Jackery JE-300B Connection Manual

Solar generator
Hide thumbs Also See for JE-300B:
Table of Contents

Advertisement

Quick Links

Download this manual
Jackery Solar Generator
Connection Guide
US
English
FR
Français
ES
Español
PT
Português (Brasil)
0 1 - 1 2
1 3 - 2 4
2 5 - 3 6
3 7- 4 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JE-300B and is the answer not in the manual?

Questions and answers

Related Manuals for Jackery JE-300B

Summary of Contents for Jackery JE-300B

  • Page 1 Jackery Solar Generator Connection Guide English 0 1 - 1 2 Français 1 3 - 2 4 Español 2 5 - 3 6 Português (Brasil) 3 7- 4 8...

  • Page 2: Table Of Contents

    Jackery SolarSaga 100 Prime Solar Panel (JS-100E) Jackery SolarSaga 100 Solar Panel (JS-100F) Jackery SolarSaga 200 Solar Panel (JS-200A) Jackery SolarSaga 200 Solar Panel (JS-200C) Jackery SolarSaga 200 Solar Panel (JS-200D) Jackery SolarSaga 85/SolarSaga 500X Solar Panel (JS-85A / JS-500A)

  • Page 3: Jackery Solarsaga 40 Mini Solar Panel (Js-40A)

    Jackery SolarSaga 40 Mini Solar Panel (JS-40A) DC Input Portable Power Station Connection Method Connection Details Explorer 100 Plus 1. Connect the DC8020 Explorer 240 V2 output port of the solar panel USB-C DC8020 output port Explorer 280 Plus to the input port of the...

  • Page 4: Jackery Solarsaga 60 Solar Panel (Spl061)

    Jackery Solar Panel SolarSaga (SPL061) DC Input Portable Power Station Connection Method Connection Details Explorer 100 Plus The DC8020 to USB-C adapter cable is sold separately. Explorer 240 V2 DC8020 to USB-C adapter cable 1. Connect the DC7909 output Explorer 280 Plus...

  • Page 5: Jackery Solarsaga 80 Solar Panel (Js-80A)

    Jackery Solar Panel SolarSaga 80 (JS-80A) DC Input Portable Power Station Connection Method Connection Details Explorer 100 Plus The DC8020 to USB-C adapter DC8020 to USB-C cable is sold separately. Explorer 240 V2 adapter cable 1. Connect the DC8020 output...

  • Page 6: Jackery Solarsaga 100 Solar Panel (Js-100A)

    Jackery Solar Panel SolarSaga 100 (JS-100A) DC Input Portable Power Station Connection Method Connection Details Explorer 100 Plus The DC8020 to USB-C adapter Explorer 240 V2 cable is sold separately. DC7909 to DC8020 adapter Explorer 280 Plus 1. Connect the DC7909 output port...

  • Page 7: Jackery Solarsaga 100 Solar Panel (Js-100C)

    Jackery Solar Panel SolarSaga 100 (JS-100C) DC Input Portable Power Station Connection Method Connection Details Explorer 100 Plus The DC8020 to USB-C adapter Explorer 240 V2 cable is sold separately. DC7909 to DC8020 adapter Explorer 280 Plus 1. Connect the DC7909 output...

  • Page 8: Jackery Solarsaga 100 Solar Panel (Js-100D)

    Jackery Solar Panel SolarSaga 100 (JS-100D) DC Input Portable Power Station Connection Method Connection Details Explorer 100 Plus The DC8020 to USB-C Explorer 240 V2 adapter cable is sold Explorer 280 Plus separately. USB-C DC8020 output port Explorer 300 Plus 1.

  • Page 9: Jackery Solarsaga 100 Prime Solar Panel (Js-100E)

    Jackery Solar Panel SolarSaga 100 Prime (JS-100E) DC Input Portable Power Station Connection Method Connection Details Explorer 100 Plus The DC8020 to USB-C adapter cable DC8020 to USB-C adapter cable Explorer 240 V2 is sold separately. Explorer 280 Plus 1. Connect the Anderson output port...

  • Page 10: Jackery Solarsaga 100 Solar Panel (Js-100F)

    Jackery Solar Panel SolarSaga 100 (JS-100F) DC Input Portable Power Station Connection Method Connection Details Explorer 100 Plus The DC8020 to USB-C DC8020 to USB-C Explorer 240 V2 adapter cable is sold adapter cable Explorer 280 Plus separately. USB-C Explorer 300 Plus 1.

  • Page 11: Jackery Solarsaga 200 Solar Panel (Js-200A)

    Jackery Solar Panel SolarSaga 200 (JS-200A) DC Input Portable Power Station Connection Method Connection Details Explorer 100 Plus The DC8020 to USB-C adapter Explorer 240 V2 cable is sold separately. DC7909 to DC8020 adapter Explorer 280 Plus 1. Connect the DC7909 output port...

  • Page 12: Jackery Solarsaga 200 Solar Panel (Js-200C)

    Jackery Solar Panel SolarSaga 200 (JS-200C) DC Input Portable Power Station Connection Method Connection Details Explorer 100 Plus The DC8020 to USB-C adapter Explorer 240 V2 cable is sold separately. DC7909 to DC8020 adapter Explorer 280 Plus 1. Connect the DC7909 output port...

  • Page 13: Jackery Solarsaga 200 Solar Panel (Js-200D)

    Jackery Solar Panel SolarSaga 200 (JS-200D) DC Input Portable Power Station Connection Method Connection Details Explorer 100 Plus The DC8020 to USB-C DC8020 to USB-C Explorer 240 V2 adapter cable is sold adapter cable Explorer 280 Plus separately. USB-C Explorer 300 Plus 1.

  • Page 14: Jackery Solarsaga 85/Solarsaga 500X Solar Panel (Js-85A / Js-500A)

    Jackery Solar Panel SolarSaga 85/SolarSaga 500X (JS-85A/JS-500A) DC Input Portable Power Station Connection Method Connection Details 1. Connect the Anderson Explorer 1000 V2 DC8020 input port Anderson output port output port of the solar Explorer 1000 Plus panel to the input port of...
