Aries Offroad 4043 Manual

99/02 Chevy Silverado 1500; 00/05 Tahoe;
Parts List
1 – Driver Side Bracket
10 – ½ x 1 ½ Bolts
2 – M12 x 1.75 x 40mm Bolts
20 – ½ USS Washers
Installing the Frame Brackets
Remove factory tow hooks from front section of vehicle. NOTE: If reusing tow hooks,
you must switch driver side for passenger and vice versa. Some models do not align
completely. You must trim off small portion off the tow hook. Attach the frame brackets
as shown in illustration. Using bolts supplied in kit, hand-tighten in case you have to
adjust the front bar to align it.
Installing the Front Bar
Line up the three holes on the lower portion of the bar with the three holes in the frame
brackets (outer edge). Attach bar to the frame brackets using the ½ x 1 ½ bolts and nuts.
When you are satisfied the bar is aligned, tighten the three bolts supporting the bar.
Tighten the bolts holding the frame brackets to the vehicle.
DIAGRAM
00/05 Suburban
1 – Passenger Side Bracket
10 – ½ Lock nuts
2 – ½ x 5 ½ Bolts
