
